Dell Inspiron 17 5770-0364

Specifications

Dell Inspiron 17 5770-0364
Dell Inspiron 17 5770-0364 (Inspiron 17 5000 Series)
Processor
Intel Core i7-8550U 4 x 1.8 - 4 GHz, Kaby Lake Refresh
Graphics adapter
AMD Radeon 530 - 4 GB VRAM
Memory
8 GB
, DDR4-2400, single-channel, 1 of 2 slots occupied, max. 16 GB
Display
17.30 inch 16:9, 1920 x 1080 pixel 127 PPI, AUO109D (AU Optronics), IPS, glossy: no
Storage
128 GB NVMe, 128 GB
, + 1TB HDD
Connections
1 USB 2.0, 2 USB 3.0 / 3.1 Gen1, 1 HDMI, 1 Kensington Lock, Audio Connections: 3.5mm, Card Reader: SD, 1 Fingerprint Reader
Networking
10/100/1000 LAN Card (10/100/1000MBit/s), 802.11 a/b/g/n/ac (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.1
Optical drive
DVD +/- RW Double Layer
Size
height x width x depth (in mm): 25 x 415.4 x 279.2
Battery
42 Wh, 3500 mAh Lithium-Ion
Operating System
Microsoft Windows 10 Home 64 Bit
Camera
Webcam: HD 0.9Mpix
Additional features
Speakers: Stereo, Keyboard: Chiclet, 24 Months Warranty
Weight
2.71 kg, Power Supply: 275 g
Price
900 Euro



Price comparison

Reviews for the Dell Inspiron 17 5770-0364

Dell Inspiron 17 5770 (Core i7-8550U, AMD Radeon 530) review – image quality is the strongest and probably the only selling point
Source: Laptop Mag English EN→zh-CN Archive.org version
The build quality isn’t exactly impressive or at least good enough to consider it over its cheaper direct competitors. Also, input devices fall short of the competition as well – the touchpad is stiff and has suboptimal gliding surface while the keyboard has that cheap feeling and short key travel. It should be noted, though, that the pleasant clicky feedback of the keyboard compensates to some extent.
Single Review, online available, Very Long, Date: 02/14/2018
Ревю на Dell Inspiron 17 5770 (Core i7-8550U, AMD Radeon 530) – добър процесор и приятно визуално преживяване
Source: Laptop.bg BU→zh-CN Archive.org version
Single Review, online available, Very Long, Date: 08/30/2018

Comment

AMD Radeon 530:

具有320或384着色单元的入门级专用显卡(取决于其所使用的芯片)以及DDR3或GDDR5图形存储器(均带有64位内存总线)。两种芯片都被应用了好些年,甚至是从Radeon 8590M(28纳米 GCN)就开始。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i5-8550U:

基于Kaby-Lake-Refresh的低功耗四核处理器。这四个内核的时钟频率介于1.8和4 GHz之间(Turbo Boost),并支持超线程。集成GPU的时钟频率介于300和1,150 MHz之间。 SoC采用14nm + FinFET工艺制造。

» Further information can be found in our Comparison of Mobile Processsors.


17.30":

这个大尺寸屏幕常见于以桌面使用为主的笔记本电脑。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


2.71 kg: 这是14到16寸的标准笔记本电脑的常见重量。


» Further information can be found in our Notebook Purchase Guide.
