AMD Radeon HD 8550M

AMD Radeon HD 8550M

AMD Radeon HD8550M（有时也被称为了ATI Mobility Radeon HD8550）是DirectX11.1显卡的笔记本电脑。它最早出现在的，华硕VivoBook U38DT（超薄13.3英寸笔记本电脑），因此适合体积小，重量轻的笔记本电脑。芯片是基于新的28nm GCN核心，因此，有关的8600M和8700M系列。但是，内存总线的8550M是只有一半的宽度（64位和128位）的更高层次的模型。

Radeon HD 8500M Series

Radeon HD 8650G + HD 8570M Dual Graphics 768 @ 0.72 GHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8590M 384 @ 0.62 GHz64 Bit @ 4500 MHz
Radeon HD 8450G + Radeon HD 8570M Dual Graphics 576 @ 0.72 GHz64 Bit @ 1800 MHz
Radeon HD 8570M 384 @ 0.65 GHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8550M 384 @ 0.7 GHz64 Bit @ 1800 MHz
ArchitectureGCN
Pipelines384 - unified
Core Speed700 MHz
Memory Speed1800 MHz
Memory Bus Width64 Bit
Memory TypeDDR3
Shared Memoryno
APIDirectX 11.1, Shader 5.0
technology28 nm
Notebook Sizemedium sized
Date of Announcement16.11.2012

Benchmarks

3DMark 11 - 3DM11 Performance Score
1242 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
1307 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -87%
...
NVIDIA GeForce GT 555M
1179 -10%
AMD Radeon R5 M230
1203 -8%
AMD Radeon HD 8570M
1233 -6%
Intel HD Graphics 615
1233 -6%
AMD Radeon R5 (Stoney Ridge)
1245 -5%
NVIDIA GeForce 820M
1259 -4%
NVIDIA Quadro 2000M
1261 -4%
AMD Radeon HD 8670M
1286 -2%
Intel HD Graphics 520
1296 -1%
AMD Radeon HD 8550M
1307
AMD Radeon HD 6770M
1328 2%
AMD Radeon HD 7690M XT
1346 3%
NVIDIA GeForce GT 640M LE
1349 3%
AMD FirePro M5950
1350 3%
Intel HD Graphics 530
1355 4%
AMD Radeon HD 8650G
1361 4%
AMD Radeon HD 8730M
1371 5%
Intel HD Graphics 6000
1372 5%
NVIDIA GeForce 910M
1413 8%
...
AMD Radeon RX 7900M
59943 4486%
max:
NVIDIA GeForce RTX 4090
106023 8012%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
3705 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
3858 Points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -98%
...
AMD Radeon HD 8670M
3647 -5%
AMD Radeon R6 (Kaveri)
3677 -5%
NVIDIA Quadro 1000M
3679 -5%
NVIDIA GeForce 9800M GTS
3700 -4%
NVIDIA GeForce 9800M GT
3725 -3%
AMD Radeon HD 8550G
3741 -3%
AMD Radeon HD 8570M
3750 -3%
AMD Radeon HD 6730M
3752 -3%
Intel HD Graphics 5500
3804 -1%
AMD Radeon HD 8550M
3858
Intel HD Graphics 4600
3860 0%
NVIDIA GeForce GT 550M
3866 0%
NVIDIA GeForce GT 720M
3868 0%
AMD Radeon HD 7650M
3881 1%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
3968 3%
NVIDIA GeForce 710M
3969 3%
AMD Radeon R5 M430
3995 4%
NVIDIA GeForce GT 630M
4005 4%
AMD Radeon R5 M335
4032 5%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 3333%
max:
AMD Radeon RX 7900 XTX
170928 4330%
0%
100%
3DMark 03 - 3DMark 03 - Standard
15962 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
6008 Points (7%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -98%
...
ATI Mobility Radeon HD 5430
5509 -8%
AMD Radeon HD 8330
5598 -7%
ATI Mobility Radeon X1800
5600 -7%
NVIDIA GeForce 9500M G
5766 -4%
Intel UHD Graphics 605
5802 -3%
AMD Radeon HD 8450G
5908 -2%
NVIDIA GeForce Go 7900 GS
5937 -1%
ATI Mobility Radeon HD 4350
5953 -1%
ATI Mobility Radeon HD 2600
5997 0%
AMD Radeon HD 8550M
6008
ATI Mobility Radeon HD 4530
6141 2%
NVIDIA GeForce 8600M GT
6175 3%
ATI Mobility Radeon X800XT
6310 5%
ATI Mobility Radeon HD 5470
6330 5%
Intel UHD Graphics 600
6352 6%
Intel HD Graphics 3000
6355 6%
AMD Radeon HD 8400
6397 6%
AMD Radeon R4 (Beema)
6421 7%
NVIDIA NVS 2100M
6443 7%
...
NVIDIA GeForce RTX 4090 Laptop GPU
61850 929%
max:
NVIDIA GeForce RTX 4080 Super
87172 1351%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
4700 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
11.2 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
14.1 fps (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -96%
...
AMD Radeon HD 8670M
12.7 -10%
Intel HD Graphics 5000
12.97 -8%
NVIDIA GeForce GT 540M
13.48 -4%
Intel HD Graphics 510
13.5 -4%
NVIDIA NVS 5200M
13.65 -3%
AMD Radeon R5 M330
13.7 -3%
NVIDIA Quadro K610M
13.8 -2%
Intel HD Graphics 610
14 -1%
NVIDIA GeForce GT 635M
14.07 0%
AMD Radeon HD 8550M
14.1
NVIDIA GeForce GT 550M
14.45 2%
AMD Radeon R7 (Carrizo)
14.7 4%
AMD Radeon HD 6720G2
14.8 5%
AMD Radeon HD 6850M
14.9 6%
NVIDIA GeForce GT 720M
15.1 7%
AMD Radeon HD 6750M
15.23 8%
Intel HD Graphics 4600
15.3 9%
AMD Radeon R6 M340DX
15.3 9%
AMD Radeon R5 M335
15.3 9%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 3673%
0%
100%
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
22.6 fps (8%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Far Cry 3

Far Cry 3

2012
low 1024x768
15.4  fps    + Compare
med. 1366x768
15.3  fps    + Compare
high 1366x768
11  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Assassin´s Creed III

Assassin´s Creed III

2012
med. 1366x768
7.2  fps    + Compare
high 1366x768
6.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
11.1  fps    + Compare
med. 1366x768
9.4  fps    + Compare
high 1366x768
8.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Call of Duty: Black Ops 2

Call of Duty: Black Ops 2

2012
low 1024x768
36.6  fps    + Compare
med. 1366x768
28.6  fps    + Compare
high 1366x768
15.9  fps    + Compare
» With all tested laptops playable in detail settings low.
Need for Speed: Most Wanted

Need for Speed: Most Wanted

2012
low 1024x768
14.9  fps    + Compare
med. 1366x768
13.4  fps    + Compare
high 1366x768
9.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Medal of Honor: Warfighter

Medal of Honor: Warfighter

2012
low 1024x768
28.1  fps    + Compare
med. 1366x768
21.6  fps    + Compare
high 1366x768
16.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dishonored

Dishonored

2012
low 1024x768
32  fps    + Compare
med. 1366x768
29.4  fps    + Compare
high 1366x768
26.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 13

Fifa 13

2012
low 1024x768
58.7  fps    + Compare
med. 1366x768
43.5  fps    + Compare
high 1366x768
41.5  fps    + Compare
» With all tested laptops playable in detail settings high.
Borderlands 2

Borderlands 2

2012
low 1024x768
25.4  fps    + Compare
med. 1366x768
20.9  fps    + Compare
high 1366x768
16.7  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Guild Wars 2

Guild Wars 2

2012
low 1024x768
16.8  fps    + Compare
high 1366x768
7.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Counter-Strike: GO

Counter-Strike: GO

2012
low 1024x768
38.7  fps    + Compare
med. 1366x768
33.6  fps    + Compare
high 1366x768
29.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Darksiders II

Darksiders II

2012
med. 1366x768
31.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
22.1  fps    + Compare
med. 1366x768
15.5  fps    + Compare
high 1366x768
13.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Max Payne 3

Max Payne 3

2012
low 1024x768
11.2  fps    + Compare
med. 1366x768
10.5  fps    + Compare
high 1366x768
10  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt Showdown

Dirt Showdown

2012
low 1024x768
16.5  fps    + Compare
med. 1366x768
11.5  fps    + Compare
high 1366x768
10.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Diablo III

Diablo III

2012
low 1024x768
59.5  fps    + Compare
med. 1366x768
44.9  fps    + Compare
high 1366x768
34.4  fps    + Compare
» With all tested laptops playable in detail settings med..
Risen 2: Dark Waters

Risen 2: Dark Waters

2012
low 1024x768
10  fps    + Compare
med. 1366x768
17  fps    + Compare
high 1366x768
13.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Mass Effect 3

Mass Effect 3

2012
low 1280x720
30.2  fps    + Compare
high 1366x768
23.6  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Alan Wake

Alan Wake

2012
low 1024x768
20.6  fps    + Compare
med. 1366x768
12.8  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
56.4  fps    + Compare
med. 1366x768
25.6  fps    + Compare
high 1366x768
19.1  fps    + Compare
» With all tested laptops playable in detail settings low.
The Elder Scrolls V: Skyrim

The Elder Scrolls V: Skyrim

2011
low 1280x720
20.9  fps    + Compare
med. 1366x768
19  fps    + Compare
high 1366x768
15.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
CoD: Modern Warfare 3

CoD: Modern Warfare 3

2011
low 1024x768
44.6  fps    + Compare
med. 1366x768
30.1  fps    + Compare
high 1366x768
24  fps    + Compare
» With all tested laptops playable in detail settings low.
Battlefield 3

Battlefield 3

2011
low 1024x768
16.4  fps    + Compare
med. 1366x768
14.4  fps    + Compare
high 1366x768
13.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
lowmed.highultraQHD4K
Far Cry 315.415.311
Assassin´s Creed III7.26.8
Hitman: Absolution11.19.48.8
Call of Duty: Black Ops 236.628.615.9
Need for Speed: Most Wanted14.913.49.3
Medal of Honor: Warfighter28.121.616.5
Dishonored3229.426.7
Fifa 1358.743.541.5
Borderlands 225.420.916.7
Guild Wars 216.87.8
Counter-Strike: GO38.733.629.4
Darksiders II31.5
Sleeping Dogs22.115.513.5
Max Payne 311.210.510
Dirt Showdown16.511.510.4
Diablo III59.544.934.4
Risen 2: Dark Waters101713.1
Mass Effect 330.223.6
Alan Wake20.612.8
Anno 207056.425.619.1
The Elder Scrolls V: Skyrim20.91915.9
CoD: Modern Warfare 344.630.124
Battlefield 316.414.413.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		13
8

16
5

19
2










For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 26. 04:05:53

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Tue, 25 Jun 2024 05:31:39 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.038s ... 0.039s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.039s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.039s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.039s

#7 composed specs +0s ... 0.039s

#8 did output specs +0s ... 0.039s

#9 start showIntegratedCPUs +0s ... 0.039s

#10 getting avg benchmarks for device 3532 +0.014s ... 0.053s

#11 got single benchmarks 3532 +0.011s ... 0.064s

#12 got avg benchmarks for devices +0s ... 0.064s

#13 min, max, avg, median took s +0.223s ... 0.287s

#14 before gaming benchmark output +0s ... 0.287s

#15 Got 63 rows for game benchmarks. +0.005s ... 0.292s

#16 composed SQL query for gamebenchmarks +0s ... 0.292s

#17 got data and put it in $dataArray +0.014s ... 0.307s

#18 benchmarks composed for output. +0.603s ... 0.909s

#19 no comparison url found in template nbc.compare_page_1 needed +0.002s ... 0.912s

#20 return log +0s ... 0.912s

Notebook reviews with AMD Radeon HD 8550M graphics card

Toshiba Satellite S50D-A-10G: AMD A10-5745M, 15.60", 2.4 kg
  External Review » Toshiba Satellite S50D-A-10G

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
GeForce MX570 *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
SD X Adreno X1-85 GPU *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
SD X Adreno 3.8 TFLOPS GPU *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
Radeon Graphics (Ryzen 9000) *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
Radeon HD 8550M
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
