AMD Radeon HD 6520G + HD 7450M Dual Graphics

AMD Radeon HD 6520G + HD 7450M Dual Graphics

AMD的Radeon HD 6520G+ HD7450M双显卡是一个非对称的Radeon HD 6520G处理器的图形卡(Llano的APU)和一个专用的Radeon HD7450M交火组合。前身为Radeon HD6540G2的(与Radeon HD6450M都基于同一个芯片上,而不是7450M)的组合。交火模式只适用于DX10和DX11的游戏,有时甚至会降低性能。在我们的测试中的表现相结合为从英特尔HD Graphics 3000到Radeon HD 6630M独立。此外,该组合还患有从微口吃。

AMD Radeon HD 7400M Series

Radeon HD 6620G + HD 7670M Dual Graphics 880 @ 0.4 GHz? Bit @ 1800 MHz
Radeon HD 6620G + HD 7450M Dual Graphics 560 @ 0.4 GHz? Bit @ 1800 MHz
Radeon HD 6520G + HD 7450M Dual Graphics 480 @ 0.4 GHz64 Bit @ 1800 MHz
Radeon HD 6480G + HD 7450M Dual Graphics 400 @ 0.59 GHz64 Bit @ - / 1800 MHz
ArchitectureTerascale 2
Pipelines480 - unified
Core Speed400 / 700 MHz
Memory Speed1800 MHz
Memory Bus Width64 Bit
Shared Memoryyes
APIDirectX 11, Shader 5.0
technology40 nm
Date of Announcement08.02.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 1008     avg: 1060     median: 1040 (1%)     max: 1133 Points
3DMark 11 - 3DM11 Performance GPU
min: 952     avg: 1013     median: 1006 (1%)     max: 1081 Points
171.8 -83%
...
944 -7%
948 -6%
977 -4%
979 -3%
982 -3%
990 -2%
990 -2%
Intel HD Graphics 5000
993 -2%
993 -2%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
1013
1015 0%
1039 3%
1057 4%
1061 5%
AMD Radeon HD 6570M
1067 5%
1079 7%
1102 9%
1106 9%
1107 9%
...
59943 5817%
max:
104201 10186%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 2895     avg: 3326     median: 3384 (1%)     max: 3700 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 2553     avg: 2974     median: 3023 (2%)     max: 3346 Points
ATI Radeon HD 3200
62 -98%
...
2731 -8%
2800 -6%
2801 -6%
2803 -6%
2865 -4%
2914 -2%
2927 -2%
NVIDIA GeForce 9800M GS
2955 -1%
2969 0%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
2974
Intel HD Graphics 4400
3005 1%
3044 2%
3055 3%
3061 3%
3079 4%
3103 4%
3112 5%
Intel HD Graphics 510
3125 5%
NVIDIA GeForce GTS 250M
3128 5%
...
132443 4353%
max:
170928 5647%
0%
100%
3DMark 2001SE - 3DMark 2001 - Standard
13445 Points (14%)
3DMark 03 - 3DMark 03 - Standard
min: 9654     avg: 11956     median: 11956 (6%)     max: 14258 Points
3DMark 05 - 3DMark 05 - Standard
min: 6190     avg: 7282     median: 7282 (8%)     max: 8374 Points
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
6928 -5%
6991 -4%
7024 -4%
7077 -3%
7095 -3%
ATI Mobility Radeon X1900
7117 -2%
7168 -2%
7236 -1%
7273 0%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
7282
7333 1%
7365 1%
7483 3%
7493 3%
ATI Mobility Radeon X1800XT
7539 4%
ATI Mobility Radeon HD 3650
7539 4%
7600 4%
7605 4%
7732 6%
...
68064 835%
max:
87172 1097%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 3314     avg: 4317     median: 4786 (6%)     max: 4851 Points
Unigine Heaven 2.1 - Heaven 2.1 high
min: 4.7     avg: 8.9     median: 10.2 (2%)     max: 11.7 fps
0.6 -93%
...
7.4 -17%
7.45 -16%
7.617 -14%
7.675 -13%
7.7 -13%
AMD Radeon R2 (Stoney Ridge)
7.8 -12%
8.1 -9%
AMD Radeon R4 (Stoney Ridge)
8.35 -6%
8.7 -2%
AMD Radeon HD 6520G + HD 7450M Dual Graphics
8.867
8.9 0%
Intel UHD Graphics 605
9 1%
9 1%
9.1 3%
9.3 5%
9.585 8%
9.7 9%
AMD Radeon HD 8550G
9.8 11%
9.9 12%
...
532 5900%
0%
100%
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
4.4 fps (3%)
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
2.6 fps (1%)
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
10 fps (8%)
specvp11 proe-05 +
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
5.6 fps (4%)
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
13.1 fps (14%)
specvp11 ensight-04 +
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
2.5 fps (1%)
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.1     avg: 6.4     median: 6.5 (82%)     max: 6.5 Points
Windows 7 Experience Index - Win7 Graphics
min: 4.5     avg: 5.4     median: 5.9 (75%)     max: 5.9 Points
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 3146     avg: 3503     median: 3645 (3%)     max: 3719 points
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 13.78     avg: 18.4     median: 20.5 (7%)     max: 20.88 fps
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Star Wars: The Old Republic

Star Wars: The Old Republic

2011
low 1024x768
28.2  fps    + Compare
high 1366x768
12.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
76.9 84 ~ 80 fps    + Compare
med. 1366x768
17.6 38 ~ 28 fps    + Compare
high 1366x768
11.5 14 ~ 13 fps    + Compare
» With all tested laptops playable in detail settings low.
low 1280x720
29.1 32 ~ 31 fps    + Compare
med. 1366x768
20  fps    + Compare
high 1366x768
13.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
22  fps    + Compare
med. 1366x768
23.4  fps    + Compare
high 1366x768
17.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
126.1  fps    + Compare
med. 1024x768
67.7  fps    + Compare
high 1360x768
51  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2011

F1 2011

2011
low 800x600
49  fps    + Compare
med. 1024x768
30  fps    + Compare
high 1366x768
23  fps    + Compare
» With all tested laptops playable in detail settings low.
low 1024x768
30 60.9 61 ~ 51 fps    + Compare
high 1366x768
26 30.4 38 ~ 31 fps    + Compare
» With most tested laptops playable in detail settings low.
Dirt 3

Dirt 3

2011
low 800x600
49 74.9 ~ 62 fps    + Compare
med. 1024x768
37 45.4 ~ 41 fps    + Compare
high 1360x768
24 36.9 ~ 30 fps    + Compare
» With all tested laptops playable in detail settings med..
Crysis 2

Crysis 2

2011
low 800x600
30  fps    + Compare
med. 1024x768
20.2  fps    + Compare
high 1366x768
14.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 800x600
50.6  fps    + Compare
med. 1024x768
36.3  fps    + Compare
high 1360x768
30.2  fps    + Compare
» With all tested laptops playable in detail settings med..
Mafia 2

Mafia 2

2010
low 800x600
31  fps    + Compare
med. 1024x768
25.8  fps    + Compare
high 1360x768
22.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
low 1024x768
79 89 94.9 ~ 88 fps    + Compare
med. 1360x768
19 28.2 33 ~ 27 fps    + Compare
high 1360x768
12 19.5 ~ 16 fps    + Compare
» With all tested laptops playable in detail settings low.
low 800x600
35.2  fps    + Compare
med. 1360x768
25.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Anno 1404

Anno 1404

2009
low 1024x768
59  fps    + Compare
ultra 1280x1024
43  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Sims 3

Sims 3

2009
low 800x600
223  fps    + Compare
med. 1024x768
71  fps    + Compare
» With all tested laptops playable in detail settings med..
Racedriver: GRID

Racedriver: GRID

2008
low 800x600
75  fps    + Compare
med. 1024x768
43  fps    + Compare
high 1280x1024
27  fps    + Compare
» With all tested laptops playable in detail settings med..
The Elder Scrolls IV - Oblivion

The Elder Scrolls IV - Oblivion

2006
high 1280x800
47  fps    + Compare
» With all tested laptops playable in detail settings high.
World of Warcraft

World of Warcraft

2005
low 800x600
81  fps    + Compare
med. 1024x768
59  fps    + Compare
high 1280x1024
28  fps    + Compare
» With all tested laptops playable in detail settings med..
lowmed.highultraQHD4K
Star Wars: The Old Republic28.212.3
Anno 2070802813
The Elder Scrolls V: Skyrim312013.1
Battlefield 32223.417.1
Fifa 12126.167.751
F1 2011493023
Deus Ex Human Revolution5131
Dirt 3624130
Crysis 23020.214.9
Call of Duty: Black Ops50.636.330.2
Mafia 23125.822.5
StarCraft 2882716
Metro 203335.225.9
Anno 14045943
Sims 322371
Racedriver: GRID754327
The Elder Scrolls IV - Oblivion47
World of Warcraft815928
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
2
8
5
2
7
5
2
10
5


1







For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 09. 12:37:25

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.032s ... 0.033s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.033s

#7 composed specs +0s ... 0.033s

#8 did output specs +0s ... 0.033s

#9 start showIntegratedCPUs +0s ... 0.033s

#10 getting avg benchmarks for device 2873 +0.012s ... 0.046s

#11 got single benchmarks 2873 +0.009s ... 0.055s

#12 got avg benchmarks for devices +0s ... 0.055s

#13 min, max, avg, median took s +0.325s ... 0.38s

#14 before gaming benchmark output +0s ... 0.38s

#15 Got 63 rows for game benchmarks. +0.006s ... 0.386s

#16 composed SQL query for gamebenchmarks +0s ... 0.386s

#17 got data and put it in $dataArray +0.009s ... 0.395s

#18 benchmarks composed for output. +0.376s ... 0.771s

#19 no comparison url found in template nbc.compare_page_1 needed +0.002s ... 0.773s

#20 return log +0s ... 0.773s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

M4 20-core GPU
GeForce RTX 2080 Super Mobile

Class 2

M1 Max 32-Core GPU *
GeForce RTX 2070 Super Mobile
M1 Max 24-Core GPU *
Quadro RTX 5000 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
Quadro P5200
Quadro RTX 3000 Max-Q *
Quadro P4200
Quadro P5000 Max-Q *
GeForce GTX 980 (Laptop)
Quadro P4000
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000 Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
Quadro T1000 Max-Q *

Class 3

Vega M GH
Quadro M5000M
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
T500 Laptop GPU *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 660M
Radeon Pro WX 4150 *
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
GeForce GTX 960M
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
GeForce 945M
Quadro P500 *
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics 580
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
UHD Graphics 730
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
Quadro M600M
FirePro W4190M
Radeon R9 M375
Radeon R7 M445
Iris Plus Graphics 650
Iris Graphics 550
Radeon 625
Vega 6 *
Iris Plus Graphics 640
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 M360
GeForce 920M
Radeon 620
Radeon R7 M340
Radeon 610
Radeon 610M *
Vega 6 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
GeForce 910M
HD Graphics 520

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
UHD Graphics 617
UHD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 510
UHD Graphics 605
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics (Braswell)

* Approximate position of the graphics adapter

> Notebookcheck中文版(NBC中国) > FAQ / 小提示/ 技术参数 > 移动显示芯片——基准测试成绩列表 > AMD Radeon HD 6520G + HD 7450M Dual Graphics
Klaus Hinum (Update: 2016-01-26)
