AMD Radeon HD 8690M

AMD Radeon HD 8690M

AMD Radeon HD 8690M（有时也被称为了ATI Mobility Radeon HD 8690）是DirectX 11.1显卡的笔记本电脑。就像8500M和8700M系列，它是基于384着色器核心，24 TMUs，16个ROPs在火星上芯片（28nm制GCN架构）。核心主频为775 MHz（或增强）高达825 MHz的，并且可以访问GDDR5 VRAM（64位，1125兆赫）。的Radeon HD 8690M的性能应该是在范围内的GeForce GT 630M和Radeon HD 7670M。当前和要求苛刻的游戏，如“孤岛惊魂3流利的中低的分辨率和细节设置。 384着色器可以使用与OpenCL 1.2通用计算的（8计算单位）。老万亿次芯片相比，基于GCN-火星的体系结构提供了更好的性能，在此框架内。特色的8690M包括通过UVD3视频解码进行解码的MPEG-4 AVC/H.264，VC-1，MPEG-2，和Flash直接从AMD GPU。多视图编解码器（MVC）和MPEG-4的第2部分（DIVX，XVID）的高清视频是目前兼容。 8600M系列还支持集成的GPU和独立显卡之间的自动显卡切换。耐力赛，这项技术取代了AMD的动态切换显卡，是类似于NVIDIA的Optimus。另外，8690M可以直接支持2个连接显示器如果耐力赛被禁止使用Eyefinity技术。的8600M系列的其它特征包括ZeroCore为降低功耗，当显示器关闭和电源选通区域中未使用的芯片断电。 PowerTune允许的显卡的GPU自动超频和降频是在其TDP限制。例如，该芯片可以降频运行时的FurMark和OCCT，但会在某些游戏如“失落的星球”，“孤岛危机”，“生化危机5超频。集成的HD音频处理器能够通过HDMI和DisplayPort（例如，蓝光视频）传输高清音频（TrueHD或DTS Master音频）。此外，现在它可以同时并行多个设备的音频输出与新的离散数字多音频（DDMA）功能。的功耗范围内的旧HD 7670M。其结果，适合于13英寸的笔记本电脑或更大8690M。

Radeon HD 8600M Series

Radeon HD 8690M 384 @ 0.78 GHz64 Bit @ 4500 MHz
Radeon HD 8650M 384 @ 0.65 GHz64 Bit @ 4500 MHz
Radeon HD 8650G + HD 8670M Dual Graphics 768 @ 0.72 GHz64 Bit @ 1800 - 2000 MHz
Radeon HD 8550G + HD 8670M Dual Graphics 640 @ 0.72 GHz64 Bit @ 2000 MHz
Radeon HD 8670M 384 @ 0.78 GHz64 Bit @ 2000 MHz
ArchitectureGCN
Pipelines384 - unified
Core Speed775 MHz
Memory Speed4500 MHz
Memory Bus Width64 Bit
Memory TypeGDDR5
Max. Amount of Memory1024 MB
Shared Memoryno
APIDirectX 11.1, Shader 5.0
technology28 nm
Notebook Sizemedium sized
Date of Announcement16.11.2012

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.6 pt (2%)
AMD Radeon HD 8180
0.06605 -88%
...
NVIDIA GeForce GT 645M
0.525 -5%
NVIDIA GeForce 920M
0.529 -4%
Intel UHD Graphics 620
0.532 -3%
AMD Radeon RX Vega 3
0.534 -3%
AMD Radeon R7 M460
0.536 -3%
Intel UHD Graphics 24EUs (Alder Lake-N)
0.541 -2%
AMD Radeon R7 M440
0.546 -1%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
0.548 -1%
AMD Radeon R7 M340
0.551 0%
AMD Radeon HD 8690M
0.551
Intel UHD Graphics 630
0.552 0%
NVIDIA GeForce GT 640M
0.558 1%
AMD Radeon R7 M270
0.573 4%
AMD Radeon HD 8750M
0.581 5%
AMD Radeon R5 (Bristol Ridge)
0.585 6%
Intel UHD Graphics G7 (Lakefield GT2 64 EU)
0.59 7%
AMD Radeon HD 8550G + HD 8750M Dual Graphics
0.594 8%
AMD Radeon 520
0.601 9%
AMD Radeon R7 M265
0.609 11%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 3729%
max:
NVIDIA GeForce RTX 4090
33.3 5944%
0%
100%
3DMark - 3DMark Cloud Gate Score
6093 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
7930 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
1151 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
1210 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
69892 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
1790 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
1600 Points (1%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -89%
...
Intel HD Graphics 620
1499 -6%
AMD Radeon HD 6755G2
1529 -4%
NVIDIA Quadro 3000M
1539 -4%
Intel UHD Graphics 617
1541 -4%
Intel UHD Graphics 24EUs (Alder Lake-N)
1552 -3%
AMD Radeon HD 6740G2
1577 -1%
AMD Radeon HD 7640G + HD 7610M Dual Graphics
1583 -1%
AMD Radeon R5 M240
1588 -1%
AMD Radeon HD 8450G + Radeon HD 8570M Dual Graphics
1597 0%
AMD Radeon HD 8690M
1600
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
1602 0%
AMD Radeon HD 7520G + HD 7670M Dual Graphics
1621 1%
Intel UHD Graphics (Jasper Lake 32 EU)
1625 2%
NVIDIA GeForce GTX 460M
1628 2%
AMD Radeon R5 M320
1652 3%
Intel Iris Graphics 6100
1656 4%
AMD Radeon HD 7640G + HD 7670M Dual Graphics
1671 4%
AMD Radeon RX Vega 3
1674 5%
AMD Radeon R5 M330
1684 5%
...
AMD Radeon RX 7900M
59943 3646%
max:
NVIDIA GeForce RTX 4090
106023 6526%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
9413 Points (12%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
7043 points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
37.4 fps (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
41 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
95 % (95%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

GRID 2

GRID 2

2013
low 1024x768
101  fps    + Compare
med. 1366x768
52.3  fps    + Compare
high 1366x768
35.6  fps    + Compare
ultra 1920x1080
18.9  fps    + Compare
» With all tested laptops playable in detail settings high.
Metro: Last Light

Metro: Last Light

2013
low 1024x768
52.3  fps    + Compare
med. 1366x768
36  fps    + Compare
high 1366x768
28.6  fps    + Compare
ultra 1920x1080
19.3  fps    + Compare
» With all tested laptops playable in detail settings med..
Tomb Raider

Tomb Raider

2013
low 1024x768
59.9  fps    + Compare
med. 1366x768
33.6  fps    + Compare
high 1366x768
22.1  fps    + Compare
ultra 1920x1080
12.5  fps    + Compare
» With all tested laptops playable in detail settings low.
Crysis 3

Crysis 3

2013
low 1024x768
28.5  fps    + Compare
med. 1366x768
15.4  fps    + Compare
high 1366x768
10.3  fps    + Compare
ultra 1920x1080
6.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Diablo III

Diablo III

2012
low 1024x768
70.3  fps    + Compare
med. 1366x768
50.6  fps    + Compare
high 1366x768
40.1  fps    + Compare
ultra 1920x1080
29.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Anno 2070

Anno 2070

2011
low 1024x768
90.8  fps    + Compare
med. 1366x768
40.5  fps    + Compare
high 1366x768
25.4  fps    + Compare
ultra 1920x1080
13.4  fps    + Compare
» With all tested laptops playable in detail settings med..
lowmed.highultraQHD4K
GRID 210152.335.618.9
Metro: Last Light52.33628.619.3
Tomb Raider59.933.622.112.5
Crysis 328.515.410.36.5
Diablo III70.350.640.129.1
Anno 207090.840.525.413.4
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
2
3
1
5

4
2

6








For more games that might be playable and a list of all games and graphics cards visit our Gaming List
