AMD Ryzen 7 3700U

AMD R7 3700U

AMD Ryzen 7 3700U是一款移动SoC,已于2019年1月发布。它结合了时钟频率为2.3-4 GHz的四个Zen +内核(8个线程)和Radeon RX Vega 10图形卡以及时钟频率高达1400 MHz 的10个CU(640个着色器)。该SoC的额定功耗为15瓦TDP,适用于中型笔记本电脑。

Picasso SoC使用Zen +微体系结构并进行了一些细微的改进,从而可以将IPC(每频率性能)提高3%。此外,12nm工艺允许以相似的功耗获得更高的时钟速率。

集成的双通道内存控制器最多支持DDR4-2400内存。由于Picasso APU的功能与Raven Ridge的前代产品相同,因此,我们推荐您阅读Raven Ridge文章。

AMD指出,Picasso APU比以前的产品快8%。因此,Ryzen 7 3700U应该稍微领先于Ryzen 7 2700U。

SeriesAMD Picasso (Ryzen 3000 APU)
CodenamePicasso-U (Zen+)

Series: Picasso (Ryzen 3000 APU) Picasso-U (Zen+)

AMD Ryzen 7 3780U2.3 - 4 GHz4 / 8 cores4 MB L3
AMD Ryzen 7 3700U « 2.3 - 4 GHz4 / 8 cores4 MB L3
AMD Ryzen 5 3550H2.1 - 3.7 GHz4 / 8 cores4 MB L3
AMD Ryzen 5 3500U2.1 - 3.7 GHz4 / 8 cores4 MB L3
AMD Ryzen 5 3450U2.1 - 3.5 GHz4 / 8 cores4 MB L3
AMD Ryzen 5 3580U2.1 - 3.7 GHz4 / 8 cores4 MB L3
Clock Rate2300 - 4000 MHz
Level 1 Cache384 KB
Level 2 Cache2 MB
Level 3 Cache4 MB
Number of Cores / Threads4 / 8
Power Consumption (TDP = Thermal Design Power)15 Watt
Transistor Count4500 Million
Manufacturing Technology12 nm
Max. Temperature105 °C
SocketFP5
FeaturesDDR4-2400, PCIe 3, MMX, SSE, SSE2, SSE3, SSSE3, SSE4A, SSE4.1, SSE4.2, AVX, AVX2, BMI2, ABM, FMA, ADX, SMEP, SMAP, SMT, CPB, AES-NI, RDRAND, RDSEED, SHA, SME
GPUAMD Radeon RX Vega 10 ( - 1400 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date01/06/2019
Product Link (external)www.amd.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
24.7 pt (41%)
AMD E1-2100
2.33 -91%
...
Intel Core i7-8500Y
23.7 -4%
23.8 -4%
AMD Ryzen Embedded V1605B
23.9 -3%
24 -3%
Intel Core i3-8109U
24.2 -2%
Intel Core i5-6287U
24.4 -1%
24.5 -1%
24.5 -1%
Intel Core i7-6567U
24.6 0%
AMD Ryzen 7 3700U
24.7
24.8 0%
AMD Ryzen 5 3580U
24.9 1%
24.9 1%
24.9 1%
AMD Ryzen 7 2700U
25.1 2%
25.1 2%
25.2 2%
25.5 3%
25.8 4%
...
47.6 93%
max:
60.3 144%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
min: 285     avg: 339.2     median: 343 (38%)     max: 368 Points
Cinebench R20 - Cinebench R20 CPU (Multi Core)
min: 1047     avg: 1344     median: 1499 (4%)     max: 1560 Points
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 537     avg: 648     median: 672 (4%)     max: 683 Points
AMD A4-1200
31 -95%
...
Intel Core i7-4870HQ
629 -3%
630 -3%
Intel Core i7-4960HQ
632 -2%
634 -2%
635 -2%
Intel Core i7-4770HQ
635 -2%
AMD Ryzen 7 2700U
640 -1%
Intel Core i7-4900MQ
641 -1%
642 -1%
AMD Ryzen 7 3700U
648
650 0%
AMD Ryzen Embedded V1605B
654 1%
658 2%
Intel Core i5-1035G7
662 2%
666 3%
Intel Core i7-5850HQ
667 3%
671 4%
689 6%
AMD Ryzen 5 3580U
693 7%
...
5600 764%
max:
15842 2345%
0%
100%
03570105140175210245280315350385420455490525560595630665Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 127     avg: 138     median: 139 (39%)     max: 146 Points
AMD A4-1200
19 -86%
...
AMD Ryzen 3 3300U
134 -3%
Intel Core i7-6770HQ
134.5 -3%
AMD Ryzen 5 PRO 2500U
135 -2%
135.6 -2%
136.2 -1%
136.2 -1%
Intel Core i7-6600U
136.6 -1%
137.5 0%
137.9 0%
AMD Ryzen 7 3700U
138
Intel Core i3-8109U
138.7 1%
AMD Ryzen 5 3580U
139 1%
AMD Ryzen Embedded R1606G
139 1%
Intel Core i3-8130U
139 1%
Intel Core i7-5557U
140 1%
140 1%
Intel Core i5-7300U
140 1%
Intel Core i5-7267U
141 2%
141 2%
...
311 125%
max:
Intel Core Ultra 9 285K
355.5 158%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 5.02     avg: 7     median: 7.6 (10%)     max: 7.71 Points
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 1.23     avg: 1.5     median: 1.6 (38%)     max: 1.67 Points
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 4045     avg: 4411     median: 4410.5 (27%)     max: 4776 points
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 12881     avg: 15461     median: 15461 (11%)     max: 18041 points
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 27166     avg: 27205     median: 27205 (17%)     max: 27244 Points
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 7765     avg: 7767     median: 7767 (9%)     max: 7769 Points
wPrime 2.10 - wPrime 2.0 1024m *
450.4 s (5%)
wPrime 2.10 - wPrime 2.0 32m *
13.5 s (3%)
WinRAR - WinRAR 4.0
2392 points (4%)
7-Zip 18.03 - 7-Zip 18.03 Multi Thread 4 runs
min: 12738     avg: 15166     median: 15386.5 (9%)     max: 17153 MIPS
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
min: 3038     avg: 3423     median: 3492.5 (42%)     max: 3668 MIPS
X264 HD Benchmark 4.0 - x264 Pass 2
27.1 fps (9%)
X264 HD Benchmark 4.0 - x264 Pass 1
104.8 fps (24%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
min: 2.76     avg: 3.3     median: 3.3 (6%)     max: 3.9 fps
012345678Tooltip
TrueCrypt - TrueCrypt Serpent
0.4 GB/s (11%)
TrueCrypt - TrueCrypt Twofish
0.6 GB/s (11%)
TrueCrypt - TrueCrypt AES
3.8 GB/s (10%)
Blender - Blender 2.79 BMW27 CPU *
min: 671     avg: 797     median: 703 (5%)     max: 1018 Seconds
3DMark 06 - CPU - 3DMark 06 - CPU
4595 Points (10%)
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
12.6 s (3%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
29.6 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
748 s (3%)
3DMark 11 - 3DM11 Performance Physics
min: 5060     avg: 5955     median: 5416 (14%)     max: 7250 Points
3DMark - 3DMark Ice Storm Physics
min: 30752     avg: 31840     median: 31238.5 (25%)     max: 34132 Points
3DMark - 3DMark Ice Storm Extreme Physics
min: 30487     avg: 32042     median: 31393 (25%)     max: 34896 Points
3DMark - 3DMark Ice Storm Unlimited Physics
min: 24397     avg: 31189     median: 30959.5 (26%)     max: 38440 Points
3DMark - 3DMark Cloud Gate Physics
min: 2957     avg: 4954     median: 4978 (13%)     max: 7033 Points
3DMark - 3DMark Fire Strike Standard Physics
min: 6380     avg: 8272     median: 8698.5 (16%)     max: 9457 Points
3DMark - 3DMark Time Spy CPU
min: 2012     avg: 2427     median: 2224 (9%)     max: 3044 Points
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
min: 3445     avg: 3785     median: 3843.5 (38%)     max: 4009 points
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
min: 8907     avg: 10275     median: 10542 (11%)     max: 11107 points
Geekbench 4.0 - Geekbench 4.0 64 Bit Single-Core
3247 points (44%)
Geekbench 4.0 - Geekbench 4.0 64 Bit Multi-Core
9117 points (22%)
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
10238 points (18%)
Geekbench 3 - Geekbench 3 32 Bit Single-Core
3003 points (59%)
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
10881 points (17%)
Geekbench 3 - Geekbench 3 64 Bit Single-Core
3354 points (50%)
Geekbench 2 - 32 Bit - Geekbench Stream
7277 Points (59%)
Geekbench 2 - 32 Bit - Geekbench Memory
5738 Points (52%)
Geekbench 2 - 32 Bit - Geekbench Floating Point
12851 Points (25%)
Geekbench 2 - 32 Bit - Geekbench Integer
10434 Points (21%)
Geekbench 2 - 32 Bit - Geekbench Total Score
10025 Points (26%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 1285     avg: 1321     median: 1299 (2%)     max: 1405 ms
Sunspider - Sunspider 1.0 Total Score *
147.3 ms (2%)
Octane V2 - Octane V2 Total Score
min: 23657     avg: 26597     median: 27490 (24%)     max: 28301 Points
WebXPRT 3 - WebXPRT 3 Score
min: 152     avg: 154     median: 154 (32%)     max: 156 Points
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
