AMD Radeon R9 M290X Crossfire

AMD Radeon R9 M290X Crossfire

AMD Radeon R9 M290X Crossfire（常称为CF或CrossFireX），是用于大型笔记本电脑的两块高端显卡的组合设置模式。通常，每块R9 M290X交替渲染间隔的帧。因此，它可能在较低帧数下（30fps）有“微卡帧”的情况。这个现象源自两个相邻帧间的时间间隔出现误差（例如在帧序列间出现的不规则延迟）。相比Radeon HD 8970M CF，R9 M290X CF提供了相同数量的着色器和同样的时钟频率。 R9 M290X显卡是基于桌面型的HD 7870 Pitcairn芯片架构，包含1280个1D着色器，和80个纹理单元。GCN（graphics core next，次代图形核心）架构提供了对DirectX 11.2（仅Tier 1）和OpenGL 4.3的支持。关于显卡特性的更多信息请参见我们的独立R9 M290X显卡页面。 性能 两块设置在CF模式下的R9 M290X图形芯片的性能仅仅略低于Nvidia GeForce GTX 780M SLI的性能，但无法与GTX 880M SLI的性能相抗衡。不过，最新的高配置需求的像是《战地4》或《地铁：最后的曙光》仍然可以在最高分辨率、最高细节设置和抗锯齿开启模式下运行。 特性 M290X的特性包括一个新增的UVD3视频解码器，提供对MPEG-4 AVC/H.264, VC-1, MPEG-2, Flash, Multi-View编码(MVC)和MPEG-4 part 2(DivX, xVid)高清视频的显卡硬解码。 M290系列也提供了对在集成显卡和独立显卡间自动切换的支持。替代前代Dynamic Switchable Graphics的新Enduro技术和Nvidia的Optimus技术很相似。另外，当Enduro功能禁用时，每块M290X可以最多通过Eyefinity技术连接6个外部显示器。 其他的功能还包括了在显示器关闭时自动节能的ZeroCore技术。但根据AMD提供的信息，它并不支持Power Grating技术。PowerTune技术允许显卡在热设计功率允许的范围内自动超频或降频以适应使用需求。例如，当运行FurMark和OCCT时，先卡可能会自动降频，但当运行大型游戏例如失落的星球，孤岛危机，或者生化危机时，则会自动超频。 集成的高清音频处理器可以通过HDMI或DisplayPort接口传输TrueHD或DTS Master Audio高清音频信号（例如当播放蓝光视频时）。另外，新增的对DDMA（Discrete Digital Multipoint Audio）技术的支持使得同时输出音频信号到多个设备成为了可能。 功耗 CF设置下的显卡功耗非常高（2x 100W）因此只适合大型的桌面型笔记本电脑。

Radeon R9 M200 Series

Radeon R9 M290X Crossfire 2560 @ 0.85 - 0.9 GHz2x 256 Bit @ 4800 MHz
Radeon R9 M295X 2048 @ 0.85 GHz256 Bit @ 5448 MHz
Radeon R9 M290X 1280 @ 0.85 - 0.9 GHz256 Bit @ 4800 MHz
Radeon R9 M280X 896 @ 0.9 - 1 GHz128 Bit @ 5500 MHz
Radeon R9 M275 640 @ 0.93 GHz128 Bit @ 4500 MHz
Radeon R9 M270 640 @ 0.73 GHz128 Bit @ 4500 MHz
Radeon R9 M265X 640 @ 0.63 GHz128 Bit @ 4000 MHz
CodenameNeptune CF
ArchitectureGCN
Pipelines2560 - unified
Core Speed850 - 900 (Boost) MHz
Memory Speed4800 MHz
Memory Bus Width2x 256 Bit
Memory TypeGDDR5
Max. Amount of Memory2x 4096 MB
Shared Memoryno
APIDirectX 12 (FL 11_1), Shader 5.0, OpenGL 4.3
Power Consumption200 Watt
Transistor Count0 Billion
technology28 nm
Notebook Sizelarge
Date of Announcement01.03.2014

Benchmarks

Performance Rating - 3DMark 11 + Fire Strike + Time Spy
4.7 pt (14%)
AMD Radeon HD 8180
0.06404 -99%
...
NVIDIA GeForce GTX 1650 Mobile
4.11 -12%
AMD Radeon 890M
4.23 -9%
NVIDIA GeForce GTX 980M
4.28 -8%
NVIDIA GeForce GTX 1650 Ti Mobile
4.39 -6%
NVIDIA GeForce GTX 780M SLI
4.46 -4%
NVIDIA GeForce GTX 965M SLI
4.51 -3%
AMD Radeon RX Vega M GH
4.53 -3%
AMD Radeon HD 8970M Crossfire
4.57 -2%
NVIDIA GeForce GTX 1060 Max-Q
4.61 -1%
AMD Radeon R9 M290X Crossfire
4.66
AMD Radeon RX 580 (Laptop)
4.97 7%
NVIDIA GeForce GTX 1060 Mobile
5.1 9%
NVIDIA GeForce GTX 880M SLI
5.22 12%
NVIDIA GeForce RTX 3050 6GB Laptop GPU
5.28 13%
NVIDIA GeForce RTX 3050 4GB Laptop GPU
5.28 13%
NVIDIA Quadro P4000
5.41 16%
AMD Radeon RX 5500M
5.42 16%
NVIDIA Quadro P3200
5.55 19%
NVIDIA GeForce GTX 980 (Laptop)
5.76 24%
...
NVIDIA GeForce RTX 4090 Laptop GPU
20.4 338%
max:
NVIDIA GeForce RTX 4090
33.3 615%
0%
100%
3DMark - 3DMark Cloud Gate Score
22183 Points (21%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Graphics
71977 Points (18%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Score
8176 Points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Graphics
10551 Points (12%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Graphics
284150 Points (31%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Score
11503 Points (15%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance GPU
14147 Points (12%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 6250
171.8 -99%
...
NVIDIA GeForce GTX 1650 Mobile
12797 -10%
NVIDIA GeForce RTX 2050 Mobile
12801 -10%
AMD Radeon HD 8970M Crossfire
13160 -7%
NVIDIA GeForce GTX 1650 Ti Mobile
13515 -4%
NVIDIA Quadro T2000 (Laptop)
13524 -4%
NVIDIA GeForce GTX 1060 Max-Q
13581 -4%
NVIDIA T1200 Laptop GPU
13714 -3%
AMD Radeon 880M
14014 -1%
NVIDIA GeForce GTX 780M SLI
14140 0%
AMD Radeon R9 M290X Crossfire
14147
AMD Radeon RX Vega M GH
14302 1%
AMD Radeon RX 5300M
14412 2%
NVIDIA GeForce GTX 965M SLI
14428 2%
NVIDIA GeForce GTX 1060 Mobile
14692 4%
AMD Radeon Pro 5500M
14725 4%
NVIDIA RTX A1000 Laptop GPU
15135 7%
AMD Radeon RX 580 (Laptop)
15223 8%
NVIDIA Quadro P4000
15433 9%
NVIDIA GeForce RTX 3050 4GB Laptop GPU
15592 10%
...
AMD Radeon RX 7900M
59943 324%
max:
NVIDIA GeForce RTX 4090
104201 637%
0%
100%
3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
32792 Points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
37644 Points (21%)
+ 1 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -100%
...
NVIDIA GeForce GTX 1660 Ti Max-Q
34951 -7%
AMD Radeon HD 7970M Crossfire
35209 -6%
AMD Radeon 780M
35269 -6%
NVIDIA GeForce GTX 980M
35807 -5%
Intel Arc 8-Core iGPU
36137 -4%
NVIDIA GeForce GTX 680M SLI
36214 -4%
AMD Radeon RX 5300M
36391 -3%
NVIDIA Quadro P3000
36405 -3%
NVIDIA Quadro T2000 Max-Q
36812 -2%
AMD Radeon R9 M290X Crossfire
37644
AMD Radeon 890M
37785 0%
Intel Arc Graphics 140V
38502 2%
NVIDIA GeForce GTX 1060 Mobile
38910 3%
AMD Radeon HD 8970M Crossfire
39191 4%
Intel Arc A310
39213 4%
NVIDIA RTX A500 Laptop GPU
39319 4%
NVIDIA GeForce GTX 1070 Mobile
40134 7%
Intel Arc Graphics 130V
40146 7%
NVIDIA GeForce GTX 1650 Ti Mobile
40643 8%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 252%
max:
AMD Radeon RX 7900 XTX
170928 354%
0%
100%
Unigine Heaven 3.0 - Unigine Heaven 3.0 DX 11
122.1 fps (40%)
+ 1 benchmarks and specifications   + Show comparison chart
Unigine Heaven 2.1 - Heaven 2.1 high
150 fps (28%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD Radeon HD 7310
0.6 -100%
...
NVIDIA GeForce GTX 1050 Max-Q
101.2 -33%
NVIDIA GeForce GTX 880M
104 -31%
NVIDIA GeForce GTX 860M SLI
107.1 -29%
AMD FirePro W7170M
112.5 -25%
NVIDIA Quadro M3000M
114.5 -24%
NVIDIA GeForce GTX 1650 Mobile
120 -20%
AMD Radeon R9 M295X
125.9 -16%
NVIDIA GeForce GTX 680M SLI
135.1 -10%
NVIDIA Quadro T1000 (Laptop)
149.7 0%
AMD Radeon R9 M290X Crossfire
150
AMD Radeon HD 7970M Crossfire
151.3 1%
AMD Radeon HD 8970M Crossfire
154.3 3%
NVIDIA Quadro M5000M
155.3 4%
NVIDIA GeForce GTX 780M SLI
163.2 9%
NVIDIA GeForce GTX 880M SLI
164.2 9%
NVIDIA Quadro RTX 3000 (Laptop)
199.4 33%
NVIDIA GeForce GTX 1080 Mobile
224.2 49%
NVIDIA Quadro RTX 5000 Max-Q
236.1 57%
NVIDIA Quadro RTX 5000 (Laptop)
532 255%
0%
100%
SPECviewperf 12
specvp12 sw-03 +
SPECviewperf 12 - specvp12 sw-03
51.3 fps (13%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 snx-02 +
SPECviewperf 12 - specvp12 snx-02
14.5 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 showcase-01 +
SPECviewperf 12 - specvp12 showcase-01
33.8 fps (7%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 mediacal-01 +
SPECviewperf 12 - specvp12 mediacal-01
17.7 fps (5%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 maya-04 +
SPECviewperf 12 - specvp12 maya-04
41 fps (11%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 energy-01 +
SPECviewperf 12 - specvp12 energy-01
2.3 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 creo-01 +
SPECviewperf 12 - specvp12 creo-01
31.9 fps (13%)
+ 1 benchmarks and specifications   + Show comparison chart
specvp12 catia-04 +
SPECviewperf 12 - specvp12 catia-04
48.5 fps (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
90.9 fps (30%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15
Cinebench R15 OpenGL 64 Bit +
Cinebench R15 - Cinebench R15 OpenGL 64 Bit
100.4 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Thief

Thief

2014
low 1024x768
60.3  fps    + Compare
med. 1366x768
57.3  fps    + Compare
high 1366x768
57  fps    + Compare
ultra 1920x1080
52.1  fps    + Compare
» With all tested laptops playable in detail settings ultra.
X-Plane 10.25

X-Plane 10.25

2013
low 1024x768
70.8  fps    + Compare
med. 1366x768
43.1  fps    + Compare
high 1366x768
21.5  fps    + Compare
ultra 1920x1080
17  fps    + Compare
» With all tested laptops playable in detail settings med..
Call of Duty: Ghosts

Call of Duty: Ghosts

2013
low 1024x768
53.2  fps    + Compare
med. 1366x768
50.1  fps    + Compare
high 1366x768
37.4  fps    + Compare
ultra 1920x1080
27.1  fps    + Compare
» With all tested laptops playable in detail settings high.
Battlefield 4

Battlefield 4

2013
low 1024x768
152.4  fps    + Compare
med. 1366x768
132.2  fps    + Compare
high 1366x768
120.6  fps    + Compare
ultra 1920x1080
77.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
F1 2013

F1 2013

2013
low 1024x768
118  fps    + Compare
med. 1366x768
98  fps    + Compare
high 1366x768
96  fps    + Compare
ultra 1920x1080
86  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Saints Row IV

Saints Row IV

2013
low 1280x720
67  fps    + Compare
med. 1366x768
55.9  fps    + Compare
high 1366x768
50.2  fps    + Compare
ultra 1920x1080
48.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Dota 2

Dota 2

2013
low 1024x768
119.2  fps    + Compare
med. 1366x768
116.6  fps    + Compare
ultra 1920x1080
109.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
GRID 2

GRID 2

2013
low 1024x768
192.9  fps    + Compare
med. 1366x768
134  fps    + Compare
high 1366x768
119  fps    + Compare
ultra 1920x1080
108.3  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Metro: Last Light

Metro: Last Light

2013
low 1024x768
97.4  fps    + Compare
med. 1366x768
91.9  fps    + Compare
high 1366x768
80.3  fps    + Compare
ultra 1920x1080
52.6  fps    + Compare
» With all tested laptops playable in detail settings ultra.
BioShock Infinite

BioShock Infinite

2013
low 1280x720
173.4  fps    + Compare
med. 1366x768
152.6  fps    + Compare
high 1366x768
145.5  fps    + Compare
ultra 1920x1080
85  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Tomb Raider

Tomb Raider

2013
low 1024x768
379.1  fps    + Compare
med. 1366x768
353.2  fps    + Compare
high 1366x768
295.9  fps    + Compare
ultra 1920x1080
127.2  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Crysis 3

Crysis 3

2013
low 1024x768
120.8  fps    + Compare
med. 1366x768
107.7  fps    + Compare
high 1366x768
86.6  fps    + Compare
ultra 1920x1080
38  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Far Cry 3

Far Cry 3

2012
low 1024x768
106.6  fps    + Compare
med. 1366x768
102.6  fps    + Compare
high 1366x768
81.3  fps    + Compare
ultra 1920x1080
54.1  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Hitman: Absolution

Hitman: Absolution

2012
low 1024x768
73.8  fps    + Compare
med. 1366x768
69.7  fps    + Compare
high 1366x768
62.2  fps    + Compare
ultra 1920x1080
59.5  fps    + Compare
» With all tested laptops playable in detail settings ultra.
Guild Wars 2

Guild Wars 2

2012
low 1024x768
52.2  fps    + Compare
high 1366x768
36.3  fps    + Compare
ultra 1920x1080
32.9  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Thief60.357.35752.1
X-Plane 10.2570.843.121.517
Call of Duty: Ghosts53.250.137.427.1
Battlefield 4152.4132.2120.677.2
F1 2013118989686
Saints Row IV6755.950.248.6
Dota 2119.2116.6109.6
GRID 2192.9134119108.3
Metro: Last Light97.491.980.352.6
BioShock Infinite173.4152.6145.585
Tomb Raider379.1353.2295.9127.2
Crysis 3120.8107.786.638
Far Cry 3106.6102.681.354.1
Hitman: Absolution73.869.762.259.5
Guild Wars 252.236.332.9
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
2
8
5
4
6
4		1
4
6
3		2
7
5
1





For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.28
log 24. 13:01:00

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Sat, 23 Nov 2024 20:16:45 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_1 needed +0.024s ... 0.025s

#5 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#6 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#7 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#8 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.025s

#9 no comparison url found in template nbc.compare_page_1 needed +0s ... 0.026s

#10 composed specs +0s ... 0.026s

#11 did output specs +0s ... 0.026s

#12 start showIntegratedCPUs +0s ... 0.026s

#13 getting avg benchmarks for device 5445 +0.028s ... 0.053s

#14 got single benchmarks 5445 +0.007s ... 0.06s

#15 got avg benchmarks for devices +0s ... 0.06s

#16 min, max, avg, median took s +0.375s ... 0.435s

#17 before gaming benchmark output +0s ... 0.435s

#18 Got 58 rows for game benchmarks. +0.004s ... 0.439s

#19 composed SQL query for gamebenchmarks +0s ... 0.439s

#20 got data and put it in $dataArray +0.01s ... 0.449s

#21 benchmarks composed for output. +0.478s ... 0.927s

#22 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 0.929s

#23 return log +0s ... 0.929s

No reviews found for this graphics card.

Please share our article, every link counts!
Mail Logo

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

Class 2

Radeon RX 6800S
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M4 32-core GPU *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M *
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
A550M *
Quadro P5000 Max-Q *
Radeon 890M *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
Arc 8-Core *
GeForce RTX 2050 Mobile
Arc 140V *
GeForce MX570 *
Radeon RX 6300M *
Arc 130V *
GeForce GTX 1650 Mobile
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Quadro T1000 (Laptop) *
Radeon Pro WX 7100 *
Arc 7-Core *
Radeon RX 570X (Laptop) *

Class 3

M4 8-Core GPU *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 Max-Q *
A310 *
A350M *
T600 Laptop GPU *
T550 Laptop GPU *
Radeon R9 M290X Crossfire
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Iris Xe G7 80EUs
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
Radeon 740M *
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

* Approximate position of the graphics adapter

Klaus Hinum (Update: 2016-01-26)
