The AMD Radeon RX 6500 XT is a mid rangegraphics card for desktop PCs.It is using the Navi 24 graphics chip which uses the RDNA 2 architecture and is manufactured in 6nm at TSMC.6500XT 提供 16 个计算单元（CU = 1,024 着色器）和 4 GB GDDR6 专用 VRAM，通过 64 位接口（最大 143.9 GB/s）连接。
Radeon RX 6500 XT 的性能类似于 NvidiaGeForce GTX 1650 Super，但比老款 Radeon RX 5500 XT 慢。因此，该显卡最适合 1080p 和 2021 款游戏的高预设值（实际游戏基准测试见下文）。
额定功耗为 107 瓦（TGP），因此与 GTX 1650 Super（100 瓦）相似。
| Architecture | Navi / RDNA2 |
| Pipelines | 1024 - unified |
| TMUs | 64 |
| ROPs | 32 |
| Raytracing Cores | 16 |
| Core Speed | 2310 MHz |
| Shader Speed | 2815 MHz |
| Memory Speed | 18000 MHz |
| Memory Type | GDDR6 |
| Max. Amount of Memory | 0 GB |
| Shared Memory | no |
| API | DirectX 12_2, Shader 6.6, OpenGL 4.4, OpenCL 2.2, Vulkan 1.3 |
| Power Consumption | 107 Watt |
| Transistor Count | 5.4 Billion |
| Die Size | 107 mm² |
| technology | 7 nm |
| PCIe | 4.0 x4 |
| Displays | 2 Displays (max.), HDMI 2.1, DisplayPort 1.4a |
| Date of Announcement | 19.01.2022 |
- Average benchmark values for this graphics cardThe following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.
| low | med. | high | ultra | QHD | 4K | |
|---|---|---|---|---|---|---|
| F1 24 | 85.8 | 56.6 | 36.9 | 10.4 | 6.8 | |
| Senua's Saga Hellblade 2 | 8 | 5.8 | 2.3 | |||
| Ghost of Tsushima | 59.7 | 46.9 | 31.7 | 15.3 | 11.6 | |
| Dragon's Dogma 2 | 19.8 | 19.3 | 11.8 | |||
| Horizon Forbidden West | 37.8 | 30.2 | 12 | 11.4 | ||
| Alone in the Dark | 143.6 | 112.9 | 93.5 | 18.7 | ||
| Last Epoch | 111 | 89.2 | 74 | 54.5 | 30.6 | 8.4 |
| Skull & Bones | 63 | 54 | 42 | 30 | 18 | |
| Helldivers 2 | 23.8 | 12.8 | 12.9 | 12.3 | ||
| Enshrouded | 37.7 | 35.9 | 22.8 | 12.4 | ||
| Palworld | 68.7 | 43.7 | 30.1 | 21.7 | ||
| Prince of Persia The Lost Crown | 357 | 329 | 311 | 173.1 | 82.6 | |
| Ready or Not | 81.1 | 68.7 | 50.4 | 36.1 | 23.1 | 6.2 |
| The Finals | 107.8 | 75.2 | 65.8 | 48.6 | 28.2 | 6 |
| Avatar Frontiers of Pandora | 34 | 30 | 22 | 17 | 12 | 9.6 |
| Call of Duty Modern Warfare 3 2023 | 84 | 58 | 40 | 32 | 14 | |
| EA Sports WRC | 80.3 | 58.3 | 17.8 | 15.6 | 8.9 | |
| Alan Wake 2 | 34 | 25.7 | 24 | 13.1 | ||
| Lords of the Fallen | 29 | 21.1 | 14.4 | 9.8 | ||
| Total War Pharaoh | 188.9 | 143.1 | 81.5 | 66 | 40.7 | 16.9 |
| Assassin's Creed Mirage | 78 | 63 | 39 | 27 | 21 | 8 |
| EA Sports FC 24 | 161.4 | 145.7 | 101.3 | 55.7 | 44.2 | 28.8 |
| Counter-Strike 2 | 281 | 194 | 94.5 | 69.2 | 35 | 13.9 |
| Cyberpunk 2077 2.2 Phantom Liberty | 64 | 39.8 | 28.4 | 23.5 | ||
| Baldur's Gate 3 | 68.2 | 55.7 | 45.1 | 44.2 | ||
| Lies of P | 88.4 | 67 | 48.3 | 32.8 | 17.5 | 7.6 |
| Starfield | 42.3 | 13.9 | 10.6 | 9.7 | ||
| Armored Core 6 | 89.6 | 69.3 | 58.7 | 35.3 | 20 | 10.7 |
| Immortals of Aveum | 27.3 | 23.7 | 15.2 | |||
| Atlas Fallen | 51.3 | 35.5 | 28.6 | 6.18 | ||
| Ratchet & Clank Rift Apart | 23.7 | 20.5 | 15.3 | 10.6 | ||
| F1 23 | 85.3 | 77.3 | 52 | 11.5 | 7.39 | 2.23 |
| Diablo 4 | 116.9 | 93.7 | 80.8 | 75.8 | ||
| Star Wars Jedi Survivor | 39.1 | 30.4 | 28.9 | 23.7 | ||
| Dead Island 2 | 159.1 | 117.4 | 87.6 | 62.3 | 45.3 | 20.4 |
| The Last of Us | 54.1 | 37.1 | 28.7 | 24.4 | ||
| Resident Evil 4 Remake | 77.3 | 57.2 | 11.7 | |||
| Company of Heroes 3 | 87.8 | 71.8 | 57.5 | 56.1 | 31.9 | 13.7 |
| Sons of the Forest | 40.4 | 29.4 | 26.7 | 24.5 | 18.1 | 10.5 |
| Atomic Heart | 110.9 | 84.2 | 47.9 | 37.4 | 27.2 | 13.8 |
| Returnal | 54 | 51 | 45 | 24 | 15 | 12 |
| Hogwarts Legacy | 79.5 | 59.5 | 47.9 | 33.3 | 23.3 | 9.43 |
| Dead Space Remake | 33.9 | 27.7 | 21.9 | 17.5 | 8.92 | 2.14 |
| The Witcher 3 v4.00 | 99.9 | 75.1 | 65.7 | 54.1 | 30.4 | 9.91 |
| High On Life | 150.6 | 81.2 | 56.2 | 54.4 | 32.1 | 11.8 |
| The Callisto Protocol | 90.6 | 59.1 | 29.3 | 28.2 | 18.5 | 7.3 |
| Need for Speed Unbound | 55.8 | 33.6 | 30.7 | 23.5 | 17.2 | |
| Spider-Man Miles Morales | 52.5 | 48 | 36.6 | 30.2 | 19.7 | 10.6 |
| Call of Duty Modern Warfare 2 2022 | 87 | 69 | 53 | 42 | 28 | 11 |
| Uncharted Legacy of Thieves Collection | 51.8 | 42.1 | 16.7 | 15.1 | 9.16 | |
| A Plague Tale Requiem | 66.6 | 49.9 | 35.3 | 22.7 | 13.1 | 4.61 |
| FIFA 23 | 170.8 | 150.4 | 79.6 | 66 | 56.9 | 29.5 |
| The Quarry | 79 | 58 | 45 | 26 | 9 | 4.23 |
| F1 22 | 132 | 111 | 72 | 16 | 10 | 3 |
| Vampire Bloodhunt | 222 | 116.3 | 111.9 | 110.9 | 62.7 | 23.1 |
| Ghostwire Tokyo | 94 | 89 | 87 | 88 | 49 | 20 |
| Tiny Tina's Wonderlands | 118 | 82 | 51 | 31 | 18 | 8 |
| Cyberpunk 2077 1.6 | 72 | 54 | 34 | 30 | 17 | 4 |
| Elex 2 | 64.8 | 59.7 | 40.5 | 33.8 | 21.7 | 5.87 |
| GRID Legends | 202 | 149.6 | 85.2 | 59.4 | 52.5 | 26.5 |
| Elden Ring | 59.4 | 59.5 | 59.4 | 58 | 44 | 20.6 |
| Dying Light 2 | 58.3 | 44.1 | 35.5 | 24.4 | 11.2 | |
| Rainbow Six Extraction | 101 | 91 | 66 | 33 | 19 | 6 |
| God of War | 78 | 62 | 30 | 9 | 8 | 6.68 |
| Halo Infinite | 74.8 | 73 | 64.5 | 56 | 11.1 | |
| Farming Simulator 22 | 291 | 162 | 112 | 92.3 | 70.5 | 37.9 |
| Battlefield 2042 | 145 | 80.4 | 39.8 | 25.3 | 18.5 | 3.95 |
| Forza Horizon 5 | 204 | 102 | 81 | 29 | 11 | 5 |
| Call of Duty Vanguard | 102 | 87.1 | 34.9 | 31.4 | 22.8 | 3.18 |
| Riders Republic | 127 | 66 | 54 | 47 | 27 | 9 |
| Guardians of the Galaxy | 78 | 38 | 33 | 31 | 26 | 6 |
| Back 4 Blood | 140 | 117 | 109 | 68.1 | 27.7 | |
| Far Cry 6 | 155 | 19 | 33 | 8 | 5 | 2 |
| Alan Wake Remastered | 147 | 123 | 93.3 | 55 | ||
| New World | 145 | 62.1 | 55.3 | 43.4 | 29.8 | 16.8 |
| F1 2021 | 379 | 155 | 109 | 35 | 26 | 11 |
| Mass Effect Legendary Edition | 110 | 105 | 78.1 | 37.5 | ||
| Immortals Fenyx Rising | 128 | 68 | 58 | 46 | 35 | 10 |
| Assassin´s Creed Valhalla | 100 | 51 | 43 | 31 | 23 | 6 |
| Dirt 5 | 168.5 | 61.7 | 41.9 | 34.3 | 24.2 | 14.5 |
| Watch Dogs Legion | 117 | 73.7 | 57.6 | 24.8 | 18.5 | 9.68 |
| Mafia Definitive Edition | 146 | 63 | 57.9 | 36.2 | 17.2 | |
| Crysis Remastered | 271 | 121 | 59.9 | 51.3 | 36.9 | 18.2 |
| Horizon Zero Dawn | 121 | 76 | 63 | 53 | 42 | 23 |
| F1 2020 | 363 | 178 | 138 | 93 | 65 | 31 |
| Borderlands 3 | 194 | 94 | 56 | 41 | 25 | 10 |
| Control | 187 | 64 | 43 | 28 | 8 | |
| Anno 1800 | 117 | 109 | 60.9 | 28.3 | 33.5 | 11.3 |
| Far Cry New Dawn | 165 | 99 | 91 | 83 | 56 | 20 |
| Metro Exodus | 138 | 68 | 51 | 31 | 21 | 10 |
| Shadow of the Tomb Raider | 227 | 86 | 72 | 55 | 35 | 16 |
| Strange Brigade | 390 | 128 | 107 | 84 | 56 | 26 |
| Far Cry 5 | 193 | 102 | 92 | 86 | 55 | 22 |
| X-Plane 11.11 | 77 | 63 | 43 | 42 | ||
| Final Fantasy XV Benchmark | 147 | 72 | 47 | 31 | 13 | |
| Rise of the Tomb Raider | 238 | 154 | 85.7 | 68.1 | 27.8 | |
| Dota 2 Reborn | 235 | 191 | 147 | 116 | 68 | |
| The Witcher 3 | 312 | 188 | 93 | 54 | 28 | |
| GTA V | 188 | 187 | 119 | 50 | 31 | 28 |
| < 30 fps < 60 fps < 120 fps ≥ 120 fps | 6 17 37 35 | 9 29 41 17 | 21 44 29 4 | 34 37 17 1 | 47 24 6 1 | 66 5 2 |
