Intel Pentium Gold 6500Y

Intel Pentium 6500Y

英特尔奔腾金6500Y是一款高效的双核SoC,适用于平板电脑和被动冷却的笔记本,基于2018年的旧琥珀湖一代。它在2021年第一季度宣布,基本上是一个酷睿m3-8100Y,集成显卡稍慢(24个EU中的一个EU被停用)。

该CPU由两个处理器核心组成,时钟频率为1.1-3.4GHz。由于采用了超线程技术,该处理器可以同时执行多达四个线程。芯片还包括英特尔HD Graphics 615 GPU,有23个EU,一个双通道内存控制器(DDR3L/LPDDR3),以及VP9和H.265视频解码器和编码器。 与Kaby Lake-Y前辈(如Core m3-7Y32)相比,Amber Lake使用了在改进的14nm+ FinFET工艺(没有14nm++)下生产的相同架构,但在增加的TDP等级下提供了更高的时钟速度。

架构

英特尔基本上使用了Skylake/Kaby Lake一代熟悉的微架构,所以每MHz的性能是相同的。

性能

Y系列的性能在很大程度上取决于笔记本电脑/平板电脑的冷却方案和持续负载的TDP设置。在我们的测试中,旧的m3-8100Y提供了一个稍微失望的性能,只适合低要求的任务(见英特尔酷睿m3-8100Y的页面)。

图形

集成的英特尔HD Graphics 615 GPU有23个24个执行单元(EUs),就像旧的HD Graphics 515一样,与该处理器一起运行的时钟在300到950MHz之间。性能在很大程度上取决于TDP限制以及内存配置;在双通道模式下使用快速的LPDDR3-1866内存,GPU有时应该能够与HD Graphics 520竞争,但在其他情况下也可能会慢得多。2016年的现代游戏,如果有的话,也只能在最低设置下顺利运行。

与Skylake相反,Kaby Lake和Amber Lake现在还支持10位色深的H.265/HEVC Main10的硬件解码,以及谷歌的VP9编解码。

电源消耗

该芯片采用旧的14纳米+工艺制造,采用FinFET晶体管。Amber Lake Y系列的典型TDP规定为5瓦(前几代为4.5瓦),并可根据使用场景进行双向调整(可配置3.5-7瓦)。

SeriesIntel Amber Lake
CodenameAmber Lake-Y

Series: Amber Lake Amber Lake-Y

Intel Core i5-10310Y1.1 - 4.1 GHz4 / 8 cores6 MB L3
Intel Core i5-10210Y1 - 4 GHz4 / 8 cores6 MB L3
Intel Core i7-8500Y1.5 - 4.2 GHz2 / 4 cores4 MB L3
Intel Core i3-10110Y1 - 4 GHz2 / 4 cores4 MB L3
Intel Core i5-8210Y1.6 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i5-8200Y1.3 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core i3-10100Y1.3 - 3.9 GHz2 / 4 cores4 MB L3
Intel Core m3-8100Y1.1 - 3.4 GHz2 / 4 cores4 MB L3
Intel Pentium Gold 6500Y « 1.1 - 3.4 GHz2 / 4 cores4 MB L3
Clock Rate1100 - 3400 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)5 Watt
Manufacturing Technology14 nm
Max. Temperature100 °C
FeaturesDDR3L-1600/LPDDR3-1866 RAM, PCIe 3, 4 GT/s bus, MMX, SSE, SSE2, SSE3, SSSE3, SSE4.1, SSE4.2, AVX, AVX2, BMI2, ABM, FMA, ADX, VMX, SMEP, SMAP, MPX, EIST, TM1, TM2, Hyper-Threading, Turbo, SST, AES-NI, RDRAND, RDSEED, SGX
GPUIntel UHD Graphics 615 (300 - 900 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date03/01/2021
Product Link (external)ark.intel.com

Benchmarks

Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
3647 points (36%)
AMD E1-2100
577 -84%
...
3486 -4%
AMD Ryzen 7 2700U
3487 -4%
AMD Ryzen 5 PRO 2500U
3492 -4%
Intel Core i3-7130U
3497 -4%
Intel Core i3-7167U
3546 -3%
3562 -2%
3583 -2%
3594 -1%
3641 0%
Intel Pentium Gold 6500Y
3647
3652 0%
Intel Core i7-4722HQ
3664 0%
Intel Core i7-3720QM
3739 3%
Intel Core i5-7Y54
3745 3%
Intel Core m3-7Y32
3774 3%
3785 4%
3785 4%
3797 4%
Intel Core i5-7200U
3799 4%
...
8945 145%
max:
10016 175%
0%
100%
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
5963 points (6%)
AMD E1-2100
1028 -83%
...
AMD A10-5750M
5292 -11%
5419 -9%
AMD Ryzen Embedded R1505G
5478 -8%
Intel Celeron N4120
5606 -6%
Intel Pentium Gold 4415U
5630 -6%
5662 -5%
Intel Core i5-5250U
5758 -3%
5841 -2%
Intel Core i3-7100U
5895 -1%
Intel Pentium Gold 6500Y
5963
6053 2%
6126 3%
Intel Core i3-6157U
6371 7%
6379 7%
Qualcomm Snapdragon 835 (8998)
6515 9%
6641 11%
Intel Core m3-7Y32
6736 13%
Intel Core i3-7130U
6792 14%
Intel Core i5-7Y54
6921 16%
...
75959 1174%
max:
100326 1582%
0%
100%
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
