AMD Ryzen 7 PRO 6860Z

AMD R7 PRO 6860Z

AMD Ryzen 7 PRO 6860Z 是基于伦勃朗一代的轻薄笔记本处理器。R7 6850U 集成了基于 Zen 3+ 微架构的全部八个内核。它们的主频为 2.7(保证基本时钟)至 4.7 GHz(Turbo),支持 SMT/超线程(16 线程)。芯片采用现代 6 纳米台积电工艺制造。Ryzen 7 PRO 6860Z 是消费级R7 6800U与同类产品 Ryzen 7 PRO 6850U 相比,6860Z 的处理器内核 Turbo 时钟速度提高了 50 MHz,TDP 规定为 28 瓦(6850U 可降至 15 瓦)。

新的 Zen 3+ 是 Zen 3 架构的升级版,应该不会有太大变化。不过,芯片本身提供了很多新功能,如支持 USB 4(40 Gbps)、PCI-E Gen 4、DDR5-4800MT/s 或 LPDDR5-6400MT/s、WiFi 6E、蓝牙 LE 5.2、DisplayPort 2 和 AV1 解码。

处理器性能与 Ryzen 7 6800U 和 Ryzen 7 PRO 6850U 非常相似,由于时钟速度的提高,性能明显优于旧版 Ryzen 7 5800U。平均英特尔酷睿i7-1280P仅略微快一些,但由于核心数量较多(取决于散热和 TDP 设置),也有明显更快的型号。

一大新奇之处在于 集成 GPU Radeon 680M现在基于 RDNA2 架构,提供 12 个 CU,主频高达 2.2GHz。在发布时,它应该是最快的 iGPU。

APU 的 TDP 规定为 28 瓦。得益于 6nm 工艺的改进和 6000 系列附加的省电功能,它的能效应该会非常高。

SeriesAMD Rembrandt (Zen 3+)
CodenameRembrandt U (Zen 3+)
Clock Rate2700 - 4750 MHz
Level 1 Cache512 KB
Level 2 Cache4 MB
Level 3 Cache16 MB
Number of Cores / Threads8 / 16
Power Consumption (TDP = Thermal Design Power)28 Watt
Manufacturing Technology6 nm
Max. Temperature95 °C
SocketFP7
FeaturesXFR, FMA3, SSE 4.2, AVX2, SMT
GPUAMD Radeon 680M ( - 2200 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date04/20/2022
Product Link (external)www.amd.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
35 pt (58%)
AMD E1-2100
2.31 -93%
...
34.6 -1%
34.6 -1%
34.7 -1%
Intel Core i5-1245U
34.8 -1%
34.8 -1%
34.8 -1%
34.9 0%
34.9 0%
Intel Core i7-1265U
34.9 0%
AMD Ryzen 7 PRO 6860Z
35
35.1 0%
35.1 0%
35.2 1%
35.4 1%
AMD Ryzen 9 5900HS
35.5 1%
35.5 1%
35.6 2%
35.8 2%
AMD Ryzen 7 7735H
35.8 2%
...
47.4 35%
max:
60.1 72%
0%
100%
Cinebench R23 - Cinebench R23 Multi Core
11822 Points (11%)
AMD E1-2100
202 -98%
...
11507 -3%
11515 -3%
11525 -3%
11604 -2%
11637 -2%
11662 -1%
11685 -1%
11767 0%
11811 0%
AMD Ryzen 7 PRO 6860Z
11822
11871 0%
11992 1%
12109 2%
12308 4%
12370 5%
12389 5%
12393 5%
12394 5%
AMD Ryzen 9 5900HS
12533 6%
...
32782 177%
max:
107681 811%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
1468 Points (62%)
AMD A10-5745M
74.4 -95%
...
1447 -1%
1449 -1%
1455 -1%
1457 -1%
1457 -1%
1460 -1%
1465 0%
1467 0%
1467 0%
AMD Ryzen 7 PRO 6860Z
1468
1469 0%
1474 0%
AMD Ryzen 9 5900HS
1474 0%
1475 0%
1480 1%
Intel Core i5-11500B
1484 1%
1488 1%
1490 1%
1499 2%
...
2269 55%
max:
Intel Core Ultra 9 285K
2348 60%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
588 Points (65%)
Cinebench R20 - Cinebench R20 CPU (Multi Core)
4555 Points (11%)
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
1992 Points (13%)
01002003004005006007008009001000110012001300140015001600170018001900Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
233 Points (65%)
AMD A4-1200
19 -92%
...
230 -1%
230 -1%
230 -1%
230.8 -1%
231 -1%
231 -1%
AMD Ryzen 9 5900HS
231 -1%
232.3 0%
232.5 0%
AMD Ryzen 7 PRO 6860Z
233
234 0%
234 0%
234 0%
235 1%
235.9 1%
236 1%
236 1%
236.2 1%
236.5 2%
...
311 33%
max:
Intel Core Ultra 9 285K
355.5 53%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
23.1 Points (30%)
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
2.9 Points (68%)
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
6238 points (38%)
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
36959 points (27%)
wPrime 2.10 - wPrime 2.0 1024m *
252.1 s (3%)
wPrime 2.10 - wPrime 2.0 32m *
7.9 s (2%)
7-Zip 18.03 - 7-Zip 18.03 Multi Thread 4 runs
52568 MIPS (30%)
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
5289 MIPS (62%)
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
14.7 fps (26%)
05101520Tooltip
Blender - Blender 2.79 BMW27 CPU *
274 Seconds (2%)
R Benchmark 2.5 - R Benchmark 2.5 *
0.5 sec (11%)
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
18.6 s (1%)
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
694 s (3%)
3DMark 11 - 3DM11 Performance Physics
13574 Points (34%)
3DMark - 3DMark Cloud Gate Physics
14140 Points (36%)
3DMark - 3DMark Fire Strike Standard Physics
20062 Points (36%)
3DMark - 3DMark Time Spy CPU
6779 Points (29%)
Geekbench 5.5 - Geekbench 5.1 - 5.5 64 Bit Multi-Core
8734 points (16%)
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
599 ms (1%)
Octane V2 - Octane V2 Total Score
73281 Points (61%)
WebXPRT 4 - WebXPRT 4 Score
214 Points (60%)
WebXPRT 3 - WebXPRT 3 Score
270 Points (50%)
CrossMark - CrossMark Overall
1505 Points (58%)
Power Consumption - Prime95 Power Consumption - external Monitor *
45.6 Watt (8%)
051015202530354045505560Tooltip
Power Consumption - Cinebench R15 Multi Power Consumption - external Monitor *
62.3 Watt (11%)
051015202530354045505560Tooltip
Power Consumption - Idle Power Consumption - external Monitor *
6.6 Watt (4%)
0123456789Tooltip
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
