AMD Radeon HD 7550M

AMD Radeon HD 7550M

AMD Radeon HD 7550M（有时也被称为AMD的Mobility Radeon HD 7550）是一个DirectX11的中产阶层的图形卡的笔记本电脑。它是基于在同一芯片上的Radeon HD 6630M，但只有5 SIMD引擎（= 400着色器）被激活。此外，只有64位宽的存储器接口，支持DDR3和GDDR5。根据不同的版本，核心频率是450 550兆赫之间。该架构是基于对北方四岛的一代，在40nm工艺制造。 400个流处理器，仍然要基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。 3D性能，小的存储器接口的限制，应该是远低于Radeon HD 6530M的。因此减速，目前的游戏应该运行在1024×768或1366×768中的细节流利。 2070年安诺播放等要求很高的游戏的设置，进一步降低可能是必要的。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD 7500M系列集成了HD音频控制器，通过HDMI和DisplayPort（如蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片则是能够从理论上同时驱动多达5个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。功耗的芯片的Radeon HD 6530M应该是相似的，因此适合更小的笔记本电脑（13-14）。

Radeon HD 7500M Series

Radeon HD 7590M 480 @ 0.6 GHz64 Bit @ 3200 MHz
Radeon HD 7570M 400 @ 0.45 - 0.65 GHz64 Bit @ 3200 / 1800 MHz
Radeon HD 7550M 400 @ 0.45 - 0.55 GHz64 Bit @ 3200 / 1800 MHz
Radeon HD 7500G + HD 7550M Dual Graphics 736 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7530M 400 @ 0.45 GHz64 Bit @ 1800 MHz
Radeon HD 7510M 400 @ 0.45 GHz64 Bit @ 1600 MHz
CodenameThames-LP / Pro
ArchitectureTerascale 2
Pipelines400 - unified
Core Speed450 - 550 (Boost) MHz
Memory Speed3200 / 1800 MHz
Memory Bus Width64 Bit
Memory TypeGDDR5 / DDR3
Shared Memoryno
APIDirectX 11, Shader 5.0
technology40 nm
Notebook Sizemedium sized
Date of Announcement07.01.2012

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.3 pt (1%)
AMD Radeon HD 8180
0.06404 -75%
...
AMD Radeon HD 8450G
0.2052 -18%
AMD Radeon HD 8610G
0.2098 -17%
Intel HD Graphics 4000
0.212 -16%
AMD Radeon R4 (Beema)
0.2195 -13%
AMD Radeon R2 (Stoney Ridge)
0.2259 -10%
AMD Radeon HD 7500G
0.2261 -10%
AMD Radeon HD 8450G + Radeon HD 8570M Dual Graphics
0.2275 -9%
Intel UHD Graphics (Elkhart Lake 16 EU)
0.231 -8%
AMD Radeon R5 (Beema/Carrizo-L)
0.2381 -5%
AMD Radeon HD 7550M
0.2513
Intel HD Graphics 4400
0.2513 0%
AMD Radeon HD 7570M
0.2513 0%
AMD Radeon R5 (Kaveri)
0.2526 1%
AMD Radeon R4 (Stoney Ridge)
0.2575 2%
AMD Radeon HD 7610M
0.2672 6%
Intel HD Graphics 610
0.2683 7%
Intel HD Graphics 510
0.2743 9%
AMD Radeon HD 7640G + HD 7670M Dual Graphics
0.2752 10%
Intel HD Graphics 4600
0.2807 12%
...
NVIDIA GeForce RTX 4090 Laptop GPU
20.4 8018%
max:
NVIDIA GeForce RTX 4090
33.3 13151%
0%
100%
3DMark - 3DMark Cloud Gate Score
3573 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
4081 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
545 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
569 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
40338 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 780     avg: 826     median: 843 (1%)     max: 856 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 739     avg: 753     median: 756 (1%)     max: 764 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -77%
...
Intel UHD Graphics (Elkhart Lake 16 EU)
650 -14%
AMD Radeon HD 7640G
656 -13%
AMD Radeon HD 8450G
678 -10%
NVIDIA GeForce GT 420M
685 -9%
AMD Radeon HD 7600G
700 -7%
Intel UHD Graphics 605
701 -7%
AMD Radeon R4 (Beema)
721 -4%
AMD Radeon R2 (Stoney Ridge)
731 -3%
NVIDIA GeForce GT 525M
743 -1%
AMD Radeon HD 7550M
753
Intel HD Graphics 4400
755 0%
NVIDIA GeForce GT 425M
756 0%
AMD Radeon HD 7610M
757 1%
AMD Radeon R5 (Beema/Carrizo-L)
777 3%
NVIDIA GeForce GT 435M
799 6%
Intel UHD Graphics (Jasper Lake 16 EU)
819 9%
AMD Radeon HD 7570M
825 10%
AMD FirePro M2000
841 12%
Intel HD Graphics 510
847 12%
...
AMD Radeon RX 7900M
59943 7861%
max:
NVIDIA GeForce RTX 4090
104201 13738%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 2472     avg: 2823     median: 2927 (1%)     max: 3069 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 2394     avg: 2478     median: 2433 (1%)     max: 2607 Points
+ 3 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -97%
...
NVIDIA GeForce 8800M GTS
2220 -10%
AMD Radeon HD 7640G
2222 -10%
AMD Radeon R4 (Stoney Ridge)
2243 -9%
AMD Radeon R5 (Beema/Carrizo-L)
2259 -9%
AMD Radeon HD 7500G
2322 -6%
ATI Mobility Radeon HD 5165
2362 -5%
NVIDIA Quadro FX 2700M
2392 -3%
Intel HD Graphics 4000
2441 -1%
NVIDIA GeForce 9700M GTS
2453 -1%
AMD Radeon HD 7550M
2478
NVIDIA GeForce GT 420M
2527 2%
ATI Mobility Radeon HD 4670
2552 3%
AMD Radeon HD 6755G2
2593 5%
NVIDIA GeForce GT 335M
2624 6%
AMD Radeon R5 (Kaveri)
2674 8%
ATI Mobility Radeon HD 5650
2711 9%
AMD Radeon HD 6540G2
2731 10%
AMD Radeon HD 6680G2
2800 13%
NVIDIA Quadro FX 1800M
2801 13%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 5245%
max:
AMD Radeon RX 7900 XTX
170928 6798%
0%
100%
3DMark 2001SE - 3DMark 2001 - Standard
16206 Points (17%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
14252 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
8746 Points (10%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
AMD Radeon HD 7450M
8358 -4%
NVIDIA GeForce 9650M GT
8387 -4%
NVIDIA GeForce Go 7900 GTX
8436 -4%
NVIDIA Quadro FX 2500M
8450 -3%
AMD Radeon HD 6540G2
8495 -3%
ATI Mobility FireGL V5700
8577 -2%
Intel HD Graphics 615
8649 -1%
Intel HD Graphics 4400
8674 -1%
NVIDIA GeForce GT 220M
8696 -1%
AMD Radeon HD 7550M
8746
ATI Mobility Radeon HD 2600 XT
8769 0%
AMD Radeon HD 6755G2
8810 1%
ATI Mobility Radeon HD 3850
8816 1%
NVIDIA GeForce 9600M GS
8844 1%
AMD Radeon R4 (Stoney Ridge)
8856 1%
Intel UHD Graphics Xe 750 32EUs (Rocket Lake)
8935 2%
NVIDIA GeForce GT 520M
9070 4%
NVIDIA Quadro NVS 320M
9075 4%
NVIDIA GeForce 8700M GT
9102 4%
...
AMD Radeon RX 7600M XT
68064 678%
max:
NVIDIA GeForce RTX 4080 Super
87172 897%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 4804     avg: 5044     median: 4932 (6%)     max: 5395 Points
+ 3 benchmarks and specifications   + Show comparison chart
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
7.4 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
8.1 fps (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
5.9 Points (75%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
5.9 Points (75%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
4935 points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 20.77     avg: 21.4     median: 21.4 (7%)     max: 22.02 fps
+ 2 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

BioShock Infinite

BioShock Infinite

2013
low 1280x720
40.7  fps    + Compare
med. 1366x768
20.4  fps    + Compare
high 1366x768
16.6  fps    + Compare
» With all tested laptops playable in detail settings low.
StarCraft II: Heart of the Swarm

StarCraft II: Heart of the Swarm

2013
low 1024x768
189.6  fps    + Compare
med. 1366x768
39.3  fps    + Compare
high 1366x768
19.8  fps    + Compare
» With all tested laptops playable in detail settings med..
SimCity

SimCity

2013
low 1024x768
38.7  fps    + Compare
med. 1366x768
15.9  fps    + Compare
high 1366x768
11.6  fps    + Compare
» With all tested laptops playable in detail settings low.
Tomb Raider

Tomb Raider

2013
low 1024x768
50.9  fps    + Compare
med. 1366x768
23.8  fps    + Compare
high 1366x768
14.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis 3

Crysis 3

2013
low 1024x768
19.7  fps    + Compare
med. 1366x768
11.7  fps    + Compare
high 1366x768
7.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dead Space 3

Dead Space 3

2013
low 1024x768
76.4  fps    + Compare
med. 1366x768
28.8  fps    + Compare
high 1366x768
22.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Far Cry 3

Far Cry 3

2012
low 1024x768
32.1  fps    + Compare
med. 1366x768
17.6  fps    + Compare
high 1366x768
10.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Assassin´s Creed III

Assassin´s Creed III

2012
med. 1366x768
24.2  fps    + Compare
high 1366x768
17.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
30.4  fps    + Compare
med. 1366x768
18.4  fps    + Compare
high 1366x768
7.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops 2

Call of Duty: Black Ops 2

2012
low 1024x768
47.2  fps    + Compare
med. 1366x768
30.4  fps    + Compare
high 1366x768
13.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed: Most Wanted

Need for Speed: Most Wanted

2012
low 1024x768
30.8  fps    + Compare
med. 1366x768
18.1  fps    + Compare
high 1366x768
11.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Medal of Honor: Warfighter

Medal of Honor: Warfighter

2012
low 1024x768
27  fps    + Compare
med. 1366x768
17.6  fps    + Compare
high 1366x768
13.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dishonored

Dishonored

2012
low 1024x768
37  fps    + Compare
med. 1366x768
28.8  fps    + Compare
high 1366x768
25.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Fifa 13

Fifa 13

2012
low 1024x768
180  fps    + Compare
med. 1366x768
108.3  fps    + Compare
high 1366x768
81.2  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2012

F1 2012

2012
low 1024x768
72  fps    + Compare
med. 1366x768
45  fps    + Compare
high 1366x768
30  fps    + Compare
» With all tested laptops playable in detail settings med..
Borderlands 2

Borderlands 2

2012
low 1024x768
30.3  fps    + Compare
med. 1366x768
23.2  fps    + Compare
high 1366x768
16.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Guild Wars 2

Guild Wars 2

2012
low 1024x768
55.9  fps    + Compare
high 1366x768
17  fps    + Compare
» With all tested laptops playable in detail settings low.
Counter-Strike: GO

Counter-Strike: GO

2012
low 1024x768
133.3  fps    + Compare
med. 1366x768
75  fps    + Compare
high 1366x768
56.9  fps    + Compare
» With all tested laptops playable in detail settings high.
Darksiders II

Darksiders II

2012
med. 1366x768
26.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
43.7  fps    + Compare
med. 1366x768
32.8  fps    + Compare
high 1366x768
11.8  fps    + Compare
» With all tested laptops playable in detail settings low.
Max Payne 3

Max Payne 3

2012
low 1024x768
25.5  fps    + Compare
med. 1366x768
25.4  fps    + Compare
high 1366x768
8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt Showdown

Dirt Showdown

2012
low 1024x768
65.4  fps    + Compare
med. 1366x768
39.6  fps    + Compare
high 1366x768
25.9  fps    + Compare
» With all tested laptops playable in detail settings med..
Diablo III

Diablo III

2012
low 1024x768
58.1  fps    + Compare
med. 1366x768
38.1  fps    + Compare
high 1366x768
30.6  fps    + Compare
» With all tested laptops playable in detail settings med..
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
21.7  fps    + Compare
med. 1366x768
14.6  fps    + Compare
high 1366x768
11.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
29.5  fps    + Compare
high 1366x768
21.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Alan Wake

Alan Wake

2012
low 1024x768
18.1  fps    + Compare
med. 1366x768
11.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
36 61.8 ~ 49 fps    + Compare
med. 1366x768
14 22.7 ~ 18 fps    + Compare
high 1366x768
9 14.6 ~ 12 fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
29 37.7 ~ 33 fps    + Compare
med. 1366x768
21 22.7 ~ 22 fps    + Compare
high 1366x768
14 15.3 ~ 15 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
130.4  fps    + Compare
med. 1366x768
53.1  fps    + Compare
high 1366x768
26.5  fps    + Compare
» With all tested laptops playable in detail settings med..
Battlefield 3

Battlefield 3

2011
low 1024x768
24.9  fps    + Compare
med. 1366x768
16.4  fps    + Compare
high 1366x768
12.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Batman: Arkham City

Batman: Arkham City

2011
low 1024x768
41  fps    + Compare
med. 1366x768
34  fps    + Compare
high 1366x768
12  fps    + Compare
» With all tested laptops playable in detail settings low.
F1 2011

F1 2011

2011
low 800x600
25  fps    + Compare
med. 1024x768
18  fps    + Compare
high 1366x768
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops

Call of Duty: Black Ops

2010
low 800x600
37  fps    + Compare
med. 1024x768
29  fps    + Compare
high 1360x768
25  fps    + Compare
» With all tested laptops playable in detail settings low.
lowmed.highultraQHD4K
BioShock Infinite40.720.416.6
StarCraft II: Heart of the Swarm189.639.319.8
SimCity38.715.911.6
Tomb Raider50.923.814.4
Crysis 319.711.77.5
Dead Space 376.428.822.7
Far Cry 332.117.610.1
Assassin´s Creed III24.217.8
Hitman: Absolution30.418.47.3
Call of Duty: Black Ops 247.230.413.9
Need for Speed: Most Wanted30.818.111.7
Medal of Honor: Warfighter2717.613.8
Dishonored3728.825.5
Fifa 13180108.381.2
F1 2012724530
Borderlands 230.323.216.6
Guild Wars 255.917
Counter-Strike: GO133.37556.9
Darksiders II26.6
Sleeping Dogs43.732.811.8
Max Payne 325.525.48
Dirt Showdown65.439.625.9
Diablo III58.138.130.6
Risen 2: Dark Waters21.714.611.2
Mass Effect 329.521.8
Alan Wake18.111.7
Anno 2070491812
The Elder Scrolls V: Skyrim332215
CoD: Modern Warfare 3130.453.126.5
Battlefield 324.916.412.4
Batman: Arkham City413412
F1 2011251812
Call of Duty: Black Ops372925
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		8
16
3
4		21
8
2
27
3
1









For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 08. 22:45:08

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 08 Nov 2024 19:43:11 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.047s ... 0.048s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.048s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.049s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.049s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.049s

#9 composed specs +0s ... 0.049s

#10 did output specs +0s ... 0.049s

#11 start showIntegratedCPUs +0s ... 0.049s

#12 getting avg benchmarks for device 2913 +0.029s ... 0.078s

#13 got single benchmarks 2913 +0.017s ... 0.095s

#14 got avg benchmarks for devices +0s ... 0.095s

#15 min, max, avg, median took s +0.438s ... 0.533s

#16 before gaming benchmark output +0s ... 0.533s

#17 Got 99 rows for game benchmarks. +0.005s ... 0.538s

#18 composed SQL query for gamebenchmarks +0s ... 0.538s

#19 got data and put it in $dataArray +0.023s ... 0.561s

#20 benchmarks composed for output. +0.964s ... 1.525s

#21 no comparison url found in template nbc.compare_page_1 needed +0.004s ... 1.529s

#22 return log +0s ... 1.529s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

M4 20-core GPU
Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

M4 8-Core GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
Radeon HD 7550M
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

* Approximate position of the graphics adapter
