AMD Radeon HD7650M（有时也被称为AMD的Mobility Radeon HD7650）是一个DirectX11的中产阶层的图形卡的笔记本电脑。它是基于同一芯片上的Radeon HD 6650M，但具有较低的核心频率450 - 550兆赫。是128位宽度的存储器接口，但只支持DDR3。该架构是基于对北方四岛的一代，在40nm工艺制造。 480个流处理器，仍然要基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。 3D性能类似的Radeon HD 6630M，核心时钟（主要是500兆赫）。因此，目前的游戏（或多或少）流利运行在1366×768中的细节。 2070安诺播放等要求很高的游戏的设置，进一步降低可能是必要的。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD7600M系列集成了HD音频控制器，通过HDMI和DisplayPort（如蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片则是能够从理论上同时驱动多达5个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。该芯片的功耗，因此适用于15“笔记本电脑和类似的Radeon HD 6630M。
Radeon HD 7600M Series
| |||||||||||||||||||||||||||||||
| Codename | Thames-LP/Pro | ||||||||||||||||||||||||||||||
| Architecture | Terascale 2 | ||||||||||||||||||||||||||||||
| Pipelines | 480 - unified | ||||||||||||||||||||||||||||||
| Core Speed | 450 - 550 (Boost) MHz | ||||||||||||||||||||||||||||||
| Memory Speed | 1800 MHz | ||||||||||||||||||||||||||||||
| Memory Bus Width | 128 Bit | ||||||||||||||||||||||||||||||
| Memory Type | DDR3 | ||||||||||||||||||||||||||||||
| Shared Memory | no | ||||||||||||||||||||||||||||||
| API | DirectX 11, Shader 5.0 | ||||||||||||||||||||||||||||||
| technology | 40 nm | ||||||||||||||||||||||||||||||
| Notebook Size | medium sized | ||||||||||||||||||||||||||||||
| Date of Announcement | 07.01.2012 | ||||||||||||||||||||||||||||||
- Average benchmark values for this graphics cardThe following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
| low | med. | high | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| Need for Speed: Most Wanted | 39.6 | 29.5 | 16.1 | |||
| Medal of Honor: Warfighter | 38.2 | 24.6 | 18.9 | |||
| Dishonored | 51.9 | 41.1 | 36.8 | |||
| World of Tanks v8 | 79.3 | 34.7 | 24.9 | 14.8 | ||
| Fifa 13 | 188.8 | 126.5 | 96.9 | 57.6 | ||
| Dirt Showdown | 58.8 | 38 | 32.9 | |||
| Diablo III | 76.3 | 51.1 | 43.2 | |||
| Risen 2: Dark Waters | 37.3 | 23.2 | 17.2 | 8.7 | ||
| Mass Effect 3 | 44.24 | 32.53 | 19.4 | |||
| Anno 2070 | 75 | 32 | 22 | |||
| The Elder Scrolls V: Skyrim | 46 | 32 | 21 | 11 | ||
| CoD: Modern Warfare 3 | 151 | 76 | 40 | 22 | ||
| Battlefield 3 | 37 | 24 | 19 | 7 | ||
| Batman: Arkham City | 45.6 | 34.9 | 26.2 | |||
| Fifa 12 | 96.9 | 87 | 52 | |||
| Deus Ex Human Revolution | 102 | 34 | 14.78 | |||
| Total War: Shogun 2 | 105.4 | 31.2 | ||||
| StarCraft 2 | 229 | 46.23 | 29.86 | 17.14 | ||
| Metro 2033 | 65 | 43.9 | 17.9 | |||
| Risen | 32.8 | 21.8 | ||||
| Need for Speed Shift | 32.1 | 28.7 | ||||
| Colin McRae: DIRT 2 | 88.1 | 64.3 | 26.9 | |||
| < 30 fps < 60 fps < 120 fps ≥ 120 fps | 9 8 3 | 4 12 3 1 | 13 7 1 | 8 1 | | |
