Acer ConceptD 5 CN515-51-73Z7

Specifications

Acer ConceptD 5 CN515-51-73Z7
Acer ConceptD 5 CN515-51-73Z7 (ConceptD 5 Series)
Processor
Intel Core i7-8705G 4 x 3.1 - 4.1 GHz, Kaby Lake-G
Graphics adapter
AMD Radeon RX Vega M GL / 870 - 4096 (shared) MB VRAM, Core: 1011 MHz, RAM: 700 MHz, Crimson 18.50.06
Memory
16 GB
, DDR4-2666, verlötet
Display
15.60 inch 16:9, 3840 x 2160 pixel 282 PPI, B156ZAN03.1, LTPS IPS LED, glossy: no
Storage
WDC PC SN720 SDAPNTW-512G, 512 GB
, M.2 2280, PCIe NVMe, 423 GB free
Soundcard
Intel Skylake PCH-H High Definition Audio Controller
Connections
4 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, 1 Kensington Lock, Audio Connections: Kombo-Audio, Card Reader: SD-Kartenleser, 1 Fingerprint Reader
Networking
Intel Wireless-AC 7265 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 17 x 360 x 242
Battery
48 Wh Lithium-Ion
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: 720p
Additional features
Speakers: Stereo, Keyboard: 6 Reihen Chiclet, Keyboard Light: yes, Acer Care Center, Acer Collection 5, Acer Jumpstart, App Explorer, Acer ConceptID Palette, Acer Quick Access, eBay, Norton Security Ultra, 24 Months Warranty
Weight
1.479 kg, Power Supply: 432 g
Price
1599 Euro



Price comparison

Average Score: 82.7% - good
Average of 1 scores (from 1 reviews)
price: - %, performance: 81%, features: 53%, display: 87% mobility: 67%, workmanship: 80%, ergonomy: 87%, emissions: 90%

Reviews for the Acer ConceptD 5 CN515-51-73Z7

82.7% Acer ConceptD 5 CN515-51 laptop review: Kaby Lake G lightweight struggles with cost cutting | Notebookcheck
Acer leaves known paths with its ConceptD 5 CN515-51 to differentiate itself from the competition, with especially lightweight materials, Kaby Lake G with an integrated AMD GPU and a 4K UHD screen that covers a wider color gamut. At the same time, the Acer ConceptD CN515-51 is also cheaper than other multimedia laptops with a 15.6 inch screen. Unfortunately, the necessary cost cuts are showing up quite fast in this comprehensive review.
Acer ConceptD 5 review: laptop ușor și dotat pentru călătorie
Source: Computerblog.ro →zh-CN Archive.org version
Single Review, online available, Short, Date: 06/15/2020

Comment

AMD Vega M GL / 870:

在较慢的Kaby Lake-G SoC中集成的显卡。提供频率980-1011 MHz的20个CU(= 1280着色器),4GB HBM2图形内存(与GPU和CPU在同一封装上)。TDP的额定功率为65瓦。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-8705G: » Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


1.479 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
