Framework Laptop 13.5 Core Ultra 7 155H

Specifications

Framework Laptop 13.5 Core Ultra 7 155H
Framework Laptop 13.5 Core Ultra 7 155H (Laptop Series)
Processor
Intel Core Ultra 7 155H 16 x 3.8 - 4.8 GHz, 44 W PL2 / Short Burst, 31 W PL1 / Sustained, Meteor Lake-H
Graphics adapter
Intel Arc 8-Core iGPU, Core: 2250 MHz, DDR5, 31.0.101.5522
Memory
32 GB
, ADATA, DDR5-5600, 46-45-45-90, Dual-Channel
Display
13.50 inch 3:2, 2880 x 1920 pixel 256 PPI, BOE NE135A1M-NY1, IPS, BOE0CB4, glossy: no, 120 Hz
Mainboard
Intel Meteor Lake-U/P/H PCH
Soundcard
Intel Meteor Lake-U/P/H PCH - cAVS (Audio, Voice, Speech)
Connections
4 USB 3.1 Gen2, 4 USB 3.2 Gen 2x2 20Gbps, 4 USB 4.0 40 Gbps, 4 Thunderbolt, USB-C Power Delivery (PD), 4 DisplayPort, Audio Connections: 3.5 mm combo, Card Reader: SD, Brightness Sensor
Networking
Intel Wi-Fi 6E AX210 (a/b/g/h/n = Wi-Fi 4/ac = Wi-Fi 5/ax = Wi-Fi 6/), Bluetooth 5.3
Size
height x width x depth (in mm): 15.85 x 296.63 x 228.98
Battery
61 Wh Lithium-Polymer
Operating System
Microsoft Windows 11 Pro
Camera
Webcam: 1080p
Primary Camera: 2.1 MPix
Additional features
Speakers: Stereo, Keyboard: Chiclet, Keyboard Light: yes, Screwdriver, 12 Months Warranty
Weight
1.355 kg, Power Supply: 313 g
Price
1500 USD



Price comparison

Average Score: 82% - good
Average of 2 scores (from 1 reviews)
price: - %, performance: 65%, features: 72%, display: 82% mobility: 80%, workmanship: 78%, ergonomy: 85%, emissions: 86%

Reviews for the Framework Laptop 13.5 Core Ultra 7 155H

84% Framework 13.5 Core Ultra 7 笔记本电脑评测:全新 2.8K 120 Hz 显示屏与 Arc 8 图形处理器 | Notebookcheck
不可否认,Framework 13.5 笔记本电脑在经历了几代英特尔和 AMD CPU 之后,在设计上没有任何重大变化,因此它的功能非常全面。改进后的显示屏和集成显卡有助于保持该机型的竞争力,但散热解决方案可能已显老态。
80% Framework Laptop 13 review: Build your own laptop
Source: PC World English EN→zh-CN
The Framework Laptop 13 feels like a laptop from an alternate reality. It’s a laptop from a world where you assemble your own laptop like you’d build a desktop PC. It’s a machine you can easily screw open to replace components — or even upgrade the hardware to the next-generation. And you get to swap out the ports for the ones you like best. Want to get inside the laptop and do something? Framework will sell you components and provide detailed DIY guides. You’re not digging through forum threads and trying to find OEM components for sale on eBay. You’ve got an open-source firmware on your machine as well as great compatibility with Linux as well as Windows. If you aren’t sold on the vision, though, you can quibble.
Single Review, online available, Very Long, Date: 08/13/2024
Rating: Total score: 80%

Comment

Intel Arc 8-Core: 基于 Xe LPG 架构的集成显卡(与专用 Arc GPU 相似,但更注重效率)。提供全部 8 个 Xe 内核(128 个 Xe 向量引擎)和 8 个光线追踪单元。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


Ultra 7 155H: 2023 年 12 月亮相的高端流星湖芯片。这款第 1 代酷睿 Ultra 处理器将取代第 13 代酷睿芯片;它拥有 16 个内核(6 + 8 + 2)和 22 个线程。其中,性能内核有 6 个,运行频率最高可达 4.8 GHz,而高效内核有 10 个(8 个主内核加上低功耗岛中的 2 个额外内核),运行频率最高可达 3.8 GHz。集成的 AI Boost NPU 提供两个第 3 代引擎,用于硬件 AI 工作负载加速。这款笔记本电脑处理器的 "最低保证 "功耗为 28 W,而 Turbo 功耗应该在 115 W 以内。 » Further information can be found in our Comparison of Mobile Processsors.


13.50":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


1.355 kg: 这是11到13寸的超大尺寸平板电脑,亚笔记本电脑,超极本和变形本的常见重量。


» Further information can be found in our Notebook Purchase Guide.
