AMD Radeon HD 7730M

AMD Radeon HD 7730M

AMD Radeon HD 7730M的是中型笔记本电脑，定位于性能等级的DirectX 11显卡。这是制造在28nm和基于的GCN（图形核心下一页）架构。的Radeon HD 7730M尚未正式公布，因此像http://www.techarp.com/showarticle.aspx?artno=98&pgno=4的传闻和泄漏的信息仍然是基于设计的Radeon 7700M系列有它的根如发现佛得角的芯片，例如，在桌面上的Radeon HD 7750与512 1D着色器核心，32个纹理单元。但是，它有一个核心时脉只有575 - 675兆赫到800 MHz HD 7750。其结果是，功率消耗预计要低得多。而台式​​机版本支持PCIe 3.0，不7700M系列（AMD）。性能稍低的GeForce GT 640M的DDR3版本。因此，目前（2012年春季），并要求在中等或高设置在大多数情况下，游戏运行流利。的7730M的功能包括新的UVD3视频解码器，解码MPEG-4 AVC/H.264，VC-1，MPEG-2，Flash和现在也多视图编解码器（MVC）和MPEG-4第2部分（DIVX，XVID ）直接从AMD的​​GPU的高清视频。 7700M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛，这项技术取代了AMD的动态切换显卡，是类似于NVIDIA的Optimus。另外，7730M可以直接支持6个连接的显示器使用Eyefinity技术如果被禁用耐力赛。的7700M系列的其它特征包括ZeroCore为降低功耗，当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是其TDP范围内。例如，该芯片可以降频运行时的FurMark和OCCT，但会在某些游戏如“失落的星球”，“孤岛危机”，“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。此外，现在它可以同时并行多个设备的音频输出与新的离散数字多音频（DDMA）功能。消耗功率的7730M适合于15英寸的笔记本电脑或更大。

Radeon HD 7700M Series

Radeon HD 7770M 512 @ 0.68 GHz128 Bit @ 4000 MHz
Radeon HD 7750M 512 @ 0.58 GHz128 Bit @ 4000 MHz
Radeon HD 7730M 512 @ 0.58 - 0.68 GHz128 Bit @ 1800 MHz
CodenameLombok GL
ArchitectureGCN
Pipelines512 - unified
Core Speed575 - 675 (Boost) MHz
Memory Speed1800 MHz
Memory Bus Width128 Bit
Memory TypeDDR3
Shared Memoryno
APIDirectX 11.1, Shader 5.0, OpenGL 4.1
Power Consumption32 Watt
technology28 nm
Notebook Sizemedium sized
Date of Announcement24.04.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 1677     avg: 1684     median: 1684 (2%)     max: 1691 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
1478 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -88%
...
Intel HD Graphics 530
1355 -8%
AMD Radeon HD 8650G
1361 -8%
AMD Radeon HD 8730M
1371 -7%
Intel HD Graphics 6000
1372 -7%
NVIDIA GeForce 910M
1413 -4%
Intel HD Graphics 5600
1431 -3%
AMD Radeon R6 (Carrizo)
1452 -2%
Intel UHD Graphics (Jasper Lake 24 EU)
1458 -1%
AMD Radeon HD 6850M
1470 -1%
AMD Radeon HD 7730M
1478
AMD Radeon HD 6720G2
1479 0%
Intel HD Graphics 620
1499 1%
AMD Radeon HD 6755G2
1529 3%
NVIDIA Quadro 3000M
1539 4%
Intel UHD Graphics 617
1541 4%
Intel UHD Graphics 24EUs (Alder Lake-N)
1552 5%
AMD Radeon HD 6740G2
1577 7%
AMD Radeon HD 7640G + HD 7610M Dual Graphics
1583 7%
AMD Radeon R5 M240
1588 7%
...
AMD Radeon RX 7900M
59943 3956%
max:
NVIDIA GeForce RTX 4090
106023 7073%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 7002     avg: 7056     median: 7056 (2%)     max: 7110 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
5833 Points (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -99%
...
Intel UHD Graphics (Jasper Lake 32 EU)
5452 -7%
AMD FirePro M5950
5560 -5%
AMD Radeon HD 8650G + HD 8570M Dual Graphics
5573 -4%
AMD Radeon HD 7690M XT
5594 -4%
AMD Radeon HD 8550G + HD 8670M Dual Graphics
5595 -4%
NVIDIA GeForce GTX 285M
5631 -3%
NVIDIA Quadro K2000M
5698 -2%
Intel Iris Graphics 6100
5717 -2%
NVIDIA GeForce GT 740M
5735 -2%
AMD Radeon HD 7730M
5833
AMD Radeon HD 8730M
5870 1%
ATI FirePro M7740
5896 1%
NVIDIA Quadro FX 3800M
5926 2%
Intel UHD Graphics 620
5948 2%
NVIDIA GeForce 830M
5957 2%
AMD Radeon HD 8550G + HD 8750M Dual Graphics
5961 2%
AMD Radeon R7 M265
5977 2%
NVIDIA GeForce GT 730M
5987 3%
NVIDIA GeForce 8800M GTX SLI
5995 3%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 2171%
max:
AMD Radeon RX 7900 XTX
170928 2830%
0%
100%
3DMark 03 - 3DMark 03 - Standard
16656 Points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
16766 Points (18%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -99%
...
AMD Radeon RX Vega 10
16454 -2%
NVIDIA GeForce GT 550M
16510 -2%
AMD Radeon R7 M440
16534 -1%
NVIDIA Quadro 1000M
16583 -1%
Intel Iris Pro Graphics 5200
16590 -1%
NVIDIA GeForce 9800M GTX
16638 -1%
NVIDIA GeForce GT 735M
16640 -1%
NVIDIA GeForce GT 740M
16696 0%
NVIDIA GeForce GTS 360M
16712 0%
AMD Radeon HD 7730M
16766
NVIDIA GeForce GT 730M
16882 1%
NVIDIA Quadro FX 2800M
16936 1%
NVIDIA GeForce 8800M GTX SLI
16942 1%
AMD Radeon HD 6850M
16944 1%
Intel UHD Graphics 620
16972 1%
NVIDIA GeForce 825M
17043 2%
NVIDIA GeForce GT 640M
17105 2%
ATI FirePro M7740
17192 3%
NVIDIA GeForce 840M
17271 3%
...
NVIDIA GeForce RTX 4090 Laptop GPU
61850 269%
max:
NVIDIA GeForce RTX 4080 Super
87172 420%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
9615 Points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
6.6 Points (84%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
6.6 Points (84%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
5154 points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
20 fps (7%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Dirt Showdown

Dirt Showdown

2012
low 1024x768
74  fps    + Compare
med. 1366x768
45  fps    + Compare
high 1366x768
33  fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings med..
Diablo III

Diablo III

2012
med. 1366x768
51  fps    + Compare
high 1366x768
44  fps    + Compare
ultra 1920x1080
27  fps    + Compare
» With all tested laptops playable in detail settings high.
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
49  fps    + Compare
med. 1366x768
31  fps    + Compare
high 1366x768
23  fps    + Compare
ultra 1920x1080
12  fps    + Compare
» With all tested laptops playable in detail settings low.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
50  fps    + Compare
high 1366x768
36  fps    + Compare
ultra 1920x1080
25  fps    + Compare
» With all tested laptops playable in detail settings high.
Anno 2070

Anno 2070

2011
low 1024x768
110  fps    + Compare
med. 1366x768
58  fps    + Compare
high 1366x768
32  fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings med..
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
63  fps    + Compare
med. 1366x768
42  fps    + Compare
ultra 1920x1080
16  fps    + Compare
» With all tested laptops playable in detail settings med..
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
125  fps    + Compare
med. 1366x768
64  fps    + Compare
high 1366x768
41  fps    + Compare
ultra 1920x1080
25  fps    + Compare
» With all tested laptops playable in detail settings high.
Battlefield 3

Battlefield 3

2011
low 1024x768
47  fps    + Compare
med. 1366x768
32  fps    + Compare
high 1366x768
25  fps    + Compare
ultra 1920x1080
10  fps    + Compare
» With all tested laptops playable in detail settings low.
Batman: Arkham City

Batman: Arkham City

2011
low 1024x768
66  fps    + Compare
med. 1366x768
48  fps    + Compare
high 1366x768
36  fps    + Compare
ultra 1920x1080
16  fps    + Compare
» With all tested laptops playable in detail settings high.
F1 2011

F1 2011

2011
low 800x600
115  fps    + Compare
med. 1024x768
73  fps    + Compare
high 1366x768
38  fps    + Compare
ultra 1920x1080
18  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Dirt Showdown74453315
Diablo III514427
Risen 2: Dark Waters49312312
Mass Effect 3503625
Anno 2070110583215
The Elder Scrolls V: Skyrim634216
CoD: Modern Warfare 3125644125
Battlefield 347322510
Batman: Arkham City66483616
F1 2011115733818
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
3
5
1
7
2
2
7

10








For more games that might be playable and a list of all games and graphics cards visit our Gaming List
