AMD Radeon HD 6750M

AMD Radeon HD 6750M

在AMD的Radeon HD 6750M（也被称为ATI移动的Radeon HD 6750是一个快速中产阶级的图形卡的笔记本电脑，它支持DirectX11的，是的即时继任者的HD 5750M和提供更高的时钟频率，80多着色器的Eyefinity +和的新的UVD3视频解码器，但它仍然是在40nm工艺生产，是基于在同一哨类核心为6700M和6600M系列。第一个细节也表明，HD 6750M是一个6650M的GDDR5显存，480个流处理器仍然是基于因此，着色器的数量是目前NVIDIA GPU（图形处理器）的1D核心没有直接的可比性，应提高（如桌面6800系列），比上年的Radeon代Tessellation（曲面细分）性能对“老”5D类似于5000系列的架构。新的6700M卡的流处理器可以借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。后两个特点使流处理器被用于更一般的计算视频转码等。3D效能的6750M到旧的Radeon HD 5770M由于大量的着色器应该是相似的，因此，当前和要求苛刻的游戏运行流利的1366×768和中高细节要求不高的游戏，如模拟人生3或国际足联11日，应很好地运行于高细节和解决方案。UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX， XVID）高清视频的显卡。此外，HD 6700M系列集成了一个HD音频控制器，传输高清音频（TrueHD或DTS Master音频）通过HDMI和DisplayPort（例如，蓝光视频）AMD HD3D技术提供支持。蓝光3D和3D显示器都集成和外部的解决方案是不作为成熟的Nvidia的3D视觉。感谢到Eyefinity技术，在AMD的图形芯片是能够以理论上驱动高达5个显示器同时。然而，这如果笔记本电脑工作提供足够的DisplayPort输出。6750M芯片的功耗的Mobility Radeon HD 5770应该是相似的，因此适用于15“或更大的笔记本电脑。

Radeon HD 6600M/6700M Series

Radeon HD 6770M 480 @ 0.68 GHz128 Bit @ 800 MHz
Radeon HD 6750M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6730M 480 @ 0.73 GHz128 Bit @ 800 MHz
Radeon HD 6650M 480 @ 0.6 GHz128 Bit @ 900 MHz
Radeon HD 6630M 480 @ 0.49 GHz128 Bit @ 800 MHz
CodenameWhistler-PRO
ArchitectureTerascale 2
Pipelines480 - unified
Core Speed600 MHz
Memory Speed900 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Shared Memoryno
APIDirectX 11, Shader 5.0
technology40 nm
Notebook Sizemedium sized
Date of Announcement04.01.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 1208     avg: 1285     median: 1305.5 (2%)     max: 1319 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 1103     avg: 1147     median: 1158.5 (1%)     max: 1169 Points
+ 4 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -85%
...
NVIDIA Quadro K1000M
1102 -4%
AMD Radeon HD 6650M
1106 -4%
NVIDIA GeForce 710M
1107 -3%
Intel Iris Graphics 5100
1112 -3%
NVIDIA NVS 5400M
1119 -2%
AMD Radeon HD 7690M
1141 -1%
AMD Radeon HD 6730M
1141 -1%
NVIDIA GeForce GT 720M
1143 0%
NVIDIA Quadro K610M
1144 0%
AMD Radeon HD 6750M
1147
NVIDIA GeForce GT 445M
1148 0%
NVIDIA GeForce GT 635M
1152 0%
AMD Radeon R6 (Kaveri)
1161 1%
Intel UHD Graphics 615
1175 2%
NVIDIA GeForce GT 555M
1179 3%
AMD Radeon HD 8550G
1179 3%
AMD Radeon R5 M230
1203 5%
Intel HD Graphics 615
1233 7%
AMD Radeon HD 8570M
1233 7%
...
AMD Radeon RX 7900M
59943 5126%
max:
NVIDIA GeForce RTX 4090
106023 9144%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 4667     avg: 5331     median: 5483 (2%)     max: 5575 Points
+ 5 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 4359     avg: 4545     median: 4512 (3%)     max: 4884 Points
+ 5 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -99%
...
AMD Radeon 520
4324 -5%
NVIDIA Quadro FX 3700M
4326 -5%
NVIDIA NVS 5400M
4407 -3%
AMD Radeon R6 (Carrizo)
4415 -3%
AMD Radeon R7 (Carrizo)
4420 -3%
NVIDIA GeForce GT 635M
4441 -2%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake)
4452 -2%
NVIDIA GeForce GTS 360M
4516 -1%
NVIDIA GeForce GT 640M LE
4528 0%
AMD Radeon HD 6750M
4545
Intel HD Graphics 520
4547 0%
NVIDIA GeForce GT 445M
4570 1%
AMD Radeon R7 M340
4606 1%
AMD Radeon R7 M460
4645 2%
AMD Radeon RX Vega 3
4739 4%
AMD Radeon R5 M240
4761 5%
AMD Radeon R7 M260
4787 5%
AMD Radeon R5 M255
4804 6%
AMD Radeon HD 7640G + HD 7670M Dual Graphics
4812 6%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 2814%
max:
AMD Radeon RX 7900 XTX
170928 3661%
0%
100%
3DMark 2001SE - 3DMark 2001 - Standard
43578 Points (45%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
min: 17884     avg: 21813     median: 21813 (11%)     max: 25742 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 9852     avg: 15011     median: 16335.5 (18%)     max: 17519 Points
+ 4 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
NVIDIA GeForce 920M
14564 -3%
NVIDIA GeForce GTS 250M
14733 -2%
NVIDIA GeForce GTX 260M
14773 -2%
NVIDIA GeForce GT 640M LE
14777 -2%
AMD Radeon HD 6570M
14855 -1%
NVIDIA GeForce 9800M GT
14869 -1%
AMD Radeon R7 M260
14924 -1%
ATI Mobility Radeon HD 4830
14938 0%
NVIDIA GeForce 8800M GTX
14952 0%
AMD Radeon HD 6750M
15011
Intel HD Graphics 4600
15058 0%
NVIDIA NVS 5200M
15064 0%
NVIDIA Quadro FX 1800M
15249 2%
NVIDIA GeForce GT 540M
15284 2%
ATI Mobility Radeon HD 5850
15365 2%
ATI Mobility Radeon HD 4850
15419 3%
AMD Radeon HD 6770M
15484 3%
AMD Radeon HD 6730M
15492 3%
AMD Radeon R7 M340
15629 4%
...
NVIDIA GeForce RTX 4090 Laptop GPU
61850 312%
max:
NVIDIA GeForce RTX 4080 Super
87172 481%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 7260     avg: 8843     median: 9361 (12%)     max: 9477 Points
+ 5 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
min: 14.1     avg: 15.2     median: 14.8 (3%)     max: 17.2 fps
+ 4 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -96%
...
NVIDIA Quadro K610M
13.8 -9%
Intel HD Graphics 610
14 -8%
NVIDIA GeForce GT 635M
14.07 -8%
AMD Radeon HD 8550M
14.1 -7%
NVIDIA GeForce GT 550M
14.45 -5%
AMD Radeon R7 (Carrizo)
14.7 -3%
AMD Radeon HD 6720G2
14.8 -3%
AMD Radeon HD 6850M
14.9 -2%
NVIDIA GeForce GT 720M
15.1 -1%
AMD Radeon HD 6750M
15.23
AMD Radeon R5 M335
15.3 0%
AMD Radeon R6 M340DX
15.3 0%
Intel HD Graphics 4600
15.3 0%
Intel UHD Graphics (Jasper Lake 32 EU)
15.4 1%
NVIDIA Quadro K1000M
15.4 1%
AMD Radeon HD 7690M
15.5 2%
Intel HD Graphics 5500
15.5 2%
AMD FirePro M4100
15.6 2%
AMD Radeon R5 M430
15.9 4%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 3393%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.6     avg: 6.8     median: 6.8 (85%)     max: 6.9 Points
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 4.2     avg: 5.6     median: 5.6 (70%)     max: 6.9 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 3585     avg: 6402     median: 7617 (5%)     max: 8004 points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 21.1     avg: 35.9     median: 43.2 (15%)     max: 43.44 fps
+ 3 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Battlefield 3

Battlefield 3

2011
low 1024x768
34.6  fps    + Compare + 📈 Graph
med. 1366x768
26.9  fps    + Compare + 📈 Graph
high 1366x768
20.7  fps    + Compare + 📈 Graph
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
194.5  fps    + Compare + 📈 Graph
med. 1024x768
120  fps    + Compare + 📈 Graph
high 1360x768
83.4  fps    + Compare + 📈 Graph
ultra 1920x1080
50.6  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings ultra.
F1 2011

F1 2011

2011
low 800x600
76  fps    + Compare + 📈 Graph
med. 1024x768
48  fps    + Compare + 📈 Graph
high 1366x768
29  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings med..
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
109.2  fps    + Compare + 📈 Graph
high 1366x768
39.3  fps    + Compare + 📈 Graph
ultra 1920x1080
17.4  fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings high.
Dirt 3

Dirt 3

2011
low 800x600
72.6  fps    + Compare
med. 1024x768
46.9  fps    + Compare
high 1360x768
40  fps    + Compare
ultra 1920x1080
14.3  fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis 2

Crysis 2

2011
low 800x600
73.3 79 ~ 76 fps    + Compare
med. 1024x768
50.2 53 ~ 52 fps    + Compare
high 1366x768
36.8 38 ~ 37 fps    + Compare
ultra 1920x1080
12 12.8 ~ 12 fps    + Compare
» With all tested laptops playable in detail settings high.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
med. 1024x768
76  fps    + Compare + 📈 Graph
high 1360x768
57  fps    + Compare
ultra 1920x1080
32 33 ~ 33 fps    + Compare + 📈 Graph
» With all tested laptops playable in detail settings high.
Fifa 11

Fifa 11

2010
low 800x600
458  fps    + Compare
med. 1024x768
275  fps    + Compare
high 1360x768
130  fps    + Compare
ultra 1920x1080
70 70 ~ 70 fps    + Compare
» With all tested laptops playable in detail settings ultra.
Mafia 2

Mafia 2

2010
low 800x600
42.7 54.8 65.7 ~ 54 fps    + Compare
med. 1024x768
37.7 45.8 53.8 ~ 46 fps    + Compare
high 1360x768
31 46.4 ~ 39 fps    + Compare
ultra 1920x1080
20.2 23.3 29.2 ~ 24 fps    + Compare
» With most tested laptops playable in detail settings high.
StarCraft 2

StarCraft 2

2010
low 1024x768
76.9 265 ~ 171 fps    + Compare
med. 1360x768
39  fps    + Compare
high 1360x768
33.9  fps    + Compare
ultra 1920x1080
21.2 24 ~ 23 fps    + Compare
» With all tested laptops playable in detail settings med..
Metro 2033

Metro 2033

2010
low 800x600
45.1  fps    + Compare
med. 1360x768
38.8 48 ~ 43 fps    + Compare
high 1600x900
20 22 ~ 21 fps    + Compare
ultra 1920x1080
10.2 12 ~ 11 fps    + Compare
» With all tested laptops playable in detail settings med..
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
63.7 74 80 ~ 73 fps    + Compare
med. 1366x768
47.6 62 ~ 55 fps    + Compare
high 1366x768
35.8 39 ~ 37 fps    + Compare
ultra 1920x1080
18.8 20 22 ~ 20 fps    + Compare
» With all tested laptops playable in detail settings high.
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
ultra 1920x1080
33  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Risen

Risen

2009
low 800x600
50.2 78 ~ 64 fps    + Compare
med. 1024x768
33.5 47 ~ 40 fps    + Compare
high 1366x768
23.7 32 ~ 28 fps    + Compare
ultra 1920x1080
13.5 22 23 ~ 20 fps    + Compare
» With most tested laptops playable in detail settings med..
Resident Evil 5

Resident Evil 5

2009
low 800x600
54.7 140.6 ~ 98 fps    + Compare
high 1360x768
42.5 60.6 ~ 52 fps    + Compare
ultra 1920x1080
32.7 35.2 35.3 ~ 34 fps    + Compare
» With all tested laptops playable in detail settings high.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
med. 1024x768
71.5  fps    + Compare
ultra 1920x1080
21.3  fps    + Compare
» With all tested laptops playable in detail settings med..
Sims 3

Sims 3

2009
high 1280x1024
51  fps    + Compare
» With all tested laptops playable in detail settings high.
F.E.A.R. 2

F.E.A.R. 2

2009
low 800x600
75.8  fps    + Compare
med. 1024x768
47.5  fps    + Compare
high 1280x1024
42.4  fps    + Compare
ultra 1920x1080
25  fps    + Compare
» With all tested laptops playable in detail settings high.
GTA IV - Grand Theft Auto

GTA IV - Grand Theft Auto

2008
low 800x600
50.1 65.1 ~ 58 fps    + Compare
med. 1024x768
30.9 62.4 ~ 47 fps    + Compare
high 1280x1024
23.8 32 ~ 28 fps    + Compare
» With most tested laptops playable in detail settings med..
Left 4 Dead

Left 4 Dead

2008
high 1024x768
143  fps    + Compare
» With all tested laptops playable in detail settings high.
Far Cry 2

Far Cry 2

2008
low 640x480
152  fps    + Compare
high 1024x768
57  fps    + Compare
ultra 1920x1080
25.5  fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis Warhead

Crysis Warhead

2008
low 800x600
105  fps    + Compare
ultra 1024x768
16.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Racedriver: GRID

Racedriver: GRID

2008
low 800x600
65.4  fps    + Compare
med. 1024x768
48.9  fps    + Compare
high 1280x1024
39.2  fps    + Compare
» With all tested laptops playable in detail settings high.
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
111  fps    + Compare
high 1024x768
35.2 80.5 ~ 58 fps    + Compare
ultra 1920x1080
18.5 33.1 ~ 26 fps    + Compare
» With all tested laptops playable in detail settings high.
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
low 1024x768
46.3  fps    + Compare
med. 1024x768
37  fps    + Compare
high 1024x768
29.1 34.1 ~ 32 fps    + Compare
ultra 1920x1080
15 25.3 ~ 20 fps    + Compare
» With all tested laptops playable in detail settings med..
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
77.2  fps    + Compare
med. 1024x768
58.9 75.8 ~ 67 fps    + Compare
high 1024x768
41.7 46.6 ~ 44 fps    + Compare
ultra 1920x1080
10.2 10.8 ~ 11 fps    + Compare
» With all tested laptops playable in detail settings high.
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
71.7  fps    + Compare
med. 1024x768
52.1  fps    + Compare
high 1024x768
33.7  fps    + Compare
ultra 1920x1080
9.5  fps    + Compare
» With all tested laptops playable in detail settings med..
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
89  fps    + Compare
med. 1024x768
37  fps    + Compare
high 1024x768
36 52 ~ 44 fps    + Compare
ultra 1920x1080
15 18 ~ 17 fps    + Compare
» With all tested laptops playable in detail settings high.
Call of Juarez Benchmark

Call of Juarez Benchmark

2006
high 1024x768
35.9  fps    + Compare
» With all tested laptops playable in detail settings high.
Half Life 2 - Lost Coast Benchmark

Half Life 2 - Lost Coast Benchmark

2005
high 1024x768
92.4  fps    + Compare
» With all tested laptops playable in detail settings high.
World of Warcraft

World of Warcraft

2005
low 800x600
94.1  fps    + Compare
med. 1024x768
63.8  fps    + Compare
high 1280x1024
34.6 35 ~ 35 fps    + Compare
» With all tested laptops playable in detail settings med..
Doom 3

Doom 3

2004
ultra 1024x768
201.4  fps    + Compare
» With all tested laptops playable in detail settings ultra.
lowmed.highultraQHD4K
Battlefield 334.626.920.7
Fifa 12194.512083.450.6
F1 2011764829
Deus Ex Human Revolution109.239.317.4
Dirt 372.646.94014.3
Crysis 276523712
Call of Duty: Black Ops765733
Fifa 1145827513070
Mafia 254463924
StarCraft 21713933.923
Metro 203345.1432111
Battlefield: Bad Company 273553720
CoD Modern Warfare 233
Risen64402820
Resident Evil 5985234
Colin McRae: DIRT 271.521.3
Sims 351
F.E.A.R. 275.847.542.425
GTA IV - Grand Theft Auto584728
Left 4 Dead143
Far Cry 21525725.5
Crysis Warhead10516.9
Racedriver: GRID65.448.939.2
Trackmania Nations Forever1115826
Supreme Commander - FA Bench46.3373220
Crysis - GPU Benchmark77.2674411
Crysis - CPU Benchmark71.752.133.79.5
World in Conflict - Benchmark89374417
Call of Juarez Benchmark35.9
Half Life 2 - Lost Coast Benchmark92.4
World of Warcraft94.163.835
Doom 3201.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
5
15
4		1
14
4
2		5
19
2
2		17
4
1
1





For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 29. 03:56:27

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Fri, 28 Jun 2024 05:30:38 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.039s ... 0.04s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.04s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.04s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.04s

#7 composed specs +0s ... 0.04s

#8 did output specs +0s ... 0.041s

#9 start showIntegratedCPUs +0s ... 0.041s

#10 getting avg benchmarks for device 2088 +0.014s ... 0.055s

#11 got single benchmarks 2088 +0.025s ... 0.08s

#12 got avg benchmarks for devices +0s ... 0.08s

#13 min, max, avg, median took s +0.235s ... 0.315s

#14 before gaming benchmark output +0s ... 0.315s

#15 Got 142 rows for game benchmarks. +0.009s ... 0.325s

#16 composed SQL query for gamebenchmarks +0s ... 0.325s

#17 got data and put it in $dataArray +0.014s ... 0.339s

#18 benchmarks composed for output. +0.917s ... 1.256s

#19 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.259s

#20 return log +0s ... 1.259s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
GeForce MX570 *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
SD X Adreno X1-85 4.6 TFLOPS GPU *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
SD X Adreno X1-85 3.8 TFLOPS GPU *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
Radeon Graphics (Ryzen 9000) *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon HD 6750M
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
