AMD Radeon HD 7850M

AMD Radeon HD 7850M

AMD Radeon HD 7850M的是一个28nm工艺的DirectX 11显卡的GCN架构(图形核心下一页)的根据。该系统主要为中大型笔记本电脑,显卡定位在2012年的表现类别。设计的Radeon 7800M系列佛得角的芯片,如发现有其根源,例如,在桌面上的Radeon HD 7770拥有640个1D着色器内核和40个纹理单元。然而,只有675 MHz的核心频率显着降低,也比较HD 7870M(800兆赫)。其结果是,性能的HD 7850M桌面HD 7750应该是相似的。 7850M是Nvidia的GeForce®(精视™)GTX 660M范围内,提供相似或略微改进的性能和类似的功耗。因此,当前(2012年春季)和要求苛刻的游戏应该运行流利的中或高设置。的7850M的功能包括新的UVD3视频解码器,解码MPEG-4 AVC/H.264,VC-1,MPEG-2,Flash和现在也多视图编解码器(MVC)和MPEG-4第2部分(DIVX,XVID )直接从AMD的​​GPU的高清视频。 7800M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛,这项技术取代了AMD的动态切换显卡,是类似于NVIDIA的Optimus。另外,7850M可以直接支持6个连接的显示器使用Eyefinity技术如果被禁用耐力赛。的7800M系列的其它特征包括ZeroCore为降低功耗,当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是其TDP范围内。例如,该芯片可以降频运行时的FurMark和OCCT,但会在某些游戏如“失落的星球”,“孤岛危机”,“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort(例如,蓝光视频)传输高清音频(TrueHD或DTS Master音频)。此外,现在它可以同时并行多个设备的音频输出与新的离散数字多音频(DDMA)功能。应该是明显低于7870M,7850M的功耗要感谢的核心时脉较低。

Radeon HD 7800M Series

Radeon HD 7870M 640 @ 0.8 GHz128 Bit @ 4000 MHz
Radeon HD 7850M 640 @ 0.68 GHz128 Bit @ 4000 MHz
CodenameHeathrow Pro
ArchitectureGCN
Pipelines640 - unified
Core Speed675 MHz
Memory Speed4000 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Shared Memoryno
APIDirectX 11.1, Shader 5.1, OpenGL 4.1
Power Consumption32 Watt
technology28 nm
Notebook Sizelarge
Date of Announcement24.04.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 2594     avg: 2760     median: 2760 (4%)     max: 2926 Points
3DMark 11 - 3DM11 Performance GPU
min: 2311     avg: 2467     median: 2467 (2%)     max: 2623 Points
171.8 -93%
...
AMD Radeon HD 8850M
2381 -3%
NVIDIA Quadro K2100M
2396 -3%
AMD Radeon HD 8650G + HD 8670M Dual Graphics
2398 -3%
NVIDIA GeForce 940M
2417 -2%
2422 -2%
2427 -2%
NVIDIA Quadro K620M
2434 -1%
Intel Iris Graphics 550
2435 -1%
2452 -1%
AMD Radeon HD 7850M
2467
AMD Radeon R7 M340
2492 1%
AMD Radeon 610M
2539 3%
NVIDIA GeForce GT 750M
2549 3%
NVIDIA Maxwell GPU Surface Book
2577 4%
2582 5%
2595 5%
2615 6%
2658 8%
AMD Radeon R6 M340DX
2681 9%
...
59943 2330%
max:
104201 4124%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
12254 Points (4%)
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
10701 Points (6%)
ATI Radeon HD 3200
62 -99%
...
10052 -6%
10067 -6%
AMD Radeon Pro WX 3100
10150 -5%
10211 -5%
10234 -4%
AMD Radeon 540X
10287 -4%
NVIDIA GeForce GTX 285M SLI
10511 -2%
10514 -2%
AMD FirePro M5100
10561 -1%
AMD Radeon HD 7850M
10701
10755 1%
10861 1%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
10953 2%
NVIDIA Quadro M600M
10958 2%
11019 3%
11047 3%
AMD Radeon RX Vega 9
11100 4%
AMD Radeon R9 M280X
11255 5%
11385 6%
...
132443 1138%
max:
170928 1497%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
14111 Points (18%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

For more games that might be playable and a list of all games and graphics cards visit our Gaming List
