AMD Radeon HD 7670M是中产阶级的显卡，笔记本电脑和基于同一芯片上的Radeon HD 6650M。因此，支持DirectX11和仍然在40nm工艺制造。据AMD有两个版本，一个较慢的时钟泰晤士Pro与GDDR5内存和更快的主频泰晤士XT与DDR4内存。 480个流处理器，仍然要基于对“老”5D类似于5000系列的架构。因此，着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。 Tessellation（曲面细分）性能改善（如台式机6800系列）的新卡。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。随着购买2磁芯也可以用于一般的计算类似代码转换视频。的Radeon HD 6650M的3D性能应该是相同的。然而，在我们的测试中，该卡将自身定位，有时甚至高频率的Radeon HD 6730M（同一块芯片上）的水平。请记住，不同版本的驱动程序和CPU也可能影响基准。然而，2011年要求苛刻的游戏如战地3只流利的中细节设置。查看在本页面详细的游戏测试。相较于竞争对手，7670M自己的位置在我们的测试中，略高于上一个级别的GeForce GT 550M的GeForce GT 630M。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频显卡上的。此外，HD 6600M系列集成了HD音频控制器，通过HDMI和DisplayPort（如蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。然而，解决的办法是不作为NVIDIA的3D立体幻镜™作为成熟。由于Eyefinity技术的图形芯片则是能够从理论上同时驱动多达5个显示器。然而，这只是工作，如果笔记本电脑提供足够的DisplayPort输出。的Mobility Radeon HD 5650应该是相似的，因此适用于15“笔记本电脑和功耗的芯片。
Radeon HD 7600M Series
| |||||||||||||||||||||||||||||||
| Codename | Thames XT | ||||||||||||||||||||||||||||||
| Architecture | Terascale 2 | ||||||||||||||||||||||||||||||
| Pipelines | 480 - unified | ||||||||||||||||||||||||||||||
| Core Speed | 600 MHz | ||||||||||||||||||||||||||||||
| Memory Speed | 1800 MHz | ||||||||||||||||||||||||||||||
| Memory Bus Width | 128 Bit | ||||||||||||||||||||||||||||||
| Memory Type | DDR3, (GDDR5) | ||||||||||||||||||||||||||||||
| Shared Memory | no | ||||||||||||||||||||||||||||||
| API | DirectX 11, Shader 5.0, OpenGL 4.1 | ||||||||||||||||||||||||||||||
| Transistor Count | 716 Million | ||||||||||||||||||||||||||||||
| technology | 40 nm | ||||||||||||||||||||||||||||||
| Notebook Size | medium sized | ||||||||||||||||||||||||||||||
| Date of Announcement | 07.06.2011 | ||||||||||||||||||||||||||||||
- Average benchmark values for this graphics cardThe following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
| low | med. | high | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| Dead Space 3 | 104.4 | 48.3 | 37.3 | |||
| Hitman: Absolution | 15.9 | 13.6 | 8.7 | |||
| Call of Duty: Black Ops 2 | 51.2 | 38.1 | 20.2 | |||
| Medal of Honor: Warfighter | 32.9 | 23.1 | 19.5 | |||
| Dishonored | 52.5 | 44.2 | 39.6 | 22.3 | ||
| Fifa 13 | 231 | 143 | 111 | 62 | ||
| F1 2012 | 86 | 67 | 47 | 16 | ||
| Borderlands 2 | 52.9 | 40.4 | 28.5 | 15.8 | ||
| Torchlight 2 | 81 | 67 | 52 | |||
| Guild Wars 2 | 53 | 22 | 8 | |||
| Counter-Strike: GO | 140 | 97 | 75 | 46 | ||
| Darksiders II | 42.5 | 24.3 | ||||
| Sleeping Dogs | 68.9 | 51.6 | 17.8 | 5.7 | ||
| Ghost Recon: Future Soldier | 30.6 | 16.1 | 7.4 | |||
| Max Payne 3 | 40.2 | 37.4 | 10.2 | 7.9 | ||
| Dirt Showdown | 61 | 39 | 28 | 12 | ||
| Diablo III | 61.1 | 44.6 | 38.2 | |||
| Risen 2: Dark Waters | 36.5 | 24 | 18 | 8.3 | ||
| Mass Effect 3 | 43 | 32 | 21 | |||
| Alan Wake | 32.5 | 19.7 | ||||
| Star Wars: The Old Republic | 56.8 | 34.7 | 23.6 | |||
| Anno 2070 | 79 | 32 | 22 | 11 | ||
| The Elder Scrolls V: Skyrim | 47 | 34 | 24 | 13 | ||
| CoD: Modern Warfare 3 | 139 | 70 | 40 | 22 | ||
| Battlefield 3 | 37 | 26 | 21 | 7.1 | ||
| Batman: Arkham City | 62 | 51 | 32 | 9 | ||
| Fifa 12 | 210 | 118 | 80 | 49 | ||
| F1 2011 | 72 | 45 | 26 | 15 | ||
| Deus Ex Human Revolution | 96 | 37 | 15.9 | |||
| Dirt 3 | 76 | 48 | 39 | 14 | ||
| Crysis 2 | 59.5 | 39.9 | 29 | 10.4 | ||
| Call of Duty: Black Ops | 104.5 | 65.3 | 56.4 | 34.9 | ||
| Civilization 5 | 42 | |||||
| Mafia 2 | 61 | 50 | 43 | 25 | ||
| StarCraft 2 | 127 | 45 | 30 | 19 | ||
| Metro 2033 | 60.5 | 31.1 | 17.1 | 5.8 | ||
| < 30 fps < 60 fps < 120 fps ≥ 120 fps | 1 15 14 5 | 6 18 6 1 | 15 13 3 | 24 4 1 | | |
