Asus ZenBook Flip 15 UX563FD-A1027T

Specifications

Asus ZenBook Flip 15 UX563FD-A1027T
Asus ZenBook Flip 15 UX563FD-A1027T (ZenBook Flip 15 Series)
Processor
Intel Core i7-10510U 4 x 1.8 - 4.9 GHz, Comet Lake-U
Graphics adapter
NVIDIA GeForce GTX 1050 Max-Q - 4 GB VRAM, Core: 1329 MHz, RAM: 1752 MHz, GDDR5, 128-Bit-Anbindung, Nvidia 442.50, Optimus
Memory
16 GB
, LPDDR3-2133, Dual-Channel, Speicher fest verlötet, keine Speicherbänke
Display
15.60 inch 16:9, 3840 x 2160 pixel 282 PPI, kapazitiv, 10 Berührungspunkte, native pen support, BOE HF NE156QUM-N64, IPS, Pantone Zertifizierung, glossy: yes, 60 Hz
Mainboard
Intel Comet Lake-U PCH-LP Premium
Storage
Samsung SSD PM981 MZVLB1T0HALR, 1024 GB
, M.2-2280, 907 GB free
Soundcard
Realtek ALC294 @ Intel Comet Point-LP PCH - cAVS
Connections
3 USB 3.1 Gen2, 1 HDMI, Audio Connections: Audiokombo, Card Reader: SD, Sensors: Gyroskop, TPM 2.0
Networking
Intel Wi-Fi 6 AX201 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5
Size
height x width x depth (in mm): 19.9 x 356 x 229
Battery
71 Wh, 4480 mAh Lithium-Ion, 15.4 V
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Primary Camera: 0.9 MPix
Secondary Camera: IR Kamera
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, Eingabestift (Asus Active Stylus SA200H), McAfee LiveSafe (Testversion), MS Office 365 (Testversion), 24 Months Warranty
Weight
1.9 kg, Power Supply: 440 g
Price
1599 Euro



Price comparison

Average Score: 83.3% - good
Average of 5 scores (from 5 reviews)
price: - %, performance: 78%, features: 51%, display: 87% mobility: 76%, workmanship: 87%, ergonomy: 86%, emissions: 93%

Reviews for the Asus ZenBook Flip 15 UX563FD-A1027T

86.5% Asus ZenBook Flip 15 UX563FD in review: Multimedia convertible for content creators | Notebookcheck
The Asus convertible shines with powerful hardware, a sleek metal case, a backlit keyboard, good battery life and a Pantone-validated 4K touchscreen display. For the latter, users have the choice between using their fingers or the included Active Pen for inputs.
90% Asus ZenBook Flip 15 Review – A capable and premium 2-in-1 laptop
Source: Toptenreviews English EN→zh-CN Archive.org version
A great do-it-all laptop that ticks a lot of boxes. It's a quality 2-in-1 device that will handle anything from work to light gaming, and features one of the best screens going on a portable machine.
Single Review, online available, Medium, Date: 04/01/2020
Rating: Total score: 90%
80% Asus ZenBook Flip 15 review (UX563F): Second-screen sensation or simply insane?
Source: Pocket Lint English EN→zh-CN Archive.org version
Although we can't find any truly killer features from the screen-in-trackpad ScreenPad 2.0, that's almost besides the point. In the ZenBook Flip 15 you've got all the power, screen potential and battery life you could expect from a 15-inch laptop, without an unreasonable price tag.
Single Review, online available, Long, Date: 03/16/2020
Rating: Total score: 80%
80% Asus ZenBook Flip 15 review
Source: Techradar English EN→zh-CN Archive.org version
A great do-it-all laptop that ticks a lot of boxes. It's a quality 2-in-1 device that will handle anything from work to light gaming, and features one of the best screens going on a portable machine.
Single Review, online available, Very Long, Date: 03/10/2020
Rating: Total score: 80%
80% Asus ZenBook Flip 15 (UX563FD) review
Source: Tech Advisor English EN→zh-CN Archive.org version
With a 2-in-1 design and a stunning 4K display, there’s a lot to love about Asus ZenBook Flip 15 UX563FD - especially if you’re in the creative industry. That said, the unreliable ScreenPad and position of speakers could be improved, considering the price of this laptop.
Single Review, online available, Long, Date: 02/26/2020
Rating: Total score: 80%
ASUS ZenBook Flip 15 UX563 review – don’t let the ULV processor fool you, this is a very powerful machine
Source: Laptop Media English EN→zh-CN Archive.org version
ASUS ZenBook Flip 15 UX563’s display is touch-sensitive, has a super dense UHD resolution, comfortable viewing angles and decent maximum brightness and contrast ratio. Additionally, its default settings are adequate, while the backlight lacks PWM, which makes it comfortable for long periods of use.
Single Review, online available, Very Long, Date: 02/17/2020

Comment

NVIDIA GeForce GTX 1050 Max-Q:



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-10510U:

基于Comet Lake的低功耗四核处理器(在技术上与Whiskey Lake相同,但仍采用14nm ++工艺生产)。拥有超线程(8个线程),CPU频率在1.8和4.9 GHz之间(全核最大为4.3 GHz)。集成内存控制器支持DDR4-2666,通过cTDP,性能可以由OEM调整(可能为10-25瓦,默认为15W)。

» Further information can be found in our Comparison of Mobile Processsors.


15.60": 15到16寸是笔记本电脑的标准尺寸,产品型号最为丰富。» To find out how fine a display is, see our DPI List.


1.9 kg: 大部分12到16寸的亚笔记本电脑,超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
