Dell Latitude 5420 Rugged, 8650U, RX540

Specifications

Dell Latitude 5420 Rugged, 8650U, RX540
Dell Latitude 5420 Rugged, 8650U, RX540 (Latitude 14 Rugged Series)
Processor
Intel Core i7-8650U 4 x 1.9 - 4.2 GHz, Kaby Lake Refresh, Quad-core, 8 threads
Graphics adapter
AMD Radeon RX 540 - 4 GB VRAM, Core: 1176 MHz, RAM: 1500 MHz, GDDR5, AMD Driver Packaging Version 18.10.22-180612a-332314C-Dell, Yes
Memory
16 GB
, 1200.5 MHz, DDR4-2400 / PC4-19200
Display
14.00 inch 16:9, 1920 x 1080 pixel 157 PPI, Embedded Touch, AU Optronics AU Optronics AUO523D, IPS, glossy: no
Mainboard
Intel Kaby Lake-U + iHDCP 2.2 Premium PCH
Storage
SK Hynix PC401 512GB M.2 (HFS512GD9TNG), 512 GB
Soundcard
Intel Kaby Lake-U/Y PCH - High Definition Audio
Connections
3 USB 3.0 / 3.1 Gen1, 1 VGA, 1 HDMI, Audio Connections: 3.5mm, Card Reader: SD, 1 SmartCard, 1 Fingerprint Reader, USB-C
Networking
Intel Ethernet Connection I219-LM (10/100/1000MBit/s), Intel Dual Band Wireless-AC 8265 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 32.88 x 347 x 244.5
Battery
51 Wh, 3-cell
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: HD 720p
Additional features
Speakers: Stereo, Keyboard: Sealed, ruggedized
Weight
2.22 kg
Price
2200 Euro



Price comparison

Average Score: 80% - good
Average of 2 scores (from 2 reviews)

Reviews for the Dell Latitude 5420 Rugged, 8650U, RX540

70% Dell Latitude 5424 Rugged
Source: PC Mag English EN→zh-CN Archive.org version
Dell's Latitude 5424 Rugged is a 14-inch laptop that thrives in harsh environments, though perhaps inevitably, it's overshadowed by its nearly invulnerable sibling, the 7424 Rugged Extreme.
Single Review, online available, Very Long, Date: 03/01/2019
Rating: Total score: 70%
90% Dell Latitude 5420 Rugged Review
Source: Laptop Mag English EN→zh-CN Archive.org version
The Dell Latitude 5420 Rugged offers an extremely bright display and long battery life in a chassis that can withstand the harshest elements.
Single Review, online available, Very Long, Date: 01/31/2019
Rating: Total score: 90%

Comment

AMD Radeon RX 540:

拥有512个着色器(8个计算单元),最高时钟频率为1219 MHz(基于AMD)的显卡。和较快的Radeon RX 550一样,(未经验证,但很有可能)采用新款Polaris 12芯片,采用了稍微改进了的14nm FinFET工艺。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-8650U: » Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


2.22 kg: 大部分12到16寸的亚笔记本电脑,超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
