HP ZBook x2 G4-3FB86UT

Specifications

HP ZBook x2 G4-3FB86UT
HP ZBook x2 G4-3FB86UT (ZBook x2 Series)
Processor
Intel Core i7-7600U 2 x 2.8 - 3.9 GHz, Kaby Lake
Graphics adapter
NVIDIA Quadro M620 - 2048 MB VRAM, GDDR5
Memory
16 GB
, DDR4-2133 SDRAM (2 x 8 GB)
Display
14.00 inch 16:9, 3840 x 2160 pixel 315 PPI, Capacitive, native pen support, IPS, glossy: yes
Storage
512 MB NAND Flash, 0.5 GB
Connections
1 USB 3.0 / 3.1 Gen1, 2 Thunderbolt, 1 HDMI, Audio Connections: 3.5mm combo, Card Reader: SD, 1 SmartCard, 1 Fingerprint Reader
Networking
Intel Dual Band Wireless-AC 8265 (a/b/g/n = Wi-Fi 4/ac = Wi-Fi 5/), Bluetooth 4.2
Size
height x width x depth (in mm): 19.1 x 364.5 x 227
Battery
70 Wh Lithium-Ion, HP Long Life 4-cell
Operating System
Microsoft Windows 10 Pro 64 Bit
Camera
Webcam: 720p HD
Additional features
Speakers: Bang & Olufsen, Keyboard: Chiclet, Keyboard Light: yes, 12 Months Warranty
Weight
2.17 kg
Price
2500 Euro



Price comparison

Reviews for the HP ZBook x2 G4-3FB86UT

HP ZBook x2
Source: PC Mag English EN→zh-CN Archive.org version
With workstation-grade components, the HP ZBook x2 packs more power than most detachable-hybrid 2-in-1 laptops. It's a good fit for for artists, 4K videographers, and anyone who needs massive power in a versatile form factor.
Single Review, online available, Medium, Date: 10/18/2017
HP ZBook x2 brings a tear-off keyboard and 4K 10-bit color
Source: CNet English EN→zh-CN Archive.org version
As for the internals, while it uses eighth-gen Intel Core chips, those are still based on a tweaked version of last year's Kaby Lake architecture and the integrated graphics are just rebranded from last year's. That's unavoidable; Intel still hasn't shipped Coffee Lake-based mobile CPUs. But given how much the high-end configuration will probably cost, I'd be tempted to wait and at least get a sense of how much of an improvement the desktop Coffee Lake processors deliver. More cores for a workstation are more important than in a consumer laptop.
Single Review, online available, Short, Date: 10/17/2017

Comment

NVIDIA Quadro M620:

基于28纳米、GM107 Maxwell架构的中档工作站显卡,具有512个着色器和128位宽的内存总线。类似于较老的Quadro M1000M和消费级别的GeForce GTX 950M(有更多的着色器)。



» Further information can be found in our Comparison of Mobile Graphics Cards and the corresponding Benchmark List.


i7-7600U:

基于Kaby-Lake架构的双核处理器,主频为2.8至3.9 GHz,支持超线程,采用改进的14纳米制程技术制造。集成了一个主频为300  -  1150 MHz的高清显卡620,采用改进后的14纳米制程技术生产。

» Further information can be found in our Comparison of Mobile Processsors.


14.00":

大体上,这个屏幕尺寸常见于亚笔记本电脑,超极本和变形本中。对这三类产品来说这个尺寸都较大。亚笔记本中尺寸最大的机型是采用这个屏幕尺寸。

大尺寸可以让屏幕有更高的分辨率。因而例如字体等的细节将会更丰富。不过另一方面,小屏幕的功耗会较低,而设备也会更轻盈小巧,售价更低。

» To find out how fine a display is, see our DPI List.


2.17 kg: 大部分12到16寸的亚笔记本电脑,超极本和轻盈标准笔记本电脑的重量在这个水平上。


» Further information can be found in our Notebook Purchase Guide.
