AMD Ryzen 5 7520C

AMD R5 7520C

AMD Ryzen 5 7520C 是用于 Mendocino 系列 chromebook 的移动处理器。它集成了四个较旧的 Zen 2 内核(类似于 Ryzen 4000 系列,如 Ryzen 3 4300U).CPU 内核频率从 2.8 GHz(基本频率)到 4.3 GHz(单核 Turbo)不等,可使用 4 MB 三级缓存。由于采用了 SMT/超线程技术,CPU 可以同时运行 8 个线程。集成内存控制器仅支持快速 LPDDR5 内存(最高 5500 MHz)。7520C 是Chromebook 版本的 Ryzen 5 7520U7520C 是 Ryzen 5 7520U 的 变体,提供相同的规格(因此性能也相同)。

集成显卡Radeon 610M iGPU) 采用现代 RDNA 2 架构,但只有 2 个 CU(128 个着色器),时钟频率高达 1.9 GHz。

得益于更快的内存和更高的时钟频率,CPU 性能应略高于 Ryzen 4000U 四核。

Mendocino 系列采用台积电相对先进的 6nm FinFET 工艺生产,应该能提供良好的能效。R5 7520C 的额定 TDP 为 15 W,因此非常适合轻薄型笔记本电脑。

SeriesAMD Mendocino (Zen 2, Ryzen 7020)
CodenameMendocino (Zen 2)

Series: Mendocino (Zen 2, Ryzen 7020) Mendocino (Zen 2)

AMD Ryzen 5 7520C « 2.8 - 4.3 GHz4 / 8 cores4 MB L3
AMD Ryzen 3 7320C2.4 - 4.1 GHz4 / 8 cores4 MB L3
AMD Athlon Gold 7220U2.4 - 3.7 GHz2 / 4 cores4 MB L3
AMD Athlon Gold 7220C2.4 - 3.7 GHz2 / 4 cores4 MB L3
AMD Athlon Silver 7120U2.4 - 3.5 GHz2 / 2 cores2 MB L3
AMD Athlon Silver 7120C2.4 - 3.5 GHz2 / 2 cores2 MB L3
Clock Rate2800 - 4300 MHz
Level 1 Cache256 KB
Level 2 Cache2 MB
Level 3 Cache4 MB
Number of Cores / Threads4 / 8
4 x 4.3 GHz AMD Zen 2
Power Consumption (TDP = Thermal Design Power)15 Watt
Manufacturing Technology6 nm
FeaturesXFR, FMA3, SSE 4.2, AVX2, SMT
GPUAMD Radeon 610M ( - 1900 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date05/23/2023
Product Link (external)www.amd.com

Benchmarks

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.28
log 31. 04:09:00

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Mon, 28 Oct 2024 05:31:42 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_2 needed +0.016s ... 0.017s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.018s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.018s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.018s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.019s

#9 composed specs +0.001s ... 0.019s

#10 did output specs +0s ... 0.019s

#11 getting avg benchmarks for device 15040 +0.003s ... 0.023s

#12 got single benchmarks 15040 +0s ... 0.023s

#13 got avg benchmarks for devices +0s ... 0.023s

#14 min, max, avg, median took s +0s ... 0.023s

#15 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.023s

#16 return log +0s ... 0.023s

No reviews found for this CPU (yet).

Please share our article, every link counts!

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series Mendocino (Zen 2, Ryzen 7020)

» AMD Ryzen 5 7520U
   4x 2.8 GHz - 4.3 GHz
» AMD Ryzen 5 7520C
   4x 2.8 GHz - 4.3 GHz
» AMD Ryzen 3 7320U
   4x 2.4 GHz - 4.1 GHz
» AMD Ryzen 3 7320C
   4x 2.4 GHz - 4.1 GHz
» AMD Athlon Gold 7220U
   2x 2.4 GHz - 3.7 GHz
» AMD Athlon Gold 7220C
   2x 2.4 GHz - 3.7 GHz
» AMD Athlon Silver 7120U
   2x 2.4 GHz - 3.5 GHz
» AMD Athlon Silver 7120C
   2x 2.4 GHz - 3.5 GHz

Surrounding CPUs

+ Intel Core i7-1060G7
   4x 1 GHz - 3.8 GHz
+ Intel Core i5-1034G1
   4x 0.8 GHz - 3.6 GHz
+ Intel Core i5-8365U
   4x 1.6 GHz - 4.1 GHz
+ AMD Ryzen 3 7330U
   4x 2.3 GHz - 4.3 GHz
+ AMD Ryzen 5 7520U
   4x 2.8 GHz - 4.3 GHz
» AMD Ryzen 5 7520C
   4x 2.8 GHz - 4.3 GHz
- AMD Ryzen 3 7320U
   4x 2.4 GHz - 4.1 GHz
- AMD Ryzen 3 7320C
   4x 2.4 GHz - 4.1 GHz
- Intel Core i7-3740QM
   4x 2.7 GHz - 3.7 GHz
- Intel Core i7-3720QM
   4x 2.6 GHz - 3.6 GHz
- Intel Core i7-4700HQ
   4x 2.4 GHz - 3.4 GHz
