AMD Radeon HD 6450M

AMD Radeon HD 6450M

AMD Radeon HD6450M（有时也仍然被称为ATI的Mobility Radeon HD 6450）是入门级笔记本电脑，一台笔记本电脑的图形卡。它应当基于西摩PRO芯片上，因此配备的UVD3视频解码器。相比速度更快的HD 6470M，6450M提供了一个较慢的内核的时钟速度。 120个流处理器仍然是基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。 HD6370M（更名为5470），具有着色，但最可能的更高的核心时钟的性能应该是相似的。因此，目前所有的游戏运行在低细节设置很流利。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD6400M系列集成了HD音频控制器，通过HDMI和DisplayPort（如蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片能够在理论上同时驱动多达4个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。的Mobility Radeon HD 5450应该是相似的，因此适用于13“笔记本电脑和功耗的芯片。

Radeon HD 6400M Series

Radeon HD 6490M 160 @ 0.7 GHz64 Bit @ 800 MHz
Radeon HD 6470M 160 @ 0.7 GHz64 Bit @ 800 MHz
Radeon HD 6450M 160 @ 0.6 GHz64 Bit @ 800 MHz
Radeon HD 6430M 160 @ 0.48 GHz64 Bit @ 800 MHz
CodenameSeymour-PRO
ArchitectureTerascale 2
Pipelines160 - unified
Core Speed600 MHz
Memory Speed800 MHz
Memory Bus Width64 Bit
Memory TypeDDR3
Shared Memoryno
APIDirectX 11, Shader 5.0
technology40 nm
Date of Announcement04.01.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 505     avg: 507     median: 506.5 (1%)     max: 508 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
443 Points (0%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -61%
...
Intel HD Graphics 400 (Braswell)
341.1 -23%
AMD Radeon HD 8210
344.5 -22%
Intel HD Graphics 2500
349 -21%
NVIDIA GeForce GT 415M
379 -14%
Intel HD Graphics (Braswell)
389.9 -12%
AMD Radeon HD 7400G
415 -6%
NVIDIA GeForce 410M
415.3 -6%
AMD Radeon HD 8250
422.5 -5%
AMD Radeon HD 8240
427.5 -3%
AMD Radeon HD 6450M
443
AMD Radeon HD 7420G
453 2%
AMD Radeon HD 6480G
467 5%
Intel HD Graphics 405 (Braswell)
469.1 6%
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
471.7 6%
Intel HD Graphics 500
478.6 8%
Intel HD Graphics (Haswell)
479.6 8%
AMD Radeon HD 6520G
492 11%
AMD Radeon HD 8280
496 12%
NVIDIA GeForce GT 520M
499.8 13%
...
AMD Radeon RX 7900M
59943 13431%
max:
NVIDIA GeForce RTX 4090
104201 23422%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 1375     avg: 1395     median: 1394.5 (0%)     max: 1414 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 1073     avg: 1090     median: 1090 (1%)     max: 1107 Points
+ 2 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -94%
...
ATI Mobility Radeon HD 2600 XT
933 -14%
NVIDIA GeForce G210M
942 -14%
ATI Mobility Radeon HD 5470
945 -13%
ATI Mobility Radeon HD 545v
962 -12%
ATI Mobility Radeon HD 5145
972 -11%
NVIDIA GeForce GT 320M
997 -9%
ATI Mobility Radeon HD 3670
1027 -6%
NVIDIA GeForce 9650M GT
1054 -3%
AMD Radeon HD 6370M
1072 -2%
AMD Radeon HD 6450M
1090
AMD Radeon R2 (Mullins/Beema/Carrizo-L)
1091 0%
AMD Radeon HD 8250
1113 2%
NVIDIA GeForce GT 220M
1144 5%
Intel HD Graphics (Ivy Bridge)
1186 9%
NVIDIA GeForce 9600M GT
1192 9%
AMD Radeon HD 8240
1247 14%
AMD Radeon HD 6480G
1282 18%
AMD Radeon HD 6520G
1295 19%
Intel HD Graphics (Braswell)
1328 22%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 12051%
max:
AMD Radeon RX 7900 XTX
170928 15581%
0%
100%
3DMark 03 - 3DMark 03 - Standard
10322 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 7220     avg: 7236     median: 7235.5 (8%)     max: 7251 Points
+ 2 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
ATI Mobility Radeon HD 4570
6755 -7%
AMD Radeon R2 (Stoney Ridge)
6853 -5%
NVIDIA NVS 3100M
6928 -4%
ATI Mobility Radeon HD 4550
6991 -3%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
7024 -3%
NVIDIA GeForce 315M
7077 -2%
NVIDIA Quadro FX 380M
7095 -2%
ATI Mobility Radeon X1900
7117 -2%
NVIDIA GeForce 320M
7168 -1%
AMD Radeon HD 6450M
7236
AMD Radeon HD 6520G
7273 1%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
7282 1%
ATI Mobility Radeon HD 540v
7333 1%
AMD Radeon HD 6620G
7365 2%
ATI Mobility Radeon HD 5145
7483 3%
AMD Radeon R6 (Kaveri)
7493 4%
ATI Mobility Radeon X1800XT
7539 4%
ATI Mobility Radeon HD 3650
7539 4%
AMD Radeon HD 6510G2
7600 5%
...
AMD Radeon RX 7600M XT
68064 841%
max:
NVIDIA GeForce RTX 4080 Super
87172 1105%
0%
100%
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
4696 points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 3838     avg: 3846     median: 3845.5 (5%)     max: 3853 Points
+ 2 benchmarks and specifications   + Show comparison chart
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
3.6 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
3.2 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
10.5 fps (8%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 proe-05 +
SPECviewperf 11 - specvp11 proe-05
1.9 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
10.9 fps (8%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
20.3 fps (22%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 ensight-04 +
SPECviewperf 11 - specvp11 ensight-04
5.2 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
5 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
6.2 Points (78%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
5.1 Points (65%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
5804 points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 14.91     avg: 14.9     median: 14.9 (5%)     max: 14.92 fps
+ 2 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Anno 2070

Anno 2070

2011
low 1024x768
45.7  fps    + Compare
med. 1366x768
19.7  fps    + Compare
high 1366x768
13.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Fifa 12

Fifa 12

2011
low 800x600
162.6  fps    + Compare
med. 1024x768
66.1  fps    + Compare
high 1360x768
39.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Dirt 3

Dirt 3

2011
low 800x600
32  fps    + Compare
med. 1024x768
30  fps    + Compare
high 1360x768
19  fps    + Compare
ultra 1920x1080
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
31  fps    + Compare
med. 1024x768
26  fps    + Compare
high 1360x768
21  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metro 2033

Metro 2033

2010
low 800x600
26.1  fps    + Compare
med. 1360x768
12.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
31  fps    + Compare
med. 1366x768
18  fps    + Compare
high 1366x768
17  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Risen

Risen

2009
low 800x600
54.9  fps    + Compare
med. 1024x768
21.1  fps    + Compare
high 1366x768
14.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed Shift

Need for Speed Shift

2009
med. 1024x768
22.5  fps    + Compare
high 1366x768
15.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
51.4  fps    + Compare
med. 1024x768
33.3  fps    + Compare
high 1360x768
14.4  fps    + Compare
» With all tested laptops playable in detail settings low.
lowmed.highultraQHD4K
Anno 207045.719.713.7
Fifa 12162.666.139.1
Dirt 33230198
Call of Duty: Black Ops312621
Metro 203326.112.2
Battlefield: Bad Company 2311817
Risen54.921.114.4
Need for Speed Shift22.515.1
Colin McRae: DIRT 251.433.314.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
6

1		6
2
1
7
1

1








For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 09. 20:02:50

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.03s ... 0.031s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.031s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.031s

#7 composed specs +0s ... 0.031s

#8 did output specs +0s ... 0.032s

#9 start showIntegratedCPUs +0s ... 0.032s

#10 getting avg benchmarks for device 2099 +0.012s ... 0.043s

#11 got single benchmarks 2099 +0.015s ... 0.058s

#12 got avg benchmarks for devices +0s ... 0.058s

#13 min, max, avg, median took s +0.323s ... 0.381s

#14 before gaming benchmark output +0s ... 0.381s

#15 Got 26 rows for game benchmarks. +0.002s ... 0.384s

#16 composed SQL query for gamebenchmarks +0s ... 0.384s

#17 got data and put it in $dataArray +0.004s ... 0.388s

#18 benchmarks composed for output. +0.232s ... 0.62s

#19 no comparison url found in template nbc.compare_page_1 needed +0.002s ... 0.623s

#20 return log +0s ... 0.623s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
M4 20-core GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon HD 6450M

* Approximate position of the graphics adapter
