AMD Radeon HD 6480G + HD 7450M Dual Graphics

AMD Radeon HD 6480G + HD 7450M Dual Graphics

AMD的Radeon HD 6480G+ HD7450M双显卡是一个非对称的Radeon HD 6480G处理器的图形卡（Llano的APU）和一个专用的Radeon HD7450M交火组合。前身为Radeon HD6510G2的（与Radeon HD6450M都基于同一个芯片上，而不是7450M）的组合。交火模式只适用于DX10和DX11的游戏，有时甚至会降低性能。在我们的测试中的表现相结合为从英特尔HD Graphics 3000到Radeon HD 6490M独立。 Hovever，组合也患有从微口吃。

AMD Radeon HD 7400M Series

Radeon HD 6620G + HD 7670M Dual Graphics 880 @ 0.4 GHz? Bit @ 1800 MHz
Radeon HD 6620G + HD 7450M Dual Graphics 560 @ 0.4 GHz? Bit @ 1800 MHz
Radeon HD 6520G + HD 7450M Dual Graphics 480 @ 0.4 GHz64 Bit @ 1800 MHz
Radeon HD 6480G + HD 7450M Dual Graphics 400 @ 0.59 GHz64 Bit @ - / 1800 MHz
ArchitectureTerascale 2
Pipelines400 - unified
Core Speed593 / 700 MHz
Memory Speed- / 1800 MHz
Memory Bus Width64 Bit
Shared Memoryyes
APIDirectX 11, Shader 5.0
technology40 nm
Date of Announcement08.02.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
996 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
977 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -82%
...
NVIDIA GeForce GT 540M
892 -9%
AMD Radeon R5 (Kaveri)
901 -8%
NVIDIA GeForce GT 625M
921 -6%
Intel UHD Graphics 610
923 -6%
NVIDIA GeForce GT 620M
924 -5%
Intel HD Graphics 4600
926 -5%
NVIDIA Quadro 1000M
943 -3%
AMD Radeon HD 7650M
944 -3%
AMD Radeon HD 7620G
948 -3%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
977
Intel HD Graphics 5500
979 0%
NVIDIA GeForce GT 550M
982 1%
NVIDIA NVS 5200M
990 1%
AMD Radeon HD 6540G2
990 1%
AMD Radeon HD 6550M
993 2%
Intel HD Graphics 5000
993 2%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
1013 4%
Intel HD Graphics 515
1013 4%
AMD Radeon HD 6510G2
1015 4%
...
AMD Radeon RX 7900M
59943 6035%
max:
NVIDIA GeForce RTX 4090
104201 10565%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
2899 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
2865 Points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -98%
...
ATI Mobility Radeon HD 4670
2552 -11%
AMD Radeon HD 6755G2
2593 -9%
NVIDIA GeForce GT 335M
2624 -8%
AMD Radeon R5 (Kaveri)
2674 -7%
ATI Mobility Radeon HD 5650
2711 -5%
AMD Radeon HD 6540G2
2731 -5%
AMD Radeon HD 6680G2
2800 -2%
NVIDIA Quadro FX 1800M
2801 -2%
NVIDIA GeForce GT 425M
2803 -2%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
2865
Intel HD Graphics 5300
2914 2%
NVIDIA GeForce GT 525M
2927 2%
NVIDIA GeForce 9800M GS
2955 3%
Intel UHD Graphics (Jasper Lake 16 EU)
2969 4%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
2974 4%
Intel HD Graphics 4400
3005 5%
AMD Radeon R5 (Stoney Ridge)
3044 6%
AMD Radeon HD 7500G + HD 7550M Dual Graphics
3055 7%
AMD Radeon HD 7610M
3061 7%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 4523%
max:
AMD Radeon RX 7900 XTX
170928 5866%
0%
100%
3DMark 03 - 3DMark 03 - Standard
11037 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
7024 Points (8%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
NVIDIA GeForce 310M
6662 -5%
NVIDIA Quadro FX 1500M
6666 -5%
NVIDIA GeForce 9500M GS
6669 -5%
NVIDIA GeForce G210M
6720 -4%
ATI Mobility Radeon HD 2700
6729 -4%
ATI Mobility Radeon HD 4570
6755 -4%
AMD Radeon R2 (Stoney Ridge)
6853 -2%
NVIDIA NVS 3100M
6928 -1%
ATI Mobility Radeon HD 4550
6991 0%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
7024
NVIDIA GeForce 315M
7077 1%
NVIDIA Quadro FX 380M
7095 1%
ATI Mobility Radeon X1900
7117 1%
NVIDIA GeForce 320M
7168 2%
AMD Radeon HD 6450M
7236 3%
AMD Radeon HD 6520G
7273 4%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
7282 4%
ATI Mobility Radeon HD 540v
7333 4%
AMD Radeon HD 6620G
7365 5%
...
AMD Radeon RX 7600M XT
68064 869%
max:
NVIDIA GeForce RTX 4080 Super
87172 1141%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
3648 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
11.4 fps (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -95%
...
AMD Radeon HD 8650G
10.7 -6%
AMD Radeon R5 (Stoney Ridge)
10.8 -5%
AMD Radeon HD 6680G2
10.8 -5%
Intel HD Graphics 4400
10.87 -5%
Intel HD Graphics (Broadwell)
10.9 -4%
AMD Radeon HD 6550M
11.1 -3%
NVIDIA GeForce GT 425M
11.13 -2%
AMD Radeon R5 (Kaveri)
11.3 -1%
AMD Radeon HD 7650M
11.4 0%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
11.4
NVIDIA GeForce GT 525M
11.53 1%
AMD Radeon HD 6650M
11.9 4%
AMD Radeon HD 7660G + HD 7670M Dual Graphics
11.9 4%
AMD Radeon HD 7670M
12.06 6%
AMD Radeon HD 7570M
12.07 6%
AMD Radeon HD 7660G
12.3 8%
AMD Radeon HD 6730M
12.6 11%
AMD Radeon HD 8670M
12.7 11%
Intel HD Graphics 5000
12.97 14%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 4567%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
5.9 Points (75%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
4.6 Points (58%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
3868 points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
17.4 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Star Wars: The Old Republic

Star Wars: The Old Republic

2011
low 1024x768
23.2  fps    + Compare
high 1366x768
10.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
68.9  fps    + Compare
med. 1366x768
16.5  fps    + Compare
high 1366x768
10.8  fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
27.9  fps    + Compare
med. 1366x768
17.3  fps    + Compare
high 1366x768
12.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield 3

Battlefield 3

2011
low 1024x768
16.8  fps    + Compare
med. 1366x768
14.6  fps    + Compare
high 1366x768
13.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
88.5  fps    + Compare
med. 1024x768
47.6  fps    + Compare
high 1360x768
34.2  fps    + Compare
» With all tested laptops playable in detail settings med..
F1 2011

F1 2011

2011
low 800x600
35  fps    + Compare
med. 1024x768
24  fps    + Compare
high 1366x768
17  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
49.7  fps    + Compare
high 1366x768
29  fps    + Compare
» With all tested laptops playable in detail settings low.
Dirt 3

Dirt 3

2011
low 800x600
41.1  fps    + Compare
med. 1024x768
28.2  fps    + Compare
high 1360x768
26.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis 2

Crysis 2

2011
low 800x600
24.9  fps    + Compare
med. 1024x768
16.9  fps    + Compare
high 1366x768
12.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mafia 2

Mafia 2

2010
low 800x600
26.1  fps    + Compare
med. 1024x768
21.6  fps    + Compare
high 1360x768
18.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
90.9  fps    + Compare
med. 1360x768
24.1  fps    + Compare
high 1360x768
14.6  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
29.2  fps    + Compare
med. 1360x768
24.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
lowmed.highultraQHD4K
Star Wars: The Old Republic23.210.7
Anno 207068.916.510.8
The Elder Scrolls V: Skyrim27.917.312.4
Battlefield 316.814.613.3
Fifa 1288.547.634.2
F1 2011352417
Deus Ex Human Revolution49.729
Dirt 341.128.226.4
Crysis 224.916.912.5
Mafia 226.121.618.6
StarCraft 290.924.114.6
Metro 203329.224.6
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		6
3
3
9
1

10
1










For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 10. 10:17:38

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Sun, 10 Nov 2024 05:29:51 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.032s ... 0.034s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.034s

#7 composed specs +0s ... 0.034s

#8 did output specs +0s ... 0.034s

#9 start showIntegratedCPUs +0s ... 0.034s

#10 getting avg benchmarks for device 2885 +0.013s ... 0.047s

#11 got single benchmarks 2885 +0.006s ... 0.053s

#12 got avg benchmarks for devices +0s ... 0.053s

#13 min, max, avg, median took s +0.219s ... 0.272s

#14 before gaming benchmark output +0s ... 0.272s

#15 Got 33 rows for game benchmarks. +0.003s ... 0.275s

#16 composed SQL query for gamebenchmarks +0s ... 0.275s

#17 got data and put it in $dataArray +0.006s ... 0.282s

#18 benchmarks composed for output. +0.278s ... 0.56s

#19 no comparison url found in template nbc.compare_page_1 needed +0.002s ... 0.562s

#20 return log +0s ... 0.562s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
M4 20-core GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
Radeon HD 6480G + HD 7450M Dual Graphics *
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

* Approximate position of the graphics adapter

> Notebookcheck中文版（NBC中国） > FAQ / 小提示/ 技术参数 > 移动显示芯片——基准测试成绩列表 > AMD Radeon HD 6480G + HD 7450M Dual Graphics
Klaus Hinum (Update: 2016-01-26)
