Intel Celeron N2807

Intel N2807

Intel Celeron N2807是一款为入门级笔记本电脑设计的高能效双核整合系统芯片。它属于Bay Trail-M平台，运行于1.6 - 2.2GHz。得利于特别优化设计的22纳米低功耗制程（P1271）和三栅极晶体管技术，它的性能和能效明显高于前代Intel Atom处理器产品。 架构 它的处理器核心基于新的Silvermont架构，它第一次采用了乱序执行技术的设计。更高的流水线利用率和很多其他的改进（优化的分支预测，缓存的提升，加强的解码器）帮助单位频率性能提升了约50%。不过，相对于前代，它没有采用超线程技术。其他重要改进还有新增加的对SSE 4.1和4.2，AES-NI指令集的支持（根据型号）。 性能 得力于更高的单位时钟频率性能，Celeron N2807快于前代的Intel Atom处理器如N2800。预计它的表现将可以与AMD的APU如E1-1500竞争。它的性能足够满足日常应用如上网和办公，但不适合大型软件和最新游戏。 图形 它的图形核心HD Graphics（Bay Trail）基于同样使用在Ivy Bridge系列处理器中（如HD Graphics 4000）的Intel Gen7架构，支持DirectX 11。由于只有4个执行单元（EU）和较慢的（313-750MHz）运行频率，它的性能低于HD Graphics（Ivy Bridge）。因此，只有较老和要求较低的Windows游戏可以流畅运行。 功耗 这块整合系统芯片的热设计功率为4.3W(3W SDP)。因此，它可以用于紧凑设计的轻薄笔记本电脑中。

SeriesIntel Celeron
CodenameBay Trail-M

Series: Celeron Bay Trail-M

Intel Celeron N29401.83 - 2.25 GHz4 / 4 cores
Intel Celeron N29301.83 - 2.16 GHz4 / 4 cores
Intel Celeron N29201.86 - 2 GHz4 / 4 cores
Intel Celeron N28402.16 - 2.58 GHz2 / 2 cores
Intel Celeron N29101.6 GHz4 / 4 cores
Intel Celeron N28302.16 - 2.41 GHz2 / 2 cores
Intel Celeron N28202.17 - 2.39 GHz2 / 2 cores
Intel Celeron N28151.86 - 2.13 GHz2 / 2 cores
Intel Celeron N28102 GHz2 / 2 cores
Intel Celeron N28081.58 - 2.25 GHz2 / 2 cores
Intel Celeron N2807 « 1.58 - 2.16 GHz2 / 2 cores
Intel Celeron N28061.58 - 2 GHz2 / 2 cores
Intel Celeron N28051.46 GHz2 / 2 cores
Clock Rate1580 - 2160 MHz
Level 1 Cache112 KB
Level 2 Cache1 MB
Number of Cores / Threads2 / 2
Power Consumption (TDP = Thermal Design Power)4.3 Watt
Manufacturing Technology22 nm
Max. Temperature105 °C
SocketFCBGA1170
FeaturesIntel HD Graphics (Bay Trail, 313 - 750 MHz), Wireless Display, Quick Sync, Speedstep
GPUIntel HD Graphics (Bay Trail) (313 - 750 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$107 U.S.
Announcement Date02/23/2014
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
65 Points (0%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -52%
...
AMD E1-2100
35.62 -45%
Intel Celeron N2805
44 -32%
AMD E1-2500
44 -32%
AMD E1-6010
45.67 -30%
Intel Celeron N2815
55.5 -15%
Intel Celeron N2806
58 -11%
Intel Celeron N2820
58 -11%
Intel Celeron N2810
59 -9%
Intel Celeron N3050
61.2 -6%
Intel Celeron N2807
65
Intel Celeron N2830
68.3 5%
Intel Celeron N3060
71.8 10%
Intel Pentium 2129Y
72 11%
Intel Core 2 Duo SU7300
72.2 11%
Intel Celeron N2840
73.7 13%
AMD A6 Pro-7050B
81.5 25%
AMD E2-9000
84 29%
Intel Celeron N3350
85.4 31%
AMD A6-9220e
86 32%
...
AMD Ryzen 9 7945HX3D
5600 8515%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 24272%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
35 Points (10%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -46%
...
Intel Celeron N3150
32 -9%
AMD A4-5000
32.29 -8%
Intel Celeron N2815
32.5 -7%
Intel Celeron N2920
32.5 -7%
Intel Pentium N3510
33 -6%
Intel Celeron N3050
33.07 -6%
AMD A4 Micro-6400T
34 -3%
Intel Celeron N2820
34.3 -2%
Intel Celeron N2930
34.8 -1%
Intel Celeron N2807
35
Intel Celeron N2940
35.5 1%
Intel Atom x5-Z8500
35.75 2%
Intel Atom x5-Z8550
36 3%
AMD E2-7110
37 6%
Intel Atom Z3795
37 6%
Intel Pentium N3700
37.4 7%
AMD A4-6210
37.5 7%
Intel Atom x7-Z8700
37.5 7%
Intel Celeron N2830
37.57 7%
...
AMD Ryzen 9 7945HX3D
311 789%
max:
Intel Core Ultra 9 285K
355.5 916%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
0.5 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
0.3 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
986 points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
2093 points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
3047 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
1584 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
1763 s (21%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
57.4 s (12%)
+ 1 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
408 points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
3.2 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
17 fps (4%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Serpent
0 GB/s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
0.1 GB/s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
0.1 GB/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
38.8 s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
84.7 s (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
1806 s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
976 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
6368 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
548 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
1089 points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Single-Core
688 points (13%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Stream
2249 Points (18%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Memory
1974 Points (18%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Floating Point
1391 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Integer
1576 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Total Score
1658 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
