AMD Radeon HD 7970M Crossfire

AMD Radeon HD 7970M Crossfire

AMD Radeon HD 7970M交火(有时也被称为了ATI Mobility Radeon HD 7970 X2)是一个组合的两个高端​​显卡的又大又重的笔记本电脑。一般,每个单卡呈现单个帧。因此,可能会受到微在低帧率为30fps的口吃。会发生这种情况,因为不同的时间跨度的两帧之间(例如,不规则的连续的帧之间的延迟)。 HD 7970M是基于桌面HD 7870皮特凯恩1D芯片与1280着色器和80个纹理单元。 GCN(图形核心下)架构支持的DirectX 11和OpenGL 4.2。此页面上可以找到更多信息的功能单一7970M。在交火模式的HD 7970M的性能明显高于GeForce®(精视™)GTX 580M SLI又名。 6.75亿SLI,几乎等同于GeForce®(精视™)GTX 680M SLI。现代和要求苛刻的游戏,像“战地3”,因此在高分辨率,最大可播放。设置和抗锯齿。 CF组合的功耗是非常高的(2个100瓦),因此只适用于非常大的台式机替代品笔记本电脑的显卡。

Radeon HD 7900M Series

Radeon HD 7970M Crossfire 2560 @ 0.85 GHz2x 256 Bit @ 4800 MHz
Radeon HD 7970M 1280 @ 0.85 GHz256 Bit @ 4800 MHz
Radeon HD 7950M 1280 @ 0.7 GHz256 Bit @ 4000 MHz
CodenameWimbledon XT
ArchitectureGCN
Pipelines2560 - unified
Core Speed850 MHz
Memory Speed4800 MHz
Memory Bus Width2x 256 Bit
Memory TypeGDDR5
Shared Memoryno
APIDirectX 11.1, Shader 5.0, OpenGL 4.2
Power Consumption200 Watt
technology28 nm
Notebook Sizelarge
Date of Announcement01.05.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
min: 9976     avg: 10179     median: 10179 (13%)     max: 10382 Points
3DMark 11 - 3DM11 Performance GPU
min: 11109     avg: 11119     median: 11119 (10%)     max: 11129 Points
171.8 -98%
...
AMD Radeon 680M
10018 -10%
AMD Radeon Pro WX Vega M GL
10020 -10%
NVIDIA Quadro M4000M
10259 -8%
10498 -6%
AMD Radeon Pro Vega 16
10569 -5%
10730 -3%
10774 -3%
10818 -3%
10952 -2%
AMD Radeon HD 7970M Crossfire
11119
11171 0%
11305 2%
11314 2%
NVIDIA Quadro T2000 Max-Q
11461 3%
11796 6%
NVIDIA Quadro M5000M
11893 7%
11915 7%
11949 7%
12066 9%
...
59943 439%
max:
104201 837%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 30783     avg: 31554     median: 31127 (9%)     max: 32751 Points
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 34491     avg: 35209     median: 35208.5 (19%)     max: 35926 Points
3DMark 03 - 3DMark 03 - Standard
150623 Points (79%)
3DMark 05 - 3DMark 05 - Standard
36878 Points (40%)
Intel Graphics Media Accelerator (GMA) 500
133.4 -100%
...
30785 -17%
31017 -16%
31647 -14%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
31699 -14%
32434 -12%
33386 -9%
35662 -3%
36523 -1%
AMD Radeon 610M
36628 -1%
AMD Radeon HD 7970M Crossfire
36878
NVIDIA GeForce GTX 1080 Mobile
37669 2%
AMD Radeon RX Vega 7
38073 3%
38999 6%
39066 6%
43138 17%
AMD Radeon 660M
43616 18%
AMD Radeon 680M
43633 18%
44877 22%
46269 25%
...
68064 85%
max:
87172 136%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 25798     avg: 27647     median: 27647 (36%)     max: 29496 Points
Unigine Heaven 2.1 - Heaven 2.1 high
151.3 fps (28%)
0.6 -100%
...
104 -31%
107.1 -29%
AMD FirePro W7170M
112.5 -26%
NVIDIA Quadro M3000M
114.5 -24%
120 -21%
AMD Radeon R9 M295X
125.9 -17%
135.1 -11%
149.7 -1%
150 -1%
AMD Radeon HD 7970M Crossfire
151.3
AMD Radeon HD 8970M Crossfire
154.3 2%
NVIDIA Quadro M5000M
155.3 3%
NVIDIA GeForce GTX 780M SLI
163.2 8%
164.2 9%
199.4 32%
NVIDIA GeForce GTX 1080 Mobile
224.2 48%
NVIDIA Quadro RTX 5000 Max-Q
236.1 56%
532 252%
0%
100%
Windows 7 Experience Index - Win7 Gaming graphics
7.9 Points (100%)
Windows 7 Experience Index - Win7 Graphics
7.9 Points (100%)
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
7660 points (5%)
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
83.3 fps (27%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

low 1024x768
85.1  fps    + Compare
med. 1366x768
87.1  fps    + Compare
high 1366x768
86.2  fps    + Compare
ultra 1920x1080
84.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
92.5  fps    + Compare
high 1366x768
87.5  fps    + Compare
ultra 1920x1080
84.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
242.7  fps    + Compare
high 1366x768
237.5  fps    + Compare
ultra 1920x1080
194.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
103.9  fps    + Compare
high 1366x768
80.6  fps    + Compare
ultra 1920x1080
43.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
high 1366x768
59.8  fps    + Compare
ultra 1920x1080
59.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Alan Wake

Alan Wake

2012
med. 1366x768
70.7  fps    + Compare
ultra 1920x1080
40.4  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Anno 2070

Anno 2070

2011
med. 1366x768
161.5  fps    + Compare
high 1366x768
102  fps    + Compare
ultra 1920x1080
52.8  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
84.7  fps    + Compare
high 1366x768
75.1  fps    + Compare
ultra 1920x1080
64.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
188.1  fps    + Compare
high 1366x768
187.1  fps    + Compare
ultra 1920x1080
157.5  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
141.2  fps    + Compare
high 1366x768
131  fps    + Compare
ultra 1920x1080
67.9  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1366x768
165  fps    + Compare
high 1366x768
97  fps    + Compare
ultra 1920x1080
61  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Fifa 12

Fifa 12

2011
med. 1024x768
393.5  fps    + Compare
high 1360x768
347.4  fps    + Compare
ultra 1920x1080
342.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2011

F1 2011

2011
med. 1024x768
90  fps    + Compare
high 1366x768
77  fps    + Compare
ultra 1920x1080
67  fps    + Compare
» With all tested laptops playable in detail settings ultra.
high 1366x768
205.7  fps    + Compare
ultra 1920x1080
147.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Crysis 2

Crysis 2

2011
med. 1024x768
100.2  fps    + Compare
high 1366x768
100.2  fps    + Compare
ultra 1920x1080
95.9  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1360x768
137.3  fps    + Compare
high 1360x768
136.2  fps    + Compare
ultra 1920x1080
119.9  fps    + Compare
» With all tested laptops playable in detail settings ultra.
med. 1360x768
145.4  fps    + Compare
high 1600x900
132.4  fps    + Compare
ultra 1920x1080
54.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
lowmed.highultraQHD4K
Max Payne 385.187.186.284.6
Dirt Showdown92.587.584.2
Diablo III242.7237.5194.2
Risen 2: Dark Waters103.980.643.2
Mass Effect 359.859.6
Alan Wake70.740.4
Anno 2070161.510252.8
The Elder Scrolls V: Skyrim84.775.164.2
CoD: Modern Warfare 3188.1187.1157.5
Battlefield 3141.213167.9
Batman: Arkham City1659761
Fifa 12393.5347.4342.2
F1 2011907767
Deus Ex Human Revolution205.7147.3
Crysis 2100.2100.295.9
StarCraft 2137.3136.2119.9
Metro 2033145.4132.454.3
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps


1


7
8

1
8
7

5
8
4






For more games that might be playable and a list of all games and graphics cards visit our Gaming List
