Intel Atom Z3795

Intel Z3795

Intel Atom Z3795是一款为Windows和Android平板设计的高能效四核整合系统芯片。它属于Bay Trail-T平台，运行于1.59到2.39GHz之间。得利于特别优化设计的22纳米低功耗制程（P1271）和三栅极晶体管技术，它的性能和能效明显高于前代产品。相比Z3775，Z3795提供了更高的CPU基础频率。 架构 它的处理器核心基于新的Silvermont架构，它第一次采用了乱序执行技术的设计。更高的流水线利用率和很多其他的改进（优化的分支预测，缓存的提升，加强的解码器）帮助单位频率性能提升了约50%。不过，相对于前代，它第一次没有采用超线程技术。其他重要改进还有新增加的对SSE 4.1和4.2，AES-NI指令集的支持（根据型号）。 性能 得力于运行在1.59到2.39GHz之间的四个处理器核心，Z3795明显快于前代的Intel Atom处理器如Z2760。Z3795甚至击败了一些AMD Kabini APU处理器，如A4-5000，和一些ARM整合系统芯片如Tegra 4和Snapdragon 800。它的性能足够满足日常应用如上网和办公，但不适合大型软件和最新游戏。 图形 HD Graphics（Bay Trail）基于同样使用在Ivy Bridge系列处理器中（如HD Graphics 4000）的Intel Gen7架构，支持DirectX 11。由于只有4个执行单元（EU）和778MHz的较低频率，它的性能低于HD Graphics（Ivy Bridge），和Qualcomm Adreno 320（如Snapdragon 600）相当。因此，只有较老和要求较低的Windows游戏可以流畅运行。不过，视频加速和2560 x 1600的分辨率对它并不是困难。 功耗 这块整合系统芯片的典型功耗（SDP）仅2W，这意味着热设计功率低于4W。因此，它可以用于被动散热的平板电脑

SeriesIntel Atom
CodenameBay Trail-T

Series: Atom Bay Trail-T

Intel Atom Z3795 « 1.59 - 2.39 GHz4 / 4 cores
Intel Atom Z37851.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37751.46 - 2.39 GHz4 / 4 cores
Intel Atom Z3775D1.49 - 2.41 GHz4 / 4 cores
Intel Atom Z37701.46 - 2.4 GHz4 / 4 cores
Intel Atom Z3770D1.5 - 2.41 GHz4 / 4 cores
Intel Atom Z3736F1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z3736G1.33 - 2.16 GHz4 / 4 cores
Intel Atom Z37451.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3745D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z37401.33 - 1.86 GHz4 / 4 cores
Intel Atom Z3740D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735D1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735E1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735F1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z3735G1.33 - 1.83 GHz4 / 4 cores
Intel Atom Z36801.33 - 2 GHz2 / 2 cores
Intel Atom Z3680D1.33 - 2 GHz2 / 2 cores
Clock Rate1590 - 2390 MHz
Level 1 Cache224 KB
Level 2 Cache2 MB
Number of Cores / Threads4 / 4
Power Consumption (TDP = Thermal Design Power)<4 Watt
Manufacturing Technology22 nm
SocketUTFCBGA1380
FeaturesIntel HD Graphics (Bay Trail, 311 - 778 MHz), Quick Sync, Wireless Display, Clear Video HD, Intel 64, SSE 4.1, SSE 4.2, AES-NI, Secure Key, Anti-Theft, Identify-Protection, max. 4 GB Dual-Channel LPDDR3-1067
GPUIntel HD Graphics (Bay Trail) (311 - 778 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$40 U.S.
Announcement Date05/09/2014
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 118     avg: 127.7     median: 131 (1%)     max: 134 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -76%
...
Intel Core 2 Duo P8600
118 -8%
Intel Celeron N3150
118 -8%
Intel Celeron N2920
118.5 -7%
Intel Pentium 2117U
120 -6%
Intel Pentium N3510
123 -4%
Intel Atom x7-E3950
125 -2%
AMD A9-9425
125 -2%
Intel Pentium 3556U
125.5 -2%
Intel Celeron N4020
127.1 0%
Intel Atom Z3795
127.7
Intel Celeron N6211
128 0%
Intel Pentium 3558U
129 1%
Intel Celeron N2930
129.4 1%
Intel Pentium N3530
129.8 2%
AMD A9-9410
130 2%
Intel Core i3-4012Y
131.3 3%
AMD A9-9420
132 3%
Intel Celeron N4000
132.7 4%
Intel Core i5-4300Y
133 4%
...
AMD Ryzen 9 7945HX3D
5600 4285%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 12306%
0%
100%
0102030405060708090100110Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 36     avg: 37     median: 37 (11%)     max: 38 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -49%
...
Intel Pentium N3510
33 -11%
Intel Celeron N3050
33.07 -11%
AMD A4 Micro-6400T
34 -8%
Intel Celeron N2820
34.3 -7%
Intel Celeron N2930
34.8 -6%
Intel Celeron N2807
35 -5%
Intel Celeron N2940
35.5 -4%
Intel Atom x5-Z8500
35.75 -3%
Intel Atom x5-Z8550
36 -3%
Intel Atom Z3795
37
Intel Pentium N3700
37.4 1%
AMD A4-6210
37.5 1%
Intel Atom x7-Z8700
37.5 1%
Intel Celeron N2830
37.57 2%
Intel Celeron N3060
37.75 2%
Intel Pentium N3520
38.33 4%
Intel Celeron N2840
38.67 5%
Intel Core 2 Duo SU7300
38.7 5%
Intel Atom x7-Z8750
38.9 5%
...
AMD Ryzen 9 7945HX3D
311 741%
max:
Intel Core i9-14900K
332 797%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.61     avg: 1.6     median: 1.6 (2%)     max: 1.64 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.4 Points (11%)
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 1220     avg: 1394     median: 1234 (7%)     max: 1727 points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 3324     avg: 3715     median: 3715 (3%)     max: 4106 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
min: 1727     avg: 4390     median: 5683 (4%)     max: 5761 Points
+ 3 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
min: 1727     avg: 2951     median: 1732 (2%)     max: 5393 Points
+ 3 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
1020 s (12%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
min: 25.93     avg: 27.2     median: 27.2 (5%)     max: 28.4 s
+ 2 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
1075 points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
min: 7.12     avg: 8.3     median: 8.3 (3%)     max: 9.5 fps
+ 2 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
min: 37.15     avg: 42.1     median: 42.1 (10%)     max: 47.13 fps
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Serpent
min: 0.124     avg: 0.1     median: 0.1 (0%)     max: 0.125 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
min: 0.193     avg: 0.2     median: 0.2 (3%)     max: 0.195 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
min: 0.885     avg: 0.9     median: 0.9 (2%)     max: 0.891 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
min: 2069     avg: 2146     median: 2145.5 (5%)     max: 2222 Points
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 36.26     avg: 36.6     median: 36.6 (8%)     max: 37 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 79.6     avg: 80.3     median: 80.3 (3%)     max: 81 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 1732     avg: 1735     median: 1734.5 (8%)     max: 1737 s
+ 2 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Dhrystone (MIPS) - SiSoft Sandra Dhrystone (MIPS)
24.2 MIPS (0%)
+ 1 benchmarks and specifications   + Show comparison chart
SiSoft Sandra Whetstone (MFLOPS) - SiSoft Sandra Whetstone (MFLOPS)
12.2 MFLOPS (0%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark Vantage - 3DM Vant. Perf. CPU no Physx
3552 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
min: 1141     avg: 1386     median: 1301 (4%)     max: 1799 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
18838 Points (15%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Unlimited Physics
20794 Points (18%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
8367 ms (10%)
+ 1 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
388.3 ms (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
3353 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
