AMD Radeon HD 7690M

AMD Radeon HD 7690M

AMD Radeon HD 7690M是一个快速的中产阶级的图形卡的笔记本电脑在2011年推出。这是一个改名为Radeon HD 6750M的心脏模型运动DDR3 VRAM内存时钟速度100MHz的增加。因此，GPU仍然是建立在40nm工艺与DirectX11的支持。据AMD，更快的主频泰晤士XTX芯片的基础上，选择DDR3型号可供选择。同样命名为Radeon HD 7690M XT是基于相同的架构核心为7690M，但与GDDR5记忆体提供更高的时钟速度。在本质上，XT变体是一种改名为Radeon HD 6770M独立。 6750MAMD Radeon HD 7690M, 600 MHz core, GDDR5 -> 6750MAMD Radeon HD 7690M XT, 725 MHz core, GDDR5 -> 6770M The integrated 480">当前7690M型号可供选择，900 MHz的DDR3内存，725 MHz核心的AMD Radeon HD 7690M - > 6750MAMD的Radeon HD 7690M，600 MHz的核心，GDDR5 - > 6750MAMD Radeon HD 7690M独立XT，725 MHz的核心，GDDR5 - > 6770M集成480流处理器仍然是基于5D架构的Radeon 5000系列。因此，一些着色器是目前NVIDIA GPU（图形处理器）的1D核心没有直接的可比性。一般的Radeon HD 7690M网卡Tessellation性能媲美台式机6800系列。可用于流处理器，借助DirectX 11，OpenGL的4.1的DirectCompute 11和OpenCL。后两种功能将使AMD核心转码的视频和进行一般的计算。的HD 7690M的3D性能略好于平均的GeForce®（精视™）GT 550M，因此在2011年的中上阶层的定位。要求苛刻的游戏，如安诺2070或天际的只播放中详细的设置和较低的分辨率。更苛刻的游戏，如“战地3”，可能只运行在低细节设置流利。老游戏，如使命召唤：黑色行动上播放的所有设置淋漓尽致。新的UVD3视频解码器支持的解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID）高清视频AMD显卡。此外，HD 7600M系列集成了一个HD音频控制器，通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。 AMD HD3D技术提供了支持蓝光3D和3D显示器（集成和外部）。该解决方案，但是作为NVIDIA®（英伟达™）3D立体幻镜™驱动程序和软件支持方面，是不是成熟。由于Eyefinity技术，HD 7690M能够在理论上同时驱动多达5个显示器。请注意，这只会工作，如果笔记本电脑提供足够的DisplayPort输出开始。的HD 7690M的功耗应该是相似的Mobility Radeon HD 6750M，因此，通常在15英寸或更大尺寸的笔记本电脑更强大的散热解决方案。

Radeon HD 7600M Series

Radeon HD 7690M XT 480 @ 0.73 GHz128 Bit @ 3600 MHz
Radeon HD 7690M 480 @ 0.6 - 0.73 GHz128 Bit @ 3600/1800 MHz
Radeon HD 7660G + HD 7670M Dual Graphics 862 @ 0.69 GHz128 Bit @ 1800 MHz
Radeon HD 7640G + HD 7670M Dual Graphics 736 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7520G + HD 7670M Dual Graphics 736 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7670M 480 @ 0.6 GHz128 Bit @ 1800 MHz
Radeon HD 7650M 480 @ 0.45 - 0.55 GHz128 Bit @ 1800 MHz
Radeon HD 7630M 480 @ 0.45 GHz128 Bit @ 1800 MHz
Radeon HD 7640G + HD 7610M Dual Graphics 656 @ 0.66 GHz128 Bit @ 1800 MHz
Radeon HD 7610M 400 @ 0.45 GHz128 Bit @ 1600 MHz
CodenameThames XT / XTX
ArchitectureTerascale 2
Pipelines480 - unified
Core Speed600 - 725 (Boost) MHz
Memory Speed3600/1800 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5/DDR3
Shared Memoryno
APIDirectX 11, Shader 5.0, OpenGL 4.1
Transistor Count716 Million
technology40 nm
Notebook Sizemedium sized
Date of Announcement07.06.2011
Link to Manufacturer Pagewww.amd.com

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 1274     avg: 1306     median: 1306 (2%)     max: 1338 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
1141 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -85%
...
AMD Radeon HD 7660G
1057 -7%
AMD Radeon HD 6680G2
1061 -7%
AMD Radeon HD 6570M
1067 -6%
AMD Radeon HD 7670M
1079 -5%
NVIDIA Quadro K1000M
1102 -3%
AMD Radeon HD 6650M
1106 -3%
NVIDIA GeForce 710M
1107 -3%
Intel Iris Graphics 5100
1112 -3%
NVIDIA NVS 5400M
1119 -2%
AMD Radeon HD 7690M
1141
NVIDIA GeForce GT 720M
1143 0%
NVIDIA Quadro K610M
1144 0%
AMD Radeon HD 6750M
1147 1%
NVIDIA GeForce GT 445M
1148 1%
NVIDIA GeForce GT 635M
1152 1%
AMD Radeon R6 (Kaveri)
1161 2%
Intel UHD Graphics 615
1175 3%
NVIDIA GeForce GT 555M
1179 3%
AMD Radeon HD 8550G
1179 3%
...
AMD Radeon RX 7900M
59943 5154%
max:
NVIDIA GeForce RTX 4090
106023 9192%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 5558     avg: 5884     median: 5883.5 (2%)     max: 6209 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
5081 Points (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -99%
...
AMD Radeon R7 M440
4903 -4%
AMD Radeon HD 7640G + HD 7610M Dual Graphics
4937 -3%
AMD Radeon HD 6740G2
4956 -2%
NVIDIA GeForce 920M
5033 -1%
AMD Radeon R6 M255DX
5035 -1%
NVIDIA Quadro FX 2800M
5037 -1%
NVIDIA GeForce GT 735M
5058 0%
Intel HD Graphics 620
5059 0%
Intel Iris Graphics 5100
5072 0%
AMD Radeon HD 7690M
5081
AMD Radeon R7 (Bristol Ridge)
5111 1%
AMD Radeon HD 6850M
5142 1%
AMD Radeon HD 6770M
5150 1%
AMD Radeon R7 M360
5162 2%
Intel HD Graphics 530
5173 2%
Intel UHD Graphics 24EUs (Alder Lake-N)
5188 2%
NVIDIA GeForce 825M
5243 3%
NVIDIA GeForce GTX 280M
5243 3%
AMD Radeon HD 6620G + HD 7670M Dual Graphics
5324 5%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 2507%
max:
AMD Radeon RX 7900 XTX
170928 3264%
0%
100%
3DMark 03 - 3DMark 03 - Standard
26169 Points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
17784 Points (19%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
NVIDIA GeForce 8800M GTX SLI
16942 -5%
AMD Radeon HD 6850M
16944 -5%
Intel UHD Graphics 620
16972 -5%
NVIDIA GeForce 825M
17043 -4%
NVIDIA GeForce GT 640M
17105 -4%
ATI FirePro M7740
17192 -3%
NVIDIA GeForce 840M
17271 -3%
AMD Radeon 530
17513 -2%
AMD Radeon HD 7690M XT
17545 -1%
AMD Radeon HD 7690M
17784
ATI Mobility Radeon HD 5870
18044 1%
NVIDIA NVS 5400M
18136 2%
NVIDIA Quadro FX 3800M
18199 2%
NVIDIA GeForce GT 555M
18199 2%
NVIDIA GeForce GTX 280M
18414 4%
AMD Radeon HD 6950M
18466 4%
ATI Mobility Radeon HD 4870 X2
18522 4%
AMD Radeon HD 8870M
18829 6%
NVIDIA Quadro 5000M
18903 6%
...
AMD Radeon RX 7600M XT
68064 283%
max:
NVIDIA GeForce RTX 4080 Super
87172 390%
0%
100%
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
8988 points (12%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x1024 +
3DMark 06
9660 Points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
15.5 fps (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -96%
...
AMD Radeon HD 6720G2
14.8 -5%
AMD Radeon HD 6850M
14.9 -4%
NVIDIA GeForce GT 720M
15.1 -3%
AMD Radeon HD 6750M
15.23 -2%
AMD Radeon R5 M335
15.3 -1%
AMD Radeon R6 M340DX
15.3 -1%
Intel HD Graphics 4600
15.3 -1%
NVIDIA Quadro K1000M
15.4 -1%
Intel UHD Graphics (Jasper Lake 32 EU)
15.4 -1%
AMD Radeon HD 7690M
15.5
AMD FirePro M4100
15.6 1%
AMD Radeon R5 M430
15.9 3%
NVIDIA GeForce GT 445M
16.2 5%
NVIDIA GeForce 820M
16.4 6%
AMD Radeon HD 6770M
16.5 6%
NVIDIA GeForce GT 335M
16.5 6%
AMD Radeon R7 (Kaveri)
16.6 7%
AMD Radeon 520
16.6 7%
NVIDIA GeForce GT 630M
16.62 7%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 3332%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
6.9 Points (87%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
6.9 Points (87%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
7618 points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
43.8 fps (15%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Alan Wake

Alan Wake

2012
low 1024x768
43  fps    + Compare
med. 1366x768
30  fps    + Compare
ultra 1920x1080
14  fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
45  fps    + Compare
med. 1366x768
38  fps    + Compare
high 1366x768
28  fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings med..
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
154  fps    + Compare
med. 1366x768
68  fps    + Compare
high 1366x768
42  fps    + Compare
ultra 1920x1080
29  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2011

F1 2011

2011
low 800x600
90  fps    + Compare
med. 1024x768
55  fps    + Compare
high 1366x768
37  fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings high.
StarCraft 2

StarCraft 2

2010
low 1024x768
270  fps    + Compare
med. 1360x768
52  fps    + Compare
high 1360x768
38  fps    + Compare
ultra 1920x1080
24.4  fps    + Compare
» With all tested laptops playable in detail settings high.
Metro 2033

Metro 2033

2010
low 800x600
107  fps    + Compare
med. 1360x768
49  fps    + Compare
high 1600x900
25  fps    + Compare
ultra 1920x1080
8.4  fps    + Compare
» With all tested laptops playable in detail settings med..
lowmed.highultraQHD4K
Alan Wake433014
The Elder Scrolls V: Skyrim45382815
CoD: Modern Warfare 3154684229
F1 201190553715
StarCraft 2270523824.4
Metro 203310749258.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
2
2
2
5
1
2
3

6








For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 07. 01:01:47

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Thu, 04 Jul 2024 05:31:02 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.039s ... 0.04s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.04s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.041s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.041s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.041s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.042s

#9 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.042s

#10 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.042s

#11 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.042s

#12 composed specs +0s ... 0.042s

#13 did output specs +0s ... 0.042s

#14 start showIntegratedCPUs +0s ... 0.042s

#15 getting avg benchmarks for device 2812 +0.016s ... 0.058s

#16 got single benchmarks 2812 +0.013s ... 0.071s

#17 got avg benchmarks for devices +0s ... 0.071s

#18 min, max, avg, median took s +0.317s ... 0.387s

#19 before gaming benchmark output +0s ... 0.387s

#20 Got 23 rows for game benchmarks. +0.003s ... 0.391s

#21 composed SQL query for gamebenchmarks +0s ... 0.391s

#22 got data and put it in $dataArray +0.005s ... 0.395s

#23 benchmarks composed for output. +0.24s ... 0.635s

#24 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 0.638s

#25 return log +0s ... 0.638s

No reviews found for this graphics card.

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
SD X Adreno X1-85 4.6 TFLOPS GPU *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
SD X Adreno X1-85 3.8 TFLOPS GPU *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
Radeon Graphics (Ryzen 9000) *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon HD 7690M
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
