Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H

Specifications

Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H
Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H (VivoBook Pro 15 Series)
Processor
Intel Core Ultra 5 125H 14 x 3.6 - 4.5 GHz, Meteor Lake-H
Graphics adapter
NVIDIA GeForce RTX 4060 Laptop GPU - 8 GB VRAM, GDDR6
Memory
16 GB
, DDR5-5600
Display
15.60 inch 16:9, 2880 x 1620 pixel 212 PPI, OLED, glossy: yes, 120 Hz
Storage
M.2 PCIe
Connections
2 USB 3.0 / 3.1 Gen1, 1 USB 3.1 Gen2, 1 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, Audio Connections: 3.5mm, Card Reader: SD
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.3
Size
height x width x depth (in mm): 19.9 x 355.7 x 235.3
Battery
75 Wh Lithium-Ion, 4-cell
Operating System
Microsoft Windows 11 Home
Camera
Webcam: IR
Primary Camera: 5 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1.8 kg
Links
Asus homepage
Asus notebook section



Price comparison

Reviews for the Asus VivoBook Pro 15 OLED N6506, Ultra 5 125H

ASUS Vivobook Pro 15 OLED (N6506) Review: gran pantalla en un equipo compacto ideal para creadores
Source: Noticias 3D Spanish ES→zh-CN
Single Review, online available, Very Long, Date: 05/01/2024

Comment

NVIDIA NVIDIA GeForce RTX 4060 Laptop GPU: High-end graphics card for laptops based on the Ada Lovelace architecture.Offers 8 GB GDDR6 (128 Bit) and is configurable with a TGP of 35 - 115W (+ Dynamic Boost).



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 5 125H: 一款于 2023 年 12 月亮相的中端流星湖系列芯片。这款第 1 代酷睿 Ultra 笔记本电脑处理器将取代第 13 代酷睿芯片；它拥有 14 个内核（4 + 8 + 2）和 18 个线程。其中，性能内核（4 个）运行频率最高可达 4.5 GHz，而高效内核（10 个）（8 个主内核加上低功耗岛中的 2 个额外内核）运行频率最高可达 3.6 GHz。刚刚出炉的 7 核 Arc GPU 可用作集成图形适配器（运行频率高达 2.20 GHz），此外还提供了大量其他全新技术，如集成 AI Boost NPU（带有两个用于硬件 AI 工作负载加速的第 3 代引擎）。该芯片的英特尔建议 "最低保证 "功耗为 28 W，而最大 Turbo 功耗应该在 115 W 以内。» Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸，产品型号最为丰富。» To find out how fine a display is, see our DPI List.


1.8 kg: 大部分12到16寸的亚笔记本电脑，超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
