Asus TUF Gaming F15 FX506LU-HN106

Specifications

Asus TUF Gaming F15 FX506LU-HN106
Asus TUF Gaming F15 FX506LU-HN106 (TUF Gaming F15 FX506 Series)
Processor
Intel Core i7-10870H 8 x 2.2 - 5 GHz, Comet Lake-H
Graphics adapter
Memory
16 GB
, DDR4-2933
Display
15.60 inch 16:9, 1920 x 1080 pixel 141 PPI, IPS, glossy: no, 144 Hz
Storage
1TB SSD
Connections
1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, USB-C
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 5.0
Size
height x width x depth (in mm): 24.9 x 360 x 256
Battery
48 Wh Lithium-Polymer, 3-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Keyboard: Chiclet, Keyboard Light: yes, 24 Months Warranty
Weight
2.3 kg



Price comparison

Reviews for the Asus TUF Gaming F15 FX506LU-HN106

ASUS TUF Gaming F15 FX506 - Top 5 Reasons to BUY or NOT to buy it
Source: Laptop Media English
Single Review, online available, Medium, Date: 06/01/2021
ASUS TUF Gaming F15 (FX506) review – a decent performer that is easy on your budget
Source: Laptop Media English EN→zh-CN
Okay, guys, this is a notebook that may provide a different experience, depending not only on the configuration but on the actual model, itself. Some units pack a 90Wh battery, which should provide great screen-on times, but on the other hand, it lacks the 2.5-inch SATA drive bay. Respectively, the 48Wh unit provides horrendous battery life but enables the option of further storage expansion. On the bright side, there are still two M.2 NVMe slots for SSDs, and two RAM SODIMM slots for up to 64GB of DDR4 memory in dual-channel mode.
Single Review, online available, Very Long, Date: 04/23/2021
ASUS TUF F15 (FX506) - disassembly and upgrade options
Source: Laptop Media English
Support, online available, Very Short, Date: 04/23/2021

Comment

NVIDIA GeForce GTX 1660 Ti Mobile:

基于台式机GTX 1660 Ti的笔记本电脑的中档独显,基于图灵架构,没有光线追踪和Tensor内核。 Max-P变体的性能应类似于较旧的GTX 1070。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-10870H:

基于咖啡湖的处理器,适用于大型、重型笔记本电脑。 内置8个处理器内核,时钟为2.2~5GHz(8个内核最高4.2GHz),支持Hyper穿线。 采用第3代14nm英特尔工艺制造。

» Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


2.3 kg: 这是14到16寸的标准笔记本电脑的常见重量。


» Further information can be found in our Notebook Purchase Guide.
