AMD Radeon Steam Deck 8CU

AMD Radeon Radeon Steam Deck 8CU

AMD Radeon Steam Deck APU GPU 是 Steam Deck OLED 定制 CPU 中的集成显卡 (iGPU)，有 8 个 CU。图形核心采用 RDNA 2 架构，频率为 1000 MHz（最低）至 1600 MHz（最高）。

SoC 在台积电以 N6 工艺（6 纳米）制造。

CodenameRDNA 2 Sephiroth
ArchitectureRDNA 2
Pipelines512 - unified
TMUs32
ROPs16
Raytracing Cores8
Core Speed1900 (Boost) MHz
CacheL1: 512 KB, L2: 1 MB, L3: 8 MB
Shared Memoryno
APIDirectX 12_1
technology6 nm
Date of Announcement09.11.2023
CPU in Radeon Radeon Steam Deck 8CUGPU Base SpeedGPU Boost / Turbo
AMD Steam Deck OLED APU4 x 2400 MHz, 15 W1000 MHz1600 MHz

Benchmarks

Geekbench 6.3 - Geekbench 6.3 GPU Vulkan
19051 points (5%)
+ 1 benchmarks and specifications   - Hide comparison chart
Power Consumption - Furmark Stress Test Power Consumption - external Monitor *
27.7 Watt (4%)
+ 1 benchmarks and specifications   - Hide comparison chart
Intel HD Graphics 500
8.9 -68%
...
NVIDIA GeForce MX110
21 -24%
Intel UHD Graphics 615
21 -24%
Intel UHD Graphics G1 (Ice Lake 32 EU)
21.05 -24%
Intel UHD Graphics 610
23.1 -17%
Qualcomm SD X Adreno X1-85 4.6 TFLOPS
24.5 -12%
Intel UHD Graphics Xe 16EUs (Tiger Lake-H)
24.57 -11%
AMD Radeon RX Vega 3
25.7 -7%
Intel Iris Plus Graphics G4 (Ice Lake 48 EU)
27.4 -1%
AMD Radeon HD 8330
27.4 -1%
AMD Radeon Steam Deck 8CU
27.7
Intel HD Graphics 5500
27.75 0%
Intel UHD Graphics Xe G4 48EUs
27.89 1%
AMD Radeon HD 8400
28.1 1%
Intel Iris Plus Graphics G7 (Ice Lake 64 EU)
28.58 3%
Intel HD Graphics 620
29.1 5%
AMD Radeon RX Vega 10
30 8%
Intel Graphics 4-Core iGPU (Arc)
30.27 9%
Intel UHD Graphics 620
30.54 10%
AMD Radeon RX Vega 6 (Ryzen 4000/5000)
30.78 11%
...
AMD Radeon RX 7900M
313 1030%
max:
NVIDIA GeForce RTX 5090
725 2517%
0%
100%
0510152025Tooltip
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Cyberpunk 2077 2.1 Phantom Liberty

Cyberpunk 2077 2.1 Phantom Liberty

2023
low 1920x1080
25  fps    + Compare
high 1920x1080
21.1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low Preset (FSR off) 1280x720
40.1
Steam Deck 1280x800
47.3
Guardians of the Galaxy

Guardians of the Galaxy

2021
low 1280x720
48  fps    + Compare
med. 1920x1080
31  fps    + Compare
high 1920x1080
30  fps    + Compare
ultra 1920x1080
28  fps    + Compare
» With all tested laptops playable in detail settings low.
Horizon Zero Dawn

Horizon Zero Dawn

2020
low 1280x720
59  fps    + Compare
med. 1920x1080
39  fps    + Compare
high 1920x1080
33  fps    + Compare
» With all tested laptops playable in detail settings med..
Shadow of the Tomb Raider

Shadow of the Tomb Raider

2018
low 1280x720
41  fps    + Compare
med. 1920x1080
28  fps    + Compare
high 1920x1080
28  fps    + Compare
ultra 1920x1080
25  fps    + Compare
» With all tested laptops playable in detail settings low.
Strange Brigade

Strange Brigade

2018
high 1920x1080
37  fps    + Compare
ultra 1920x1080
30  fps    + Compare
» With all tested laptops playable in detail settings high.
Far Cry 5

Far Cry 5

2018
high 1920x1080
27  fps    + Compare
ultra 1920x1080
23  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Additional Benchmarks
Low Preset TAA 1920x1080
41
Final Fantasy XV Benchmark

Final Fantasy XV Benchmark

2018
low 1280x720
51.9  fps    + Compare
high 1920x1080
18.4  fps    + Compare
» With all tested laptops playable in detail settings low.
Dota 2 Reborn

Dota 2 Reborn

2015
low 1280x720
88.2  fps    + Compare
» With all tested laptops playable in detail settings low.
GTA V

GTA V

2015
ultra 1920x1080
19.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
lowmed.highultraQHD4K
Cyberpunk 2077 2.1 Phantom Liberty2521.13
Guardians of the Galaxy48313028
Horizon Zero Dawn593933
Shadow of the Tomb Raider41282825
Strange Brigade3730
Far Cry 52723
Final Fantasy XV Benchmark51.9418.4
Dota 2 Reborn88.2
GTA V19.5
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		1
4
1
1
2

4
3

4
1







For more games that might be playable and a list of all games and graphics cards visit our Gaming List
