Asus UX310UQ-FC396T

Specifications

Asus UX310UQ-FC396T
Asus UX310UQ-FC396T (ZenBook UX310 Series)
Processor
Intel Core i7-7500U 2 x 2.7 - 3.5 GHz, Kaby Lake
Graphics adapter
NVIDIA GeForce 940MX - 2048 MB VRAM, Core: 1242 MHz, RAM: 900 MHz, DDR3 (Micron), ForceWare 378.49, Nvidia Optimus, Intel HD Graphics 620
Memory
16 GB
, 8 GB 板载, 1 内存插槽被占用, DDR4 2133, 三星
Display
13.30 inch 16:9, 1920 x 1080 pixel 166 PPI, AU Optronics AUO272D, IPS, LED, glossy: no
Mainboard
Intel Kaby Lake-U Premium PCH
Storage
SanDisk SD8SN8U512G1002, 512 GB
, + Seagate, 1000 ST1000LM035-1RK172 1000 GB HDD @ 5400 rpm, 1352 GB free
Soundcard
Conexant SmartAudio HD
Connections
2 USB 2.0, 1 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 HDMI, Audio Connections: 音频输入输出复合接口, 3.5 mm 接口, Card Reader: SD/SDHC/SDXC, Brightness Sensor
Networking
Intel Dual Band Wireless-AC 8260 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.1
Size
height x width x depth (in mm): 18.35 x 323 x 223
Battery
48 Wh, 4211 mAh Lithium-Ion
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: 立体声 (底面), Keyboard: 巧克力键盘, Keyboard Light: yes, 华硕包, 电源适配器, 24 Months Warranty
Weight
1.454 kg, Power Supply: 220 g
Price
1299 EUR



Price comparison

Average Score: 84.4% - good
Average of 1 scores (from 1 reviews)
price: - %, performance: 76%, features: 53%, display: 88% mobility: 80%, workmanship: 81%, ergonomy: 78%, emissions: 91%

Reviews for the Asus UX310UQ-FC396T

84.4% 华硕 ZenBook UX310UQ (7500U, 940MX, Full HD) 笔记本简短评测 | Notebookcheck
一位出色伴侣! 在去年的十一月,这台笔记本基于Skylake处理器的上一代产品通过了我们详尽的评测。这次的测试轮到了搭载Kaby Lake的型号。评测当中我们将会展示华硕通过英特尔的新CPU提供了多少了的额外性能,以及Kaby Lake处理器究竟提供了多少的性能提升。
ASUS ZenBook UX310UQ review – thin, light, powerful
Source: Laptop Media English EN→zh-CN Archive.org version
While the laptop sounds great on paper, there are some things you really need to consider before buying it. First, the thin and light design combined with the powerful hardware has its price and this time it’s noise emissions. The cooling fan is always spinning even if you are not using laptop and it just sits idle. Secondly, there’s already a better version of the notebook that makes this one obsolete – the UX410UQ is nearly identical regarding hardware, build, dimensions, weight, input devices, storage options and performance but packs a slightly larger 14-inch display, somehow longer battery life and slightly better screen. We honestly can’t think of a reason to choose the 13-inch UX310UQ option.
Single Review, online available, Very Long, Date: 09/06/2017

Comment

NVIDIA GeForce 940MX: 基于Maxwell架构的中端笔记本电脑显卡。相比较老的940M,MX支持GDDR5显存和可能稍快的主频。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-7500U:

基于Kaby-Lake架构的双核处理器,主频为2.7至3.5 GHz,支持超线程,采用改进的14纳米制程技术制造。

» Further information can be found in our Comparison of Mobile Processsors.


13.30":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.454 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
