MagyarAsus FX504GD
Specifications
Asus FX504GD (TUF FX504GD Series)
Processor
Intel Core i5-8300H 4 x 2.3 - 4 GHz, Coffee Lake-H
Graphics adapter
NVIDIA GeForce GTX 1050 Mobile - 6 GB VRAM, Core: 1354 MHz, RAM: 7008 MHz, GDDR5, 388.73, Optimus
Memory
8 GB
, DDR4-2666, PC4-21300
Display
15.60 inch 16:9, 1920 x 1080 pixel 141 PPI, AU Optronics B156HTN03.8, TN LED, ID: AUO38ED, glossy: no
Mainboard
Intel HM370
Storage
Seagate Mobile HDD 1TB ST1000LX015-1U7172, 1027 GB
, 5400 rpm
Soundcard
Intel Cannon Lake-H/S - cAVS (Audio, Voice, Speech)
Connections
1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 Kensington Lock, Audio Connections: 3.5 mm combo
Networking
Realtek RTL8168/8111 Gigabit-LAN (10/100/1000MBit/s), Intel Wireless-AC 9560 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 25 x 384 x 262
Battery
48 Wh Lithium-Polymer
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Additional features
Keyboard: Chiclet, Keyboard Light: yes, Asus Hello, 12 Months Warranty
Weight
2.3 kg, Power Supply: 505 g
Price
700 USD
Price comparison
Average Score:
Average of 1 scores (from 1 reviews)
Average of 1 scores (from 1 reviews)
price: - %, performance: 90%, features: 41%, display: 79% mobility: 67%, workmanship: 75%, ergonomy: 82%, emissions: 84%
Reviews for the Asus FX504GD
Asus TUF FX504GD (Core i5-8300H, GTX 1050) Laptop Review | Notebookcheck
Starter gamer. Asus has made its inexpensive FX series even more affordable by reducing the battery capacity, GPU power, and number of ports. The end result is definitely easier on the wallet, but the TN display and primary HDD drag down the system.
Starter gamer. Asus has made its inexpensive FX series even more affordable by reducing the battery capacity, GPU power, and number of ports. The end result is definitely easier on the wallet, but the TN display and primary HDD drag down the system.
Asus TUF FX504GD & FX504GE Review
Source: Pemmzchannel
ID→zh-CN Archive.org version
Single Review, online available, Medium, Date: 08/07/2018
Source: Pemmzchannel
ID→zh-CN Archive.org versionSingle Review, online available, Medium, Date: 08/07/2018
Comment
NVIDIA GeForce GTX 1050 Mobile:
基于Nvidia Pascal架构的主流显卡以及GeForce GTX 960M的后续产品，制造于三星的14纳米工艺，其技术规格于桌面版本非常相似。
» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.
i5-8300H:
基于Coffee Lake架构的处理器，适用于大型笔记本电脑。集成了四个主频为2.3-4 GHz（3.9 GHz，4核）的处理器内核，支持超线程。采用改进的14nm工艺（14nm ++）制造。
» Further information can be found in our Comparison of Mobile Processsors.
15.60": 15到16寸是笔记本电脑的标准尺寸，产品型号最为丰富。» To find out how fine a display is, see our DPI List.
2.3 kg: 这是14到16寸的标准笔记本电脑的常见重量。
» Further information can be found in our Notebook Purchase Guide.
