Asus ZenBook UX3410UQ-GV077T

Specifications

Asus ZenBook UX3410UQ-GV077T
Asus ZenBook UX3410UQ-GV077T
Processor
Intel Core i7-7500U 2 x 2.7 - 3.5 GHz, Kaby Lake
Graphics adapter
NVIDIA GeForce 940MX - 2048 MB VRAM, DDR3
Memory
16 GB
, DDR4 (8 GB onboard)
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, ChiMei N140HCE-EN1, IPS, glossy: no
Mainboard
Intel Kaby Lake-U Premium PCH
Storage
256 GByte M.2-SSD + 1 TByte HDD
Soundcard
Intel Kaby Lake-U/Y PCH - High Definition Audio
Connections
2 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 DisplayPort, Audio Connections: 3.5mm, Card Reader: SD, Brightness Sensor
Networking
Intel Dual Band Wireless-AC 8260 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 18.95 x 323 x 223
Battery
48 Wh Lithium-Ion, 3-cell
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD
Additional features
Speakers: harman/kardon Audio System, Keyboard: Chiclet, Keyboard Light: yes, 45-Watt power adapter, protective sleeve, Asus Tools, Office 365 (trial), McAfee LiveSafe (trial), Team Viewer, Evernote, WPS Office, Cyberlink PhotoDirector & PowerDirector, 24 Months Warranty
Weight
1.4 kg, Power Supply: 180 g
Price
900 Euro



Price comparison

Average Score: 88.5% - very good
Average of 2 scores (from 4 reviews)

Reviews for the Asus ZenBook UX3410UQ-GV077T

Asus ZenBook UX3410UQ
Source: Allround-PC.com German DE→zh-CN Archive.org version
Single Review, online available, Medium, Date: 06/19/2017
90% Asus Zenbook UX3410UQ
Source: MobiFlip German DE→zh-CN Archive.org version
Single Review, online available, Long, Date: 04/09/2017
Rating: Total score: 90%
87% Asus ZenBook UX3410UQ (i7-7500U, GeForce 940MX, 16GB RAM, 256GB SSD, 1TB HDD)
Source: Computerbild - 5/2017 German
Single Review, , Length Unknown, Date: 03/01/2017
Rating: Total score: 87%
ASUS ZenBook UX3410U
Source: HardwareLuxx German DE→zh-CN Archive.org version
Single Review, online available, Long, Date: 02/09/2017

Comment

NVIDIA GeForce 940MX: 基于Maxwell架构的中端笔记本电脑显卡。相比较老的940M,MX支持GDDR5显存和可能稍快的主频。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-7500U:

基于Kaby-Lake架构的双核处理器,主频为2.7至3.5 GHz,支持超线程,采用改进的14纳米制程技术制造。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.4 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
