AMD Radeon HD 7750M

AMD Radeon HD 7750M

AMD Radeon HD 7750M的是一个即将到来的DirectX 11性能级显卡的笔记本电脑。将被制造在28nm和基于GCN架构。在撰写本文时,所有的信息仍然是基于传闻。传闻的来源之一是提供下面的链接:http://www.techarp.com/showarticle.aspx?artno=98&pgno=4设计的Radeon 7700M系列佛得角的芯片,如发现有其根源,例如,512 1D着色器核心,32个纹理单元,在桌面上的Radeon HD 7750。但是,它有一个只有575 MHz的核心时钟频率相比HD 7750和800兆赫,675兆赫的7770M。其结果是,功率消耗预计要低得多。而台式​​机版本支持PCIe 3.0,不7700M系列(AMD)。的性能,应该是在旧的Radeon HD 6870M的范围内,因此,略低于Nvidia的的GeForce GT 650M的GDDR5。的7750M的功能包括新的UVD3视频解码器,解码MPEG-4 AVC/H.264,VC-1,MPEG-2,Flash和现在也多视图编解码器(MVC)和MPEG-4第2部分(DIVX,XVID )直接从AMD的​​GPU的高清视频。 7700M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛,这项技术取代了AMD的动态切换显卡,是类似于NVIDIA的Optimus。另外,7750M可以直接支持6个连接的显示器使用Eyefinity技术如果被禁用耐力赛。的7700M系列的其它特征包括ZeroCore为降低功耗,当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是其TDP范围内。例如,该芯片可以降频运行时的FurMark和OCCT,但会在某些游戏如“失落的星球”,“孤岛危机”,“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort(例如,蓝光视频)传输高清音频(TrueHD或DTS Master音频)。此外,现在它可以同时并行多个设备的音频输出与新的离散数字多音频(DDMA)功能。消耗功率的7750M应适合于15英寸的笔记本电脑或更大。

Radeon HD 7700M Series

Radeon HD 7770M 512 @ 0.68 GHz128 Bit @ 4000 MHz
Radeon HD 7750M 512 @ 0.58 GHz128 Bit @ 4000 MHz
Radeon HD 7730M 512 @ 0.58 - 0.68 GHz128 Bit @ 1800 MHz
CodenameLombok XL
ArchitectureGCN
Pipelines512 - unified
Core Speed575 MHz
Memory Speed4000 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Shared Memoryno
APIDirectX 11.1, Shader 5.0, OpenGL 4.1
Power Consumption36 Watt
technology28 nm
Notebook Sizemedium sized
Date of Announcement24.04.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
2382 Points (3%)
188.7 -92%
...
2251 -5%
2257 -5%
2305 -3%
2306 -3%
AMD Radeon HD 8650G + HD 8670M Dual Graphics
2317 -3%
2331 -2%
2335 -2%
Intel Iris Graphics 540
2340 -2%
NVIDIA GeForce GT 745M
2346 -2%
AMD Radeon HD 7750M
2382
2387 0%
AMD Radeon R8 M365DX
2389 0%
Intel UHD Graphics G1 (Ice Lake 32 EU)
2394 1%
2412 1%
2417 1%
AMD Radeon R7 M445
2422 2%
AMD Radeon R7 M340
2427 2%
2431 2%
Intel Iris Plus Graphics 640
2440 2%
...
41670 1649%
max:
59122 2382%
0%
100%
3DMark 11 - 3DM11 Performance GPU
2085 Points (2%)
171.8 -92%
...
Qualcomm Adreno 680
1936 -7%
AMD Radeon HD 8550G + HD 8670M Dual Graphics
1942 -7%
1969 -6%
1981 -5%
NVIDIA GeForce GT 740M
1985 -5%
2003 -4%
AMD Radeon HD 8650G + HD 8570M Dual Graphics
2004 -4%
AMD Radeon R7 M360
2014 -3%
2017 -3%
AMD Radeon HD 7750M
2085
2092 0%
2104 1%
2110 1%
2118 2%
2125 2%
2139 3%
2145 3%
Intel UHD Graphics G1 (Ice Lake 32 EU)
2171 4%
2185 5%
...
59943 2775%
max:
104201 4898%
0%
100%
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
