AMD Radeon HD 8570M

AMD Radeon HD 8570M

AMD Radeon HD 8570M（有时也被称为了ATI Mobility Radeon HD 8570）是为小型笔记本电脑的DirectX 11.1显卡。核心主频为650 MHz和能超频至700 MHz升压。主频为1000 MHz的DDR3绘图记忆体。火星核心的28nm使用GCN架构。在8570M到8600M和8700M系列相比，只有在时钟速度，内存总线的配置，内存类型是不同的。应稍低于老的Radeon HD 7650M的Radeon HD 8570M的性能。当前和要求苛刻的游戏，如“孤岛惊魂3流利只有在低的分辨率和细节设置。 384着色器可以使用与OpenCL 1.2通用计算的（8计算单位）。老万亿次芯片相比，基于GCN-火星的体系结构提供了更好的性能，在此框架内。特色的8570M包括通过UVD3视频解码进行解码的MPEG-4 AVC/H.264，VC-1，MPEG-2，和Flash直接从AMD GPU。多视图编解码器（MVC）和MPEG-4的第2部分（DIVX，XVID）的高清视频是目前兼容。 8500M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛，这项技术取代了AMD的动态切换显卡，是类似于NVIDIA的Optimus。另外，8570M可以直接支持2个连接显示器如果耐力赛被禁止使用Eyefinity技术。的8500M系列的其它特征包括ZeroCore为降低功耗，当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是在其TDP限制。例如，该芯片可以降频运行时的FurMark和OCCT，但会在某些游戏如“失落的星球”，“孤岛危机”，“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。此外，现在它可以同时并行多个设备的音频输出与新的离散数字多音频（DDMA）功能。应该稍微低于HD 7650M的功耗。其结果，适合于13英寸的笔记本电脑或更大8570M。

Radeon HD 8500M Series

Radeon HD 8650G + HD 8570M Dual Graphics 768 @ 0.72 GHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8590M 384 @ 0.62 GHz64 Bit @ 4500 MHz
Radeon HD 8450G + Radeon HD 8570M Dual Graphics 576 @ 0.72 GHz64 Bit @ 1800 MHz
Radeon HD 8570M 384 @ 0.65 GHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8550M 384 @ 0.7 GHz64 Bit @ 1800 MHz
ArchitectureGCN
Pipelines384 - unified
Core Speed650 MHz
Memory Speed1800 - 2000 MHz
Memory Bus Width64 Bit
Memory TypeDDR3
Shared Memoryno
APIDirectX 11.1, Shader 5.0
technology28 nm
Date of Announcement16.11.2012

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.4 pt (1%)
AMD Radeon HD 8180
0.06605 -82%
...
NVIDIA GeForce GT 630M
0.3275 -9%
ATI Mobility Radeon HD 5650
0.3325 -8%
NVIDIA GeForce GT 620M
0.336 -7%
NVIDIA Quadro K610M
0.3442 -4%
NVIDIA GeForce 710M
0.3501 -3%
AMD Radeon R6 (Kaveri)
0.351 -2%
AMD Radeon R5 M230
0.3512 -2%
AMD Radeon R5 (Stoney Ridge)
0.3517 -2%
AMD Radeon HD 6620G + HD 7670M Dual Graphics
0.354 -2%
AMD Radeon HD 8570M
0.3599
AMD Radeon HD 8550G
0.3608 0%
Intel HD Graphics 520
0.366 2%
Intel UHD Graphics 615
0.3731 4%
NVIDIA GeForce GT 720M
0.3744 4%
AMD Radeon HD 7670M
0.3754 4%
AMD Radeon HD 8670M
0.3776 5%
AMD Radeon HD 8650G + HD 8670M Dual Graphics
0.3849 7%
AMD Radeon R7 (Kaveri)
0.3877 8%
Intel HD Graphics 615
0.3886 8%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 5763%
max:
NVIDIA GeForce RTX 4090
33.3 9153%
0%
100%
3DMark - 3DMark Cloud Gate Score
min: 2140     avg: 3379     median: 3958 (4%)     max: 4039 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
min: 4835     avg: 4864     median: 4867 (1%)     max: 4889 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
min: 668     avg: 718     median: 732 (1%)     max: 753 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
min: 785     avg: 796     median: 790 (1%)     max: 813 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
min: 19735     avg: 38505     median: 40907 (5%)     max: 54874 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
min: 1305     avg: 1348     median: 1364 (2%)     max: 1374 Points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
min: 1190     avg: 1233     median: 1255 (1%)     max: 1255 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -86%
...
NVIDIA Quadro K610M
1144 -7%
AMD Radeon HD 6750M
1147 -7%
NVIDIA GeForce GT 445M
1148 -7%
NVIDIA GeForce GT 635M
1152 -7%
AMD Radeon R6 (Kaveri)
1161 -6%
Intel UHD Graphics 615
1175 -5%
AMD Radeon HD 8550G
1179 -4%
NVIDIA GeForce GT 555M
1179 -4%
AMD Radeon R5 M230
1203 -2%
AMD Radeon HD 8570M
1233
AMD Radeon R5 (Stoney Ridge)
1245 1%
NVIDIA GeForce 820M
1259 2%
NVIDIA Quadro 2000M
1261 2%
AMD Radeon HD 8670M
1286 4%
Intel HD Graphics 520
1296 5%
AMD Radeon HD 8550M
1307 6%
AMD Radeon HD 6770M
1328 8%
AMD Radeon HD 7690M XT
1346 9%
NVIDIA GeForce GT 640M LE
1349 9%
...
AMD Radeon RX 7900M
59943 4762%
max:
NVIDIA GeForce RTX 4090
106023 8499%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
4365 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
3750 Points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -98%
...
AMD Radeon HD 6720G2
3600 -4%
NVIDIA GeForce GT 620M
3610 -4%
Intel HD Graphics 5000
3639 -3%
AMD Radeon HD 8670M
3647 -3%
AMD Radeon R6 (Kaveri)
3677 -2%
NVIDIA Quadro 1000M
3679 -2%
NVIDIA GeForce 9800M GTS
3700 -1%
NVIDIA GeForce 9800M GT
3725 -1%
AMD Radeon HD 8550G
3741 0%
AMD Radeon HD 8570M
3750
AMD Radeon HD 6730M
3752 0%
Intel HD Graphics 5500
3804 1%
AMD Radeon HD 8550M
3858 3%
Intel HD Graphics 4600
3860 3%
NVIDIA GeForce GT 550M
3866 3%
NVIDIA GeForce GT 720M
3868 3%
AMD Radeon HD 7650M
3881 3%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
3968 6%
NVIDIA GeForce 710M
3969 6%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 3432%
max:
AMD Radeon RX 7900 XTX
170928 4458%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 5591     avg: 5650     median: 5650 (7%)     max: 5709 Points
+ 2 benchmarks and specifications   + Show comparison chart
SPECviewperf 12
specvp12 sw-03 +
SPECviewperf 12 - specvp12 sw-03
7.4 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 snx-02 +
SPECviewperf 12 - specvp12 snx-02
4.8 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 showcase-01 +
SPECviewperf 12 - specvp12 showcase-01
18.9 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 mediacal-01 +
SPECviewperf 12 - specvp12 mediacal-01
2.8 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 maya-04 +
SPECviewperf 12 - specvp12 maya-04
9.2 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 energy-01 +
SPECviewperf 12 - specvp12 energy-01
19.8 fps (18%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 creo-01 +
SPECviewperf 12 - specvp12 creo-01
12.1 fps (5%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 catia-04 +
SPECviewperf 12 - specvp12 catia-04
6.1 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 5672     avg: 6059     median: 5829 (4%)     max: 6677 points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 20.99     avg: 21.9     median: 21.3 (7%)     max: 23.29 fps
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
17 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Room GPU
154 Samples/s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
LuxMark v2.0 64Bit - LuxMark v2.0 Sala GPU
258 Samples/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

BioShock Infinite

BioShock Infinite

2013
low 1280x720
28.1  fps    + Compare
med. 1366x768
14.7  fps    + Compare
high 1366x768
12  fps    + Compare
ultra 1920x1080
4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft II: Heart of the Swarm

StarCraft II: Heart of the Swarm

2013
low 1024x768
150.7  fps    + Compare
med. 1366x768
29.7  fps    + Compare
high 1366x768
16.9  fps    + Compare
ultra 1920x1080
6.1  fps    + Compare
» With all tested laptops playable in detail settings low.
SimCity

SimCity

2013
low 1024x768
74.9 116 ~ 95 fps    + Compare
med. 1366x768
10.9 18 ~ 14 fps    + Compare
high 1366x768
8.4 14.5 ~ 11 fps    + Compare
ultra 1920x1080
4.3 10.5 ~ 7 fps    + Compare
» With all tested laptops playable in detail settings low.
Tomb Raider

Tomb Raider

2013
low 1024x768
36.3  fps    + Compare
med. 1366x768
17.8  fps    + Compare
high 1366x768
11.6  fps    + Compare
ultra 1920x1080
5.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis 3

Crysis 3

2013
low 1024x768
13.3  fps    + Compare
med. 1366x768
8.2  fps    + Compare
high 1366x768
5.7  fps    + Compare
ultra 1920x1080
2.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 13

Fifa 13

2012
low 1024x768
110.6 175.5 ~ 143 fps    + Compare
med. 1366x768
74.2 112 ~ 93 fps    + Compare
high 1366x768
58.6 101.5 ~ 80 fps    + Compare
ultra 1920x1080
36.1 52 ~ 44 fps    + Compare
» With all tested laptops playable in detail settings ultra.
Sleeping Dogs

Sleeping Dogs

2012
low 1024x768
29.5 33 ~ 31 fps    + Compare
med. 1366x768
21.5 25.7 ~ 24 fps    + Compare
high 1366x768
9.7 14.2 ~ 12 fps    + Compare
ultra 1920x1080
5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt Showdown

Dirt Showdown

2012
low 1024x768
59.4  fps    + Compare
med. 1366x768
29.4  fps    + Compare
high 1366x768
13.6  fps    + Compare
ultra 1920x1080
7  fps    + Compare
» With all tested laptops playable in detail settings low.
Anno 2070

Anno 2070

2011
low 1024x768
50.2  fps    + Compare
med. 1366x768
24.5  fps    + Compare
high 1366x768
19.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Civilization 5

Civilization 5

2010
low 1024x768
40  fps    + Compare
ultra 1920x1080
13  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro 2033

Metro 2033

2010
low 800x600
46.1  fps    + Compare
med. 1360x768
27.1  fps    + Compare
» With all tested laptops playable in detail settings low.
lowmed.highultraQHD4K
BioShock Infinite28.114.7124
StarCraft II: Heart of the Swarm150.729.716.96.1
SimCity9514117
Tomb Raider36.317.811.65.7
Crysis 313.38.25.72.3
Fifa 13143938044
Sleeping Dogs3124125
Dirt Showdown59.429.413.67
Anno 207050.224.519.5
Civilization 54013
Metro 203346.127.1
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		2
6
1
2		9

1
8

1
8
1







For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 02. 01:01:36

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Mon, 01 Jul 2024 05:31:08 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.036s ... 0.037s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.038s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.038s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.038s

#7 composed specs +0s ... 0.038s

#8 did output specs +0s ... 0.038s

#9 start showIntegratedCPUs +0s ... 0.038s

#10 getting avg benchmarks for device 3703 +0.028s ... 0.066s

#11 got single benchmarks 3703 +0.017s ... 0.083s

#12 got avg benchmarks for devices +0s ... 0.083s

#13 min, max, avg, median took s +0.516s ... 0.599s

#14 before gaming benchmark output +0s ... 0.599s

#15 Got 50 rows for game benchmarks. +0.005s ... 0.604s

#16 composed SQL query for gamebenchmarks +0s ... 0.604s

#17 got data and put it in $dataArray +0.007s ... 0.611s

#18 benchmarks composed for output. +0.425s ... 1.036s

#19 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.04s

#20 return log +0s ... 1.04s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
SD X Adreno X1-85 4.6 TFLOPS GPU *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
SD X Adreno X1-85 3.8 TFLOPS GPU *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
Radeon Graphics (Ryzen 9000) *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
Radeon HD 8570M
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
