Asus ZenBook S13 OLED UX5304MA

Specifications

Asus ZenBook S13 OLED UX5304MA
Asus ZenBook S13 OLED UX5304MA (ZenBook S13 Series)
Processor
Intel Core Ultra 7 155U 12 x 3.8 - 4.8 GHz, Meteor Lake-P
Memory
32 GB
, DDR5
Display
13.30 inch 16:10, 2880 x 1800 pixel 255 PPI, OLED, glossy: no, 120 Hz
Storage
M.2 PCIe
Connections
1 USB 3.1 Gen2, 2 Thunderbolt, USB-C Power Delivery (PD), 1 HDMI, Audio Connections: 3.5mm
Networking
802.11 a/b/g/n/ac/ax (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.3
Size
height x width x depth (in mm): 11.8 x 296 x 216.3
Battery
63 Wh Lithium-Ion, 4-cell
Operating System
Microsoft Windows 11 Pro
Camera
Webcam: IR
Primary Camera: 2 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes
Weight
1000 g
Price
1500 Euro



Pricecompare

Average Score: 90% - very good
Average of 2 scores (from 2 reviews)

Reviews for the Asus ZenBook S13 OLED UX5304MA

80% Asus Zenbook S13 OLED Review (2024): Slim To The Max And Meddling With MacBook Air
Source: Slashgear English EN→zh-CN
With the Zenbook S13 OLED, Asus is offering an ultrabook that is also functionally rewarding. The build quality is top-notch, the keyboard is amazing, and there is a welcome diversity of I/O ports. It also serves a beautiful OLED screen that is married to perks like 65W fast charging, both of which put the latest MacBook Air to shame. But this machine is not all about slim looks and barely-there heft. The Intel Core Ultra 7 processor holds its own against Apple's venerable M-series processors even at AI workflows. If you are in the market shopping for a slim and light machine, the performance of this Asus laptop won't leave you wanting for more. But there are a few pitfalls to keep in mind, all of which are unfortunately inevitable for Windows-based ultrabooks. When pushed, this sleek laptop runs hot and throttling becomes evident if you're trying to be frugal on the battery. But having tested a healthy bunch of laptops in this segment, I feel the Zenbook S13 OLED (2024) hit the limits of PC engineering finesse.
Single Review, online available, Long, Date: 04/26/2024
Rating: Total score: 80%
100% ASUS Zenbook S 13 OLED UX5304MA-NQ039W (Qwerty toetsenbord) Review
Source: Tweakers Dutch NL→zh-CN
User Review, online available, Very Short, Date: 05/05/2024
Rating: Total score: 100%

Comment

Intel Graphics 4-Core: 基于 Xe LPG 架构的集成显卡(与专用 Arc GPU 相似,但更注重效率)。提供 4 个 Xe 内核(64 Xe 矢量引擎)和 4 个光线追踪单元。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 7 155U: 一款于 2023 年 12 月亮相的中端流星湖芯片。这款第 1 代酷睿 Ultra 处理器将取代第 13 代酷睿处理器;它拥有 12 个内核(2 + 8 + 2)和 14 个线程。其性能内核(有 2 个)的运行频率高达 4.8 GHz,而其高效内核(有 10 个)(8 个主内核加上低功耗岛中的 2 个额外内核)的运行频率高达 3.8 GHz。刚刚出炉的 4 核 Intel Arc Graphics 用作集成图形适配器,其运行频率高达 1.95 GHz,此外还提供了大量其他全新技术,包括集成 AI Boost NPU(带有两个用于硬件 AI 工作负载加速的第 3 代引擎)。这款笔记本处理器的基本功耗为 15 W,英特尔建议的最大 Turbo 功耗为 57 W。» Further information can be found in our Comparison of Mobile Processsors.


13.30":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1 kg: 这是10到11寸大尺寸平板电脑,小型亚笔记本,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
