AMD Radeon HD 6730M

AMD Radeon HD 6730M

AMD Radeon HD 6730M（有时也被称为了ATI Mobility Radeon HD 6730或类似）是一种快速的中产阶层的图形卡的笔记本电脑。它支持DirectX11的，是继承了HD 5730，并具有更高的时钟频率，80个着色器，Eyefinity技术+和新的UVD3视频解码器。然而，它仍然是在40nm和基于哨类相同的芯片作为整个6700M和6600M系列。第一信息也表明，HD 6770M 6730M是一个缓慢的DDR3内存。 480个流处理器，仍然要基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。 3D效能应该是有点老的Radeon HD 5730以上由于数额较大的着色器。因此，当前和要求苛刻的游戏运行流利的1366×768和中高细节。应该运行在高细节和分辨率要求不高的游戏，如模拟人生3或FIFA 11。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD 6700M系列集成了HD音频控制器，通过HDMI和DisplayPort（如蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片则是能够从理论上同时驱动多达5个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。的Mobility Radeon HD 5730应该是相似的，因此适用于15“笔记本电脑和功耗的芯片。

Radeon HD 6600M/6700M Series

Radeon HD 6770M 480 @ 0.68 GHz128 Bit @ 800 MHz
Radeon HD 6750M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6730M 480 @ 0.73 GHz128 Bit @ 800 MHz
Radeon HD 6650M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6630M 480 @ 0.49 GHz128 Bit @ 800 MHz
CodenameWhistler-XT
ArchitectureTerascale 2
Pipelines480 - unified
Core Speed725 MHz
Memory Speed800 MHz
Memory Bus Width128 Bit
Memory TypeDDR3
Shared Memoryno
APIDirectX 11, Shader 5.0
technology40 nm
Notebook Sizemedium sized
Date of Announcement04.01.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
1269 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
1141 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -85%
...
AMD Radeon HD 7660G
1057 -7%
AMD Radeon HD 6680G2
1061 -7%
AMD Radeon HD 6570M
1067 -6%
AMD Radeon HD 7670M
1079 -5%
NVIDIA Quadro K1000M
1102 -3%
AMD Radeon HD 6650M
1106 -3%
NVIDIA GeForce 710M
1107 -3%
Intel Iris Graphics 5100
1112 -3%
NVIDIA NVS 5400M
1119 -2%
AMD Radeon HD 6730M
1141
NVIDIA GeForce GT 720M
1143 0%
NVIDIA Quadro K610M
1144 0%
AMD Radeon HD 6750M
1147 1%
NVIDIA GeForce GT 445M
1148 1%
NVIDIA GeForce GT 635M
1152 1%
AMD Radeon R6 (Kaveri)
1161 2%
Intel UHD Graphics 615
1175 3%
AMD Radeon HD 8550G
1179 3%
NVIDIA GeForce GT 555M
1179 3%
...
AMD Radeon RX 7900M
59943 5154%
max:
NVIDIA GeForce RTX 4090
104201 9032%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
4438 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
3752 Points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -98%
...
NVIDIA GeForce GT 620M
3610 -4%
Intel HD Graphics 5000
3639 -3%
AMD Radeon HD 8670M
3647 -3%
AMD Radeon R6 (Kaveri)
3677 -2%
NVIDIA Quadro 1000M
3679 -2%
NVIDIA GeForce 9800M GTS
3700 -1%
NVIDIA GeForce 9800M GT
3725 -1%
AMD Radeon HD 8550G
3741 0%
AMD Radeon HD 8570M
3750 0%
AMD Radeon HD 6730M
3752
Intel HD Graphics 5500
3804 1%
AMD Radeon HD 8550M
3858 3%
Intel HD Graphics 4600
3860 3%
NVIDIA GeForce GT 550M
3866 3%
NVIDIA GeForce GT 720M
3868 3%
AMD Radeon HD 7650M
3881 3%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
3968 6%
NVIDIA GeForce 710M
3969 6%
AMD Radeon R5 M430
3995 6%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 3430%
max:
AMD Radeon RX 7900 XTX
170928 4456%
0%
100%
3DMark 03 - 3DMark 03 - Standard
23075 Points (12%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
15492 Points (17%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
NVIDIA GeForce 8800M GTX
14952 -3%
AMD Radeon HD 6750M
15011 -3%
Intel HD Graphics 4600
15058 -3%
NVIDIA NVS 5200M
15064 -3%
NVIDIA Quadro FX 1800M
15249 -2%
NVIDIA GeForce GT 540M
15284 -1%
ATI Mobility Radeon HD 5850
15365 -1%
ATI Mobility Radeon HD 4850
15419 0%
AMD Radeon HD 6770M
15484 0%
AMD Radeon HD 6730M
15492
AMD Radeon R7 M340
15629 1%
NVIDIA Quadro FX 3700M
15759 2%
AMD Radeon RX Vega 3
15885 3%
NVIDIA Quadro K2000M
16020 3%
NVIDIA GeForce 9800M GTX SLI
16101 4%
NVIDIA GeForce GT 630M
16128 4%
NVIDIA GeForce GT 635M
16185 4%
ATI Mobility Radeon HD 4870
16349 6%
NVIDIA GeForce 9800M GTS
16430 6%
...
AMD Radeon RX 7600M XT
68064 339%
max:
NVIDIA GeForce RTX 4080 Super
87172 463%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
7918 Points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
12.6 fps (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -95%
...
AMD Radeon R5 (Kaveri)
11.3 -10%
AMD Radeon HD 6480G + HD 7450M Dual Graphics
11.4 -10%
AMD Radeon HD 7650M
11.4 -10%
NVIDIA GeForce GT 525M
11.53 -8%
AMD Radeon HD 6650M
11.9 -6%
AMD Radeon HD 7660G + HD 7670M Dual Graphics
11.9 -6%
AMD Radeon HD 7670M
12.06 -4%
AMD Radeon HD 7570M
12.07 -4%
AMD Radeon HD 7660G
12.3 -2%
AMD Radeon HD 6730M
12.6
AMD Radeon HD 8670M
12.7 1%
Intel HD Graphics 5000
12.97 3%
NVIDIA GeForce GT 540M
13.48 7%
Intel HD Graphics 510
13.5 7%
NVIDIA NVS 5200M
13.65 8%
AMD Radeon R5 M330
13.7 9%
NVIDIA Quadro K610M
13.8 10%
Intel HD Graphics 610
14 11%
NVIDIA GeForce GT 635M
14.07 12%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 4122%
0%
100%
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
6.8 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
5 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
18.7 fps (14%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 proe-05 +
SPECviewperf 11 - specvp11 proe-05
2.2 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
10.7 fps (8%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
24.3 fps (26%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 ensight-04 +
SPECviewperf 11 - specvp11 ensight-04
13.2 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
6.2 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
6.8 Points (86%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
6.8 Points (86%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
7282 points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
37 fps (12%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Dirt 3

Dirt 3

2011
low 800x600
134.8  fps    + Compare + 📈 Graph
med. 1024x768
62.9  fps    + Compare + 📈 Graph
high 1360x768
41.6  fps    + Compare + 📈 Graph
ultra 1920x1080
15.7  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings high.
Crysis 2

Crysis 2

2011
low 800x600
56.3  fps    + Compare + 📈 Graph
med. 1024x768
38.6  fps    + Compare + 📈 Graph
high 1366x768
28  fps    + Compare + 📈 Graph
ultra 1920x1080
11.6  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings med..
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
110.3  fps    + Compare + 📈 Graph
med. 1024x768
69.9  fps    + Compare + 📈 Graph
high 1360x768
48.3  fps    + Compare + 📈 Graph
ultra 1920x1080
25.7  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings high.
Fifa 11

Fifa 11

2010
low 800x600
345.4  fps    + Compare
med. 1024x768
245.1  fps    + Compare
high 1360x768
111  fps    + Compare
ultra 1920x1080
57.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Mafia 2

Mafia 2

2010
low 800x600
69.1  fps    + Compare
med. 1024x768
55.1  fps    + Compare
high 1360x768
46.3  fps    + Compare
ultra 1920x1080
28.1  fps    + Compare
» With all tested laptops playable in detail settings high.
StarCraft 2

StarCraft 2

2010
low 1024x768
228.4  fps    + Compare + 📈 Graph
med. 1360x768
46.4  fps    + Compare + 📈 Graph
high 1360x768
28.6  fps    + Compare + 📈 Graph
ultra 1920x1080
18.2  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings med..
Metro 2033

Metro 2033

2010
low 800x600
66  fps    + Compare
med. 1360x768
31.7  fps    + Compare
high 1600x900
17  fps    + Compare
ultra 1920x1080
5.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
67  fps    + Compare + 📈 Graph
med. 1366x768
51.1  fps    + Compare + 📈 Graph
high 1366x768
35  fps    + Compare + 📈 Graph
ultra 1920x1080
17.1  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings med..
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
low 800x600
137.2  fps    + Compare
med. 1024x768
51.2  fps    + Compare
high 1366x768
41.3  fps    + Compare
ultra 1920x1080
27  fps    + Compare
» With all tested laptops playable in detail settings high.
Risen

Risen

2009
low 800x600
75.5  fps    + Compare
med. 1024x768
43.9  fps    + Compare
high 1366x768
30.7  fps    + Compare
ultra 1920x1080
21.4  fps    + Compare
» With all tested laptops playable in detail settings med..
Resident Evil 5

Resident Evil 5

2009
low 800x600
119.9  fps    + Compare
high 1360x768
54.1  fps    + Compare
ultra 1920x1080
29.8  fps    + Compare
» With all tested laptops playable in detail settings high.
Need for Speed Shift

Need for Speed Shift

2009
med. 1024x768
54  fps    + Compare
high 1366x768
35.7  fps    + Compare
ultra 1920x1080
22.1  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Dirt 3134.862.941.615.7
Crysis 256.338.62811.6
Call of Duty: Black Ops110.369.948.325.7
Fifa 11345.4245.111157.3
Mafia 269.155.146.328.1
StarCraft 2228.446.428.618.2
Metro 20336631.7175.7
Battlefield: Bad Company 26751.13517.1
CoD Modern Warfare 2137.251.241.327
Risen75.543.930.721.4
Resident Evil 5119.954.129.8
Need for Speed Shift5435.722.1
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
1
6
4
8
2
1		3
8
1
11
1







For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 09. 03:35:59

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.002s ... 0.002s

#4 no comparison url found in template nbc.compare_page_1 needed +0.201s ... 0.202s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.203s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.203s

#7 no comparison url found in template nbc.compare_page_1 needed +0.001s ... 0.204s

#8 composed specs +0s ... 0.204s

#9 did output specs +0s ... 0.204s

#10 start showIntegratedCPUs +0s ... 0.204s

#11 getting avg benchmarks for device 2090 +0.022s ... 0.226s

#12 got single benchmarks 2090 +0.037s ... 0.263s

#13 got avg benchmarks for devices +0s ... 0.263s

#14 min, max, avg, median took s +1.802s ... 2.065s

#15 before gaming benchmark output +0s ... 2.065s

#16 Got 46 rows for game benchmarks. +0.597s ... 2.662s

#17 composed SQL query for gamebenchmarks +0s ... 2.662s

#18 got data and put it in $dataArray +0.014s ... 2.676s

#19 benchmarks composed for output. +4.756s ... 7.432s

#20 no comparison url found in template nbc.compare_page_1 needed +0.004s ... 7.436s

#21 return log +0s ... 7.436s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

M4 20-core GPU
Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon HD 6730M *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

* Approximate position of the graphics adapter
