AMD Radeon R9 M275

AMD Radeon R9 M275

AMD Radeon R9 M275是一款基于GCN(Graphics Core Next）架构支持DirectX 11的28纳米显卡。主要为大型笔记本设计的这款显卡，在2014年属于中高端市场范围。相比较老的Radeon HD 8870M，R9 M275提供了更高的920MHz主频，而显存频率仍为1125MHz（GDDR5，有效频率4500MHz）。不过，一些笔记本生产商选择了较慢的显存（经常为1000MHz、有效频率4000MHz）。


Radeon R9 M275的设计源自于Cape Verde芯片的设计，它用于如桌面式的Radeon HD 7770显卡，包含640个1D着色器核心和40个纹理单元。不过，相比HD 7770的1000MHz主频，8870M的频率仅为925MHz。


因此，R9 M275的性能相比HD 7770桌面显卡较低，与GeForce GTX 760M相当。大部分2014年的游戏可以在高设定和高分辨率下流畅运行，一些较老的游戏也可以开启AA/AF运行。在一些要求特别高的游戏如战地4中，为了获得流畅的帧率则必须选择中设定和1366x768的分辨率。


它的640个着色器核心支持OpenCL 1.2协议，可用于通用运算（作为10个运算单元）。

R9系列显卡包括一个新增的UVD3视频解码器，提供对MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash, Multi-View编码(MVC)和MPEG-4 part 2(DivX, xVid)高清视频的显卡硬解码。

Radeon R9也提供了在集成显卡和独立显卡间自动切换的支持。替代前代Dynamic Switchable Graphics的名为Enduro的新技术和Nvidia的Optimus技术很相似。另外，当Enduro功能禁用时，M275可以最多通过Eyefinity技术连接6个外部显示器。


其他的功能还包括了在显示器关闭时自动节能的ZeroCore技术，和在未使用时关闭显卡部分区域的Power Grating技术。PowerTune技术允许显卡在热设计功率允许的范围内自动超频或降频以适应使用需求。例如，当运行FurMark和OCCT时，显卡可能会自动降频，但当运行一些大型游戏时，则会自动超频。


集成的高清音频处理器可以通过HDMI或DisplayPort接口传输TrueHD或DTS Master Audio高清音频信号（例如当播放蓝光视频时）。另外，新增的对DDMA（Discrete Digital Multipoint Audio）技术的支持使得同时输出音频信号到多个设备成为了可能。


R9 M275的功耗约为60W。因此，这款显卡只适合于大尺寸笔记本或桌面式笔记本电脑。

注：上述数据传输率和时钟频率尚未得到AMD的官方确认。

Radeon R9 M200 Series

Radeon R9 M290X Crossfire 2560 @ 0.85 - 0.9 GHz2x 256 Bit @ 4800 MHz
Radeon R9 M295X 2048 @ 0.85 GHz256 Bit @ 5448 MHz
Radeon R9 M290X 1280 @ 0.85 - 0.9 GHz256 Bit @ 4800 MHz
Radeon R9 M280X 896 @ 0.9 - 1 GHz128 Bit @ 5500 MHz
Radeon R9 M275 640 @ 0.93 GHz128 Bit @ 4500 MHz
Radeon R9 M270 640 @ 0.73 GHz128 Bit @ 4500 MHz
Radeon R9 M265X 640 @ 0.63 GHz128 Bit @ 4000 MHz
ArchitectureGCN
Pipelines640 - unified
Core Speed925 MHz
Memory Speed4500 MHz
Memory Bus Width128 Bit
Memory TypeGDDR5
Max. Amount of Memory4 GB
Shared Memoryno
APIDirectX 12 (FL 11_1), Shader 5.0, OpenGL 4.2
Transistor Count1.5 Billion
technology28 nm
FeaturesOpenCL 1.2
Notebook Sizelarge
Date of Announcement01.08.2014

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
0.9 pt (3%)
AMD Radeon HD 8180
0.06605 -92%
...
AMD Radeon 610M
0.753 -12%
AMD FirePro M4000
0.78 -9%
NVIDIA GeForce MX110
0.781 -9%
AMD Radeon HD 8790M
0.787 -8%
AMD FirePro W4190M
0.795 -7%
NVIDIA GeForce GTX 660M
0.798 -7%
AMD Radeon R7 M370
0.802 -7%
AMD FirePro W4170M
0.804 -6%
AMD Radeon HD 8850M
0.84 -2%
AMD Radeon R9 M275
0.859
AMD Radeon R8 M365DX
0.866 1%
Intel Iris Pro Graphics 580
0.867 1%
AMD Radeon R7 M275DX
0.88 2%
NVIDIA GeForce GTX 670M
0.888 3%
Intel Iris Plus Graphics 655
0.903 5%
NVIDIA GeForce 940MX
0.909 6%
AMD Radeon R9 M265X
0.91 6%
NVIDIA Maxwell GPU Surface Book
0.945 10%
NVIDIA GeForce GT 755M
0.959 12%
...
NVIDIA GeForce RTX 4090 Laptop GPU
21.1 2356%
max:
NVIDIA GeForce RTX 4090
33.3 3777%
0%
100%
3DMark - 3DMark Ice Storm Unlimited Graphics
145646 Points (17%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Graphics
43808 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Score
5652 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
11459 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
1603 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
1885 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
58686 Points (7%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
3182 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
3261 Points (3%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -95%
...
Intel Iris Plus Graphics 645
2985 -8%
NVIDIA Quadro P500
3022 -7%
AMD Radeon RX Vega 6 (Ryzen 2000/3000)
3101 -5%
AMD FirePro W5130M
3106 -5%
NVIDIA GeForce GTX 580M
3131 -4%
Intel UHD Graphics Xe 32EUs (Tiger Lake-H)
3180 -2%
Intel Iris Pro Graphics 580
3220 -1%
AMD Radeon HD 6990M
3238 -1%
NVIDIA GeForce GTX 675M
3249 0%
AMD Radeon R9 M275
3261
Intel UHD Graphics Xe G4 48EUs
3288 1%
NVIDIA GeForce 945M
3310 2%
NVIDIA GeForce GTX 460M SLI
3313 2%
AMD Radeon R9 M375
3314 2%
NVIDIA GeForce GTX 760M
3392 4%
NVIDIA GeForce MX230
3392 4%
AMD Radeon RX Vega 8 (Ryzen 2000/3000)
3447 6%
Intel UHD Graphics 770
3456 6%
NVIDIA Quadro K4000M
3466 6%
...
AMD Radeon RX 7900M
59943 1738%
max:
NVIDIA GeForce RTX 4090
106023 3151%
0%
100%
3DMark 06 3DMark 06 - Standard 1280x1024 +
3DMark 06
10378 Points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
37.4 fps (7%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -98%
...
NVIDIA Quadro K3000M
34.1 -9%
NVIDIA GeForce MX130
35 -6%
AMD FirePro W5130M
36 -4%
AMD FirePro M6000
36.1 -3%
AMD Radeon RX Vega 5
36.2 -3%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU)
36.4 -3%
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
36.8 -2%
AMD Radeon Pro WX 3100
36.8 -2%
AMD Radeon HD 8870M
37 -1%
AMD Radeon R9 M275
37.4
NVIDIA GeForce GT 755M
37.5 0%
NVIDIA GeForce GTX 670M
37.81 1%
AMD FirePro M5100
39.1 5%
NVIDIA Quadro M520
39.5 6%
AMD Radeon RX 540
39.75 6%
NVIDIA GeForce 940MX
40.2 7%
NVIDIA GeForce GTX 485M
40.9 9%
AMD Radeon 540X
41.3 10%
NVIDIA Quadro 5010M
41.7 11%
...
NVIDIA Quadro RTX 5000 (Laptop)
532 1322%
0%
100%
SPECviewperf 11
specvp11 snx-01 +
SPECviewperf 11 - specvp11 snx-01
12.3 fps (7%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 tcvis-02 +
SPECviewperf 11 - specvp11 tcvis-02
3 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 sw-02 +
SPECviewperf 11 - specvp11 sw-02
13.7 fps (10%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 proe-05 +
SPECviewperf 11 - specvp11 proe-05
2.7 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 maya-03 +
SPECviewperf 11 - specvp11 maya-03
6.4 fps (5%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 lightwave-01 +
SPECviewperf 11 - specvp11 lightwave-01
14.6 fps (16%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 ensight-04 +
SPECviewperf 11 - specvp11 ensight-04
28 fps (13%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp11 catia-03 +
SPECviewperf 11 - specvp11 catia-03
5.4 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
41.6 fps (14%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
50.5 fps (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 OpenGL Ref. Match 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL Ref. Match 64 Bit
98 % (98%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

GRID: Autosport

GRID: Autosport

2014
low 1024x768
81.2  fps    + Compare
med. 1366x768
42.9  fps    + Compare
high 1920x1080
31.1  fps    + Compare
ultra 1920x1080
18.7  fps    + Compare
» With all tested laptops playable in detail settings med..
Thief

Thief

2014
low 1024x768
26.8  fps    + Compare
med. 1366x768
22.6  fps    + Compare
high 1366x768
19.3  fps    + Compare
ultra 1920x1080
10.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 14

Fifa 14

2013
low 1024x768
200.3  fps    + Compare
med. 1366x768
113.2  fps    + Compare
high 1366x768
106.2  fps    + Compare
ultra 1920x1080
74.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Company of Heroes 2

Company of Heroes 2

2013
low 1024x768
39.2  fps    + Compare
med. 1366x768
34.9  fps    + Compare
high 1366x768
23.7  fps    + Compare
ultra 1920x1080
9.7  fps    + Compare
» With all tested laptops playable in detail settings low.
Metro: Last Light

Metro: Last Light

2013
low 1024x768
38  fps    + Compare
med. 1366x768
29.7  fps    + Compare
high 1366x768
26.3  fps    + Compare
ultra 1920x1080
13.4  fps    + Compare
» With all tested laptops playable in detail settings low.
BioShock Infinite

BioShock Infinite

2013
low 1280x720
88.2  fps    + Compare
med. 1366x768
52  fps    + Compare
high 1366x768
42.8  fps    + Compare
ultra 1920x1080
14.4  fps    + Compare
» With all tested laptops playable in detail settings high.
Tomb Raider

Tomb Raider

2013
low 1024x768
122.5  fps    + Compare
med. 1366x768
62.9  fps    + Compare
high 1366x768
44.1  fps    + Compare
ultra 1920x1080
25.2  fps    + Compare
» With all tested laptops playable in detail settings high.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
40  fps    + Compare
med. 1366x768
36.5  fps    + Compare
high 1366x768
20.7  fps    + Compare
ultra 1920x1080
10.5  fps    + Compare
» With all tested laptops playable in detail settings med..
Anno 2070

Anno 2070

2011
low 1024x768
135.9  fps    + Compare
med. 1366x768
70.3  fps    + Compare
high 1366x768
44.2  fps    + Compare
ultra 1920x1080
21.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Dirt 3

Dirt 3

2011
low 800x600
82.7  fps    + Compare
med. 1024x768
75.6  fps    + Compare
high 1360x768
50.5  fps    + Compare
ultra 1920x1080
30.3  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
GRID: Autosport81.242.931.118.7
Thief26.822.619.310.5
Fifa 14200.3113.2106.274.2
Company of Heroes 239.234.923.79.7
Metro: Last Light3829.726.313.4
BioShock Infinite88.25242.814.4
Tomb Raider122.562.944.125.2
Hitman: Absolution4036.520.710.5
Anno 2070135.970.344.221.1
Dirt 382.775.650.530.3
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
3
3
3		2
4
4
4
5
1
8
1
1






For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 05. 04:42:14

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Thu, 04 Jul 2024 05:31:02 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_1 needed +0.046s ... 0.047s

#4 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.047s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.047s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.047s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.047s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.047s

#9 composed specs +0s ... 0.047s

#10 did output specs +0s ... 0.047s

#11 start showIntegratedCPUs +0s ... 0.047s

#12 getting avg benchmarks for device 5934 +0.027s ... 0.074s

#13 got single benchmarks 5934 +0.008s ... 0.083s

#14 got avg benchmarks for devices +0s ... 0.083s

#15 min, max, avg, median took s +0.471s ... 0.553s

#16 before gaming benchmark output +0s ... 0.553s

#17 Got 40 rows for game benchmarks. +0.005s ... 0.559s

#18 composed SQL query for gamebenchmarks +0s ... 0.559s

#19 got data and put it in $dataArray +0.007s ... 0.566s

#20 benchmarks composed for output. +0.406s ... 0.972s

#21 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 0.975s

#22 return log +0s ... 0.975s

Please share our article, every link counts!

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

NVIDIA GeForce RTX 4090 Laptop GPU
NVIDIA RTX 5000 Ada Generation Laptop GPU
Radeon RX 7900M
NVIDIA GeForce RTX 4080 Laptop GPU
NVIDIA RTX 4000 Ada Generation Laptop GPU
NVIDIA RTX 3500 Ada Generation Laptop GPU
GeForce RTX 3080 Ti Laptop GPU
NVIDIA GeForce RTX 4070 Laptop GPU
NVIDIA RTX 3000 Ada Generation Laptop GPU
RTX A5500 Laptop GPU
GeForce RTX 3080 Laptop GPU
Radeon RX 6850M XT
GeForce RTX 3070 Ti Laptop GPU
RTX A4500 Laptop GPU
RTX A5000 Laptop GPU
NVIDIA GeForce RTX 4060 Laptop GPU
NVIDIA RTX 2000 Ada Generation Laptop GPU
Quadro RTX 6000 (Laptop)
Radeon RX 6800M
GeForce RTX 2080 Super Mobile
GeForce RTX 3070 Laptop GPU
RTX A4000 Laptop GPU *

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Radeon Pro WX 7100 *
Radeon RX 570X (Laptop) *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Radeon 890M *
Quadro T1000 (Laptop) *
Quadro T1000 Max-Q *
A310 *
Arc 8-Core *
A350M *
Arc 7-Core *
T600 Laptop GPU *
T550 Laptop GPU *

Class 3

GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
SD X Adreno X1-85 4.6 TFLOPS GPU *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
SD X Adreno X1-85 3.8 TFLOPS GPU *
Radeon 760M *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Radeon R9 M275
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
Radeon Graphics (Ryzen 9000) *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
UHD Graphics G7 (Lakefield GT2 64 EU)
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100
UHD Graphics G4 (Lakefield GT1 48 EU) *

Class 4

UHD Graphics 730
Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
HD Graphics 5300
Radeon R4 (Stoney Ridge)
Radeon R5 (Beema/Carrizo-L)
Radeon R4 (Beema)
Radeon R3 (Mullins/Beema)
Radeon R2 (Stoney Ridge)
HD Graphics (Broadwell)
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

Radeon R2 (Mullins/Beema/Carrizo-L)
Radeon R6 (Mullins)

* Approximate position of the graphics adapter
