AMD Radeon HD 7690M XT

AMD Radeon HD 7690M XT

AMD Radeon HD 7690M XT是一种快速的中产阶级的图形卡的笔记本电脑在2011年。这是心重命名的Radeon HD 6770M独立。因此,GPU仍然是建立在40nm工艺与DirectX11的支持。 Radeon HD 7690M独立(无XT此外,更名为6750M,并提供一个GDDR5变异较低的时钟速率或速度较慢的DDR3绘图记忆体)。集成480个流处理器仍然是基于5D架构的Radeon 5000系列。因此,着色器的数量是没有可比性的1D目前NVIDIA的GPU核心。一般的Radeon HD 7690M网卡Tessellation性能媲美台式机6800系列。可用于流处理器,借助DirectX 11,OpenGL的4.1的DirectCompute 11和OpenCL。后两种功能将使AMD核心转码的视频和进行一般的计算。比GeForce GT 555M,HD 7690M XT的3D性能稍微好一点,因此,在2011年的中上阶层的定位。安诺2070或天际等要求苛刻的游戏只能起到中等详细的设置和较低的分辨率。更苛刻的游戏,如“战地3”,可能只运行在低细节设置流利。老游戏,如使命召唤:黑色行动上播放的所有设置淋漓尽致。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264,VC-1,MPEG-2,Flash和现在也多视图编解码器(MVC)和MPEG-4第2部分(DIVX,XVID)高清视频AMD显卡。此外,HD 7600M系列集成了一个HD音频控制器,通过HDMI和DisplayPort(例如,蓝光视频)传输高清音频(TrueHD或DTS Master音频)。 AMD HD3D技术提供了支持蓝光3D和3D显示器(集成和外部)。该解决方案,但是作为NVIDIA®(英伟达™)3D立体幻镜™驱动程序和软件支持方面,是不是成熟。由于Eyefinity技术,HD 7690M能够在理论上同时驱动多达5个显示器。请注意,这只会工作,如果笔记本电脑提供足够的DisplayPort输出开始。的功耗HD 7690M独立的Mobility Radeon HD 5770应该是相似的,因此,通常在15英寸或更大尺寸的笔记本电脑更强大的散热解决方案。

Radeon HD 7600M Series

Radeon HD 7690M XT 480 @ 0.73 GHz128 Bit @ 3600 MHz
Radeon HD 7690M 480 @ 0.6 - 0.73 GHz128 Bit @ 3600/1800 MHz
Radeon HD 7660G + HD 7670M Dual Graphics 862 @ 0.69 GHz128 Bit @ 1800 MHz
Radeon HD 7640G + HD 7670M Dual Graphics 736 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7520G + HD 7670M Dual Graphics 736 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7670M 480 @ 0.6 GHz128 Bit @ 1800 MHz
Radeon HD 7650M 480 @ 0.45 - 0.55 GHz128 Bit @ 1800 MHz
Radeon HD 7630M 480 @ 0.45 GHz128 Bit @ 1800 MHz
Radeon HD 7640G + HD 7610M Dual Graphics 656 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7610M 400 @ 0.45 GHz128 Bit @ 1600 MHz
CodenameThames XTX
ArchitectureTerascale 2
Pipelines480 - unified
Core Speed725 MHz
Memory Speed3600 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Shared Memoryno
APIDirectX 11, Shader 5.0, OpenGL 4.1
Transistor Count716 Million
technology40 nm
Notebook Sizemedium sized
Date of Announcement07.06.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 1517     avg: 1551     median: 1550.5 (2%)     max: 1584 Points
3DMark 11 - 3DM11 Performance GPU
1346 Points (1%)
171.8 -87%
...
1233 -8%
1233 -8%
1245 -8%
1259 -6%
1261 -6%
1286 -4%
Intel HD Graphics 520
1296 -4%
1307 -3%
1328 -1%
AMD Radeon HD 7690M XT
1346
1349 0%
1350 0%
Intel HD Graphics 530
1355 1%
AMD Radeon HD 8650G
1361 1%
1371 2%
1372 2%
NVIDIA GeForce 910M
1413 5%
Intel HD Graphics 5600
1431 6%
AMD Radeon R6 (Carrizo)
1452 8%
...
59943 4353%
max:
104201 7642%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 6765     avg: 7055     median: 7054.5 (2%)     max: 7344 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
5594 Points (3%)
ATI Radeon HD 3200
62 -99%
...
5366 -4%
5369 -4%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
5372 -4%
ATI Mobility Radeon HD 4850
5382 -4%
5410 -3%
5411 -3%
5452 -3%
5560 -1%
AMD Radeon HD 8650G + HD 8570M Dual Graphics
5573 0%
AMD Radeon HD 7690M XT
5594
AMD Radeon HD 8550G + HD 8670M Dual Graphics
5595 0%
NVIDIA GeForce GTX 285M
5631 1%
5698 2%
5717 2%
NVIDIA GeForce GT 740M
5735 3%
5833 4%
5870 5%
5896 5%
5926 6%
...
132443 2268%
max:
170928 2956%
0%
100%
3DMark 05 - 3DMark 05 - Standard
17545 Points (19%)
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
16936 -3%
NVIDIA GeForce 8800M GTX SLI
16942 -3%
16944 -3%
16972 -3%
17043 -3%
NVIDIA GeForce GT 640M
17105 -3%
17192 -2%
17271 -2%
17513 0%
AMD Radeon HD 7690M XT
17545
17784 1%
18044 3%
18136 3%
18199 4%
18199 4%
NVIDIA GeForce GTX 280M
18414 5%
18466 5%
ATI Mobility Radeon HD 4870 X2
18522 6%
18829 7%
...
69623 297%
max:
87172 397%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 10628     avg: 10919     median: 10919 (14%)     max: 11210 Points
Windows 7 Experience Index - Win7 Gaming graphics
min: 6.6     avg: 6.7     median: 6.7 (84%)     max: 6.7 Points
Windows 7 Experience Index - Win7 Graphics
min: 6.6     avg: 6.7     median: 6.7 (84%)     max: 6.7 Points
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
5514 points (4%)
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
51.5 fps (17%)
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

low 1280x720
57 60 ~ 59 fps    + Compare
high 1366x768
36 42.8 ~ 39 fps    + Compare
ultra 1920x1080
27 30.2 ~ 29 fps    + Compare
» With all tested laptops playable in detail settings high.
Anno 2070

Anno 2070

2011
low 1024x768
97.6 109 ~ 103 fps    + Compare
med. 1366x768
41.3 46 ~ 44 fps    + Compare
high 1366x768
27.4 28 ~ 28 fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings med..
low 1280x720
63.2 70 ~ 67 fps    + Compare
med. 1366x768
44.7  fps    + Compare
high 1366x768
30  fps    + Compare
ultra 1920x1080
18  fps    + Compare
» With all tested laptops playable in detail settings med..
low 1024x768
49  fps    + Compare
med. 1366x768
34  fps    + Compare
high 1366x768
28  fps    + Compare
ultra 1920x1080
10  fps    + Compare
» With all tested laptops playable in detail settings low.
Fifa 12

Fifa 12

2011
low 800x600
303  fps    + Compare
med. 1024x768
154.9  fps    + Compare
high 1360x768
105.4  fps    + Compare
ultra 1920x1080
55.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2011

F1 2011

2011
low 800x600
92  fps    + Compare
med. 1024x768
62  fps    + Compare
high 1366x768
37  fps    + Compare
» With all tested laptops playable in detail settings high.
low 1024x768
102.7 157 ~ 130 fps    + Compare
high 1366x768
43.4 48 ~ 46 fps    + Compare
ultra 1920x1080
22  fps    + Compare
» With all tested laptops playable in detail settings high.
Dirt 3

Dirt 3

2011
low 800x600
104.2  fps    + Compare
med. 1024x768
63.2  fps    + Compare
high 1360x768
48.2  fps    + Compare
» With all tested laptops playable in detail settings high.
low 1024x768
39  fps    + Compare
med. 1366x768
27  fps    + Compare
high 1600x900
17  fps    + Compare
ultra 1920x1080
13  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis 2

Crysis 2

2011
low 800x600
88  fps    + Compare
med. 1024x768
54  fps    + Compare
high 1366x768
44  fps    + Compare
ultra 1920x1080
17  fps    + Compare
» With all tested laptops playable in detail settings high.
low 800x600
90  fps    + Compare
med. 1024x768
79  fps    + Compare
high 1360x768
68  fps    + Compare
ultra 1920x1080
45  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Civilization 5

Civilization 5

2010
low 1024x768
63  fps    + Compare
ultra 1920x1080
17  fps    + Compare
» With all tested laptops playable in detail settings low.
low 800x600
115  fps    + Compare
med. 1360x768
47  fps    + Compare
high 1600x900
25  fps    + Compare
ultra 1920x1080
9  fps    + Compare
» With all tested laptops playable in detail settings med..
GTA IV - Grand Theft Auto

GTA IV - Grand Theft Auto

2008
med. 1024x768
64  fps    + Compare
high 1280x1024
47  fps    + Compare
» With all tested laptops playable in detail settings high.
Far Cry 2

Far Cry 2

2008
low 640x480
166  fps    + Compare
high 1024x768
69  fps    + Compare
ultra 1920x1080
27  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Mass Effect 3593929
Anno 2070103442815
The Elder Scrolls V: Skyrim6744.73018
Battlefield 349342810
Fifa 12303154.9105.455.6
F1 2011926237
Deus Ex Human Revolution1304622
Dirt 3104.263.248.2
The Witcher 2: Assassins of Kings39271713
Crysis 288544417
Call of Duty: Black Ops90796845
Civilization 56317
Metro 203311547259
GTA IV - Grand Theft Auto6447
Far Cry 21666927
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps

3
8
3
1
5
4
1
4
7
3
10
2







For more games that might be playable and a list of all games and graphics cards visit our Gaming List
