AMD Radeon HD 6950M

AMD Radeon HD 6950M

AMD的Mobility Radeon HD 6950M(有时也被称为了ATI Mobility Radeon HD 6950)是一个高端的显卡,一般用于大又重的笔记本电脑。它是基于在桌面上的HD 6850图形卡,因此,设有新的UVD3视频处理器,Tessellation性能增加的Eyefinity +。这个GPU的代号是黑梳山临,它应该有类似的功耗GeForce®(精视™)GTX 470M。相比更快的HD 6970M,6950M的核心是至少100 MHz的时钟慢。 960个流处理器,仍然要“老字号”的5D架构,类似于5000系列的基础上。因此,在6950M的着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation(曲面细分)性能,但是,应该提高(像桌面6800系列),新卡。可用于流处理器,借助DirectX 11,OpenGL的4.1的DirectCompute 11和OpenCL。与后两者,6950M的芯也可以被用于一般像视频转码的计算。 3D效能的GeForce®(精视™)GTX 470M中高端类笔记本电脑的图形卡的面值。对于游戏玩家来说,这意味着,这款Radeon HD 6950M是能够流利地发挥最先进的游戏(如2011年),高细节设置。只有Crysis和地铁2033意志口吃设置在1920x1080分辨率最高的细节(见下文)。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264,VC-1,MPEG-2,Flash和现在也多视图编解码器(MVC)和MPEG-4第2部分(DIVX,XVID)高清视频显卡上的。此外,HD 6900M系列集成了一个HD音频控制器,通过HDMI和DisplayPort(例如,蓝光视频)传输高清音频(TrueHD或DTS Master音频)。 AMD HD3D技术提供了支持蓝光3D和3D显示器(集成和外部)。然而,作为NVIDIA的3D Vision的解决方案是那样成熟。由于Eyefinity技术,图形芯片则是能够从理论上驱动多达6台显示器同时提供笔记本本身有足够的视频输出端口。的6950M的功耗应该是类似Nvidia的GeForce GTX470M,因此只适合中大笔记本电脑提供良好的散热解决方案。

Radeon HD 6900M Series

Radeon HD 6990M Crossfire 2240 @ 0.72 GHz256 Bit @ 900 MHz
Radeon HD 6970M Crossfire 1920 @ 0.68 GHz256 Bit @ 900 MHz
Radeon HD 6990M 1120 @ 0.72 GHz256 Bit @ 900 MHz
Radeon HD 6970M 960 @ 0.68 GHz256 Bit @ 900 MHz
Radeon HD 6950M 960 @ 0.58 GHz256 Bit @ 900 MHz
CodenameBlackcomb Pro
ArchitectureTerascale 2
Pipelines960 - unified
Core Speed580 MHz
Memory Speed900 MHz
Memory Bus Width256 Bit
Memory TypeGDDR5
Max. Amount of Memory2048 MB
Shared Memoryno
APIDirectX 11, Shader 5.0
Transistor Count1.7 Billion
technology40 nm
Notebook Sizelarge
Date of Announcement06.01.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
2643 Points (3%)
3DMark 11 - 3DM11 Performance GPU
2452 Points (2%)
171.8 -93%
...
2371 -3%
AMD Radeon HD 8850M
2381 -3%
NVIDIA Quadro K2100M
2396 -2%
AMD Radeon HD 8650G + HD 8670M Dual Graphics
2398 -2%
NVIDIA GeForce 940M
2417 -1%
2422 -1%
2427 -1%
NVIDIA Quadro K620M
2434 -1%
Intel Iris Graphics 550
2435 -1%
AMD Radeon HD 6950M
2452
2467 1%
AMD Radeon R7 M340
2492 2%
AMD Radeon 610M
2539 4%
NVIDIA GeForce GT 750M
2549 4%
NVIDIA Maxwell GPU Surface Book
2577 5%
2582 5%
2595 6%
2615 7%
2658 8%
...
59943 2345%
max:
104201 4150%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
10122 Points (3%)
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
9694 Points (5%)
ATI Radeon HD 3200
62 -99%
...
NVIDIA GeForce GTX 260M SLI
8764 -10%
NVIDIA Quadro K2100M
8930 -8%
AMD Radeon RX Vega 8 (Ryzen 2000/3000)
8994 -7%
9070 -6%
Intel Iris Graphics 550
9089 -6%
9135 -6%
9184 -5%
Intel UHD Graphics Xe G4 48EUs
9484 -2%
9666 0%
AMD Radeon HD 6950M
9694
ATI Mobility Radeon HD 4870 X2
9844 2%
9902 2%
AMD Radeon RX Vega 10
9909 2%
NVIDIA GeForce GTX 280M SLI
9947 3%
10052 4%
10067 4%
AMD Radeon Pro WX 3100
10150 5%
10211 5%
10234 6%
...
132443 1266%
max:
170928 1663%
0%
100%
3DMark 03 - 3DMark 03 - Standard
49088 Points (26%)
3DMark 05 - 3DMark 05 - Standard
18466 Points (20%)
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
17271 -6%
17513 -5%
17545 -5%
17784 -4%
18044 -2%
18136 -2%
18199 -1%
18199 -1%
NVIDIA GeForce GTX 280M
18414 0%
AMD Radeon HD 6950M
18466
ATI Mobility Radeon HD 4870 X2
18522 0%
18829 2%
18903 2%
NVIDIA GeForce GTX 285M
18965 3%
19079 3%
NVIDIA GeForce 9800M GTS SLI
19100 3%
ATI Mobility Radeon HD 3870 X2
19187 4%
NVIDIA GeForce GTX 280M SLI
19268 4%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU)
19383 5%
...
68064 269%
max:
87172 372%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
13719 Points (18%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
