GMK NucBox M5 迷你电脑评测:AMD Zen 2 已显老态
AMD Ryzen 7 5700U | AMD Radeon RX Vega 8 (Ryzen 4000/5000) | 505 g
AMD Ryzen 75700U是基于Lucienne一代的轻薄笔记本电脑处理器。 R75700U基于Zen2微体系结构整合了所有8个核心,是上市时速度第二快的U系列处理器。 1.8(保证基本时钟)~4.3GHz(涡轮)时钟,支持SMT/超线程(16线程)。 芯片采用现代7nm TSMC工艺制造。 与基于新Zen3体系结构的Ryzen 75800U相比,5700U基本上更名为Renoir CPU(Zen2)。 有关详细信息,请参见 Renoir Processors 的集线器页面。
CPU和GPU的时钟速度加快,性能必须比旧的Ryzen 74800U稍高。
除8个CPU内核外,APU还内置了8个CU和1900MHz的Radeon RX Vega 8集成显卡。双通道内存控制器支持DDR4-3200和节能LPDDR4-4266 RAM。 另外,在芯片上也能够找到 8MB级 3高速缓存。
APU的TDP由笔记本电脑供应商指定为15瓦特(默认),可配置10~25瓦特(大部分芯片配置为15瓦特以上)。 也就是说,该芯片适用于薄型、轻型的笔记本电脑(风扇)。
Codename | Lucienne-U (Zen 2) | ||||||||||||
Series | AMD Lucienne (Zen 2, Ryzen 5000) | ||||||||||||
Series: Lucienne (Zen 2, Ryzen 5000) Lucienne-U (Zen 2)
| |||||||||||||
Clock Rate | 1800 - 4300 MHz | ||||||||||||
Level 1 Cache | 512 KB | ||||||||||||
Level 2 Cache | 4 MB | ||||||||||||
Level 3 Cache | 8 MB | ||||||||||||
Number of Cores / Threads | 8 / 16 | ||||||||||||
Power Consumption (TDP = Thermal Design Power) | 25 Watt | ||||||||||||
Manufacturing Technology | 7 nm | ||||||||||||
Max. Temperature | 105 °C | ||||||||||||
Socket | FP6 | ||||||||||||
Features | DDR4-3200/LPDDR4-4266 RAM, PCIe 3, MMX, SSE, SSE2, SSE3, SSSE3, SSE4A, SSE4.1, SSE4.2, AVX, AVX2, BMI2, ABM, FMA, ADX, SMEP, SMAP, SMT, CPB, AES-NI, RDRAND, RDSEED, SHA, SME | ||||||||||||
GPU | AMD Radeon RX Vega 8 (Ryzen 4000/5000) ( - 1900 MHz) | ||||||||||||
64 Bit | 64 Bit support | ||||||||||||
Architecture | x86 | ||||||||||||
Announcement Date | 01/07/2021 | ||||||||||||
Product Link (external) | www.amd.com |
