AMD Radeon HD 7450M

AMD Radeon HD 7450M

AMD Radeon HD 7450M（有时也仍然被称为ATI的Mobility Radeon HD 7450）是入门级到中产阶层的笔记本电脑一台笔记本电脑的图形卡。它是基于老西摩芯片和，因此配备UVD视频解码器。从技术上讲，它只是一个改名的Radeon HD 6400M芯片和快速GDDR5的支持，HD 6450M或6490M HD相媲美。 DDR3版本应该提供的GDDR5版本的速度稍快的时钟速率，因此，双方应进行类似的。 120个流处理器，仍然要基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。是介于6450M和6490M的时钟速度和使用的图形内存的性能。例如HD 6490M能够运行现代游戏一样，星际争霸2和呼叫的职务黑色行动中设置和XGA分辨率流利。 “地铁2033”等要求苛刻的游戏应该只在最低的设置和分辨率播放。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD 6400M系列集成了HD音频控制器，通过HDMI和DisplayPort（例如，献给蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片能够在理论上同时驱动多达4个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。的Mobility Radeon HD 5470应该是相似的，因此适用于13“笔记本电脑和功耗的芯片。

Radeon HD 7400M Series

Radeon HD 7490M 160 @ 0.8 GHz64 Bit @ 3800 MHz
Radeon HD 7470M 160 @ 0.75 GHz64 Bit @ 3200 / 1800 MHz
Radeon HD 7450M 160 @ 0.7 GHz64 Bit @ 1800 MHz
Radeon HD 7430M 160 @ 0.6 GHz64 Bit @ 1800 MHz
CodenameSeymour-PRO
ArchitectureTerascale 2
Pipelines160 - unified
Core Speed700 MHz
Memory Speed1800 MHz
Memory Bus Width64 Bit
Memory TypeDDR3, GDDR5
Shared Memoryno
APIDirectX 11, Shader 5.0
technology40 nm
Date of Announcement08.02.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 613     avg: 652     median: 652 (1%)     max: 691 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 547     avg: 582     median: 581.5 (0%)     max: 616 Points
+ 2 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -70%
...
NVIDIA GeForce GT 520M
499.8 -14%
NVIDIA GeForce 610M
513 -12%
NVIDIA NVS 4200M
519 -11%
Intel HD Graphics 4000
522 -10%
AMD Radeon HD 7470M
522 -10%
AMD Radeon HD 6470M
531 -9%
AMD Radeon HD 8330
532 -9%
Intel UHD Graphics 600
558 -4%
AMD Radeon R3 (Mullins/Beema)
576 -1%
AMD Radeon HD 7450M
582
AMD Radeon HD 7520G
584 0%
AMD Radeon HD 7500G
585 1%
NVIDIA GeForce GT 520MX
597 3%
AMD Radeon HD 6490M
599 3%
AMD Radeon R4 (Kaveri)
611 5%
AMD Radeon HD 8400
615 6%
Intel HD Graphics 4200
624 7%
AMD Radeon HD 8350G
624 7%
Intel HD Graphics 505
632 9%
...
AMD Radeon RX 7900M
59943 10199%
max:
NVIDIA GeForce RTX 4090
104201 17804%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 2034     avg: 2281     median: 2280.5 (1%)     max: 2527 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 1716     avg: 1938     median: 1938 (1%)     max: 2160 Points
+ 2 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -97%
...
AMD Radeon R4 (Kaveri)
1811 -7%
AMD Radeon HD 8610G
1817 -6%
Intel UHD Graphics 600
1836 -5%
AMD Radeon HD 8450G
1853 -4%
Intel HD Graphics (Haswell)
1859 -4%
NVIDIA GeForce 610M
1880 -3%
NVIDIA NVS 4200M
1896 -2%
ATI Mobility Radeon HD 3850
1928 -1%
AMD Radeon R2 (Stoney Ridge)
1930 0%
AMD Radeon HD 7450M
1938
Intel HD Graphics 4200
1985 2%
NVIDIA GeForce GT 230M
2012 4%
AMD Radeon HD 6490M
2018 4%
AMD Radeon HD 7620G
2031 5%
NVIDIA GeForce GT 330M
2039 5%
Intel HD Graphics 505
2073 7%
NVIDIA GeForce GT 240M
2092 8%
AMD Radeon HD 7520G
2098 8%
AMD Radeon R4 (Beema)
2111 9%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 6734%
max:
AMD Radeon RX 7900 XTX
170928 8720%
0%
100%
3DMark 03 - 3DMark 03 - Standard
14302 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
8358 Points (9%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
NVIDIA GeForce 410M
7605 -9%
ATI Mobility Radeon HD 545v
7732 -7%
AMD Radeon HD 7640G
7781 -7%
NVIDIA Quadro FX 570M
7790 -7%
NVIDIA GeForce GT 320M
7795 -7%
AMD Radeon HD 6470M
8031 -4%
ATI Mobility Radeon HD 3670
8176 -2%
NVIDIA GeForce 610M
8276 -1%
Intel HD Graphics 4000
8296 -1%
AMD Radeon HD 7450M
8358
NVIDIA GeForce 9650M GT
8387 0%
NVIDIA GeForce Go 7900 GTX
8436 1%
NVIDIA Quadro FX 2500M
8450 1%
AMD Radeon HD 6540G2
8495 2%
ATI Mobility FireGL V5700
8577 3%
Intel HD Graphics 615
8649 3%
Intel HD Graphics 4400
8674 4%
NVIDIA GeForce GT 220M
8696 4%
AMD Radeon HD 7550M
8746 5%
...
AMD Radeon RX 7600M XT
68064 714%
max:
NVIDIA GeForce RTX 4080 Super
87172 943%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 3886     avg: 4347     median: 4346.5 (6%)     max: 4807 Points
+ 2 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
min: 6.3     avg: 6.9     median: 6.9 (1%)     max: 7.4 fps
+ 2 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -91%
...
AMD Radeon HD 6520G
5.4 -21%
AMD Radeon HD 7470M
5.4 -21%
AMD Radeon R3 (Mullins/Beema)
5.45 -20%
AMD Radeon HD 6480G
5.5 -20%
Intel HD Graphics (Cherry Trail)
5.7 -17%
Intel HD Graphics (Sandy Bridge)
5.7 -17%
AMD Radeon HD 6470M
6.2 -9%
AMD Radeon HD 6490M
6.7 -2%
AMD Radeon HD 7520G
6.85 0%
AMD Radeon HD 7450M
6.85
NVIDIA GeForce 310M
7 2%
Intel HD Graphics 405 (Braswell)
7.4 8%
NVIDIA NVS 4200M
7.45 9%
NVIDIA GeForce GT 520M
7.617 11%
NVIDIA GeForce 610M
7.675 12%
Intel HD Graphics 3000
7.7 12%
AMD Radeon R2 (Stoney Ridge)
7.8 14%
AMD Radeon HD 7550M
8.1 18%
AMD Radeon R4 (Stoney Ridge)
8.35 22%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 7666%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.1     avg: 6.3     median: 6.3 (80%)     max: 6.5 Points
+ 2 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 4.7     avg: 5.3     median: 5.3 (67%)     max: 5.9 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
3513 points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
17.5 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Fifa 13

Fifa 13

2012
low 1024x768
81  fps    + Compare
med. 1366x768
60  fps    + Compare
high 1366x768
56  fps    + Compare
» With all tested laptops playable in detail settings high.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
24  fps    + Compare
high 1366x768
18  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Star Wars: The Old Republic

Star Wars: The Old Republic

2011
low 1024x768
25.6  fps    + Compare
high 1366x768
16.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
48.1 54.5 ~ 51 fps    + Compare
med. 1366x768
17.1 21 ~ 19 fps    + Compare
high 1366x768
13.6  fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
29.5  fps    + Compare
med. 1366x768
20.2  fps    + Compare
high 1366x768
13.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield 3

Battlefield 3

2011
low 1024x768
17.5 21.8 ~ 20 fps    + Compare
med. 1366x768
13.9 14.8 ~ 14 fps    + Compare
high 1366x768
11.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
87 125.3 ~ 106 fps    + Compare
med. 1024x768
56 69.9 ~ 63 fps    + Compare
high 1360x768
40 55.6 ~ 48 fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2011

F1 2011

2011
low 800x600
49  fps    + Compare
med. 1024x768
30  fps    + Compare
high 1366x768
21  fps    + Compare
» With all tested laptops playable in detail settings low.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
61.3  fps    + Compare
high 1366x768
19.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Dirt 3

Dirt 3

2011
low 800x600
75.7  fps    + Compare
med. 1024x768
38.3  fps    + Compare
high 1360x768
25  fps    + Compare
» With all tested laptops playable in detail settings med..
Crysis 2

Crysis 2

2011
low 800x600
35  fps    + Compare
med. 1024x768
23.5  fps    + Compare
high 1366x768
17.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
52.8  fps    + Compare
med. 1024x768
36.5  fps    + Compare
high 1360x768
30.1  fps    + Compare
» With all tested laptops playable in detail settings med..
Mafia 2

Mafia 2

2010
low 800x600
34.4  fps    + Compare
med. 1024x768
29.2  fps    + Compare
high 1360x768
24.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
92.9  fps    + Compare
med. 1360x768
28.4  fps    + Compare
high 1360x768
19.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
34.2  fps    + Compare
med. 1360x768
17.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Risen

Risen

2009
low 800x600
49.6  fps    + Compare
med. 1024x768
22.4  fps    + Compare
» With all tested laptops playable in detail settings low.
lowmed.highultraQHD4K
Fifa 13816056
Mass Effect 32418
Star Wars: The Old Republic25.616.8
Anno 2070511913.6
The Elder Scrolls V: Skyrim29.520.213.1
Battlefield 3201411.2
Fifa 121066348
F1 2011493021
Deus Ex Human Revolution61.319.8
Dirt 375.738.325
Crysis 23523.517.7
Call of Duty: Black Ops52.836.530.1
Mafia 234.429.224.7
StarCraft 292.928.419.8
Metro 203334.217.5
Risen49.622.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		4
7
5
8
3
2
11
3










For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 09. 12:37:24

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.035s ... 0.036s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.036s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.037s

#7 composed specs +0s ... 0.037s

#8 did output specs +0s ... 0.037s

#9 start showIntegratedCPUs +0s ... 0.037s

#10 getting avg benchmarks for device 2682 +0.014s ... 0.05s

#11 got single benchmarks 2682 +0.014s ... 0.064s

#12 got avg benchmarks for devices +0s ... 0.064s

#13 min, max, avg, median took s +0.219s ... 0.283s

#14 before gaming benchmark output +0s ... 0.283s

#15 Got 50 rows for game benchmarks. +0.003s ... 0.286s

#16 composed SQL query for gamebenchmarks +0s ... 0.286s

#17 got data and put it in $dataArray +0.01s ... 0.296s

#18 benchmarks composed for output. +0.416s ... 0.712s

#19 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 0.715s

#20 return log +0s ... 0.715s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
M4 20-core GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
Radeon HD 7450M
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

* Approximate position of the graphics adapter
