Intel Celeron N2820

Intel N2820

Intel Celeron N2820是一款为入门级笔记本电脑设计的高能效双核整合系统芯片。它属于Bay Trail-M平台，运行于最高2.4GHz。得利于特别优化设计的22纳米低功耗制程（P1271）和三栅极晶体管技术，它的性能和能效明显高于前代Intel Atom处理器产品。 架构 它的处理器核心基于新的Silvermont架构，它第一次采用了乱序执行技术的设计。更高的流水线利用率和很多其他的改进（优化的分支预测，缓存的提升，加强的解码器）帮助单位频率性能提升了约50%。不过，相对于前代，它没有采用超线程技术。其他重要改进还有新增加的对SSE 4.1和4.2，AES-NI指令集的支持（根据型号）。 性能 得力于四个处理器核心更高的单位时钟频率性能，Celeron N2820明显快于前代的Intel Atom处理器如N2850。它的表现可以与较老的处理器如AMD Turion RM-72竞争。它的性能足够满足日常应用如上网和办公，但不适合大型软件和最新游戏。 图形 HD Graphics（Bay Trail）基于同样使用在Ivy Bridge系列处理器中（如HD Graphics 4000）的Intel Gen7架构，支持DirectX 11。由于只有4个执行单元（EU）和756MHz的较低运行频率，它的性能低于HD Graphics（Ivy Bridge）。因此，只有较老和要求较低的Windows游戏可以流畅运行。 功耗 这块整合系统芯片的热设计功率为7.5W。因此，它可以用于紧凑设计的轻薄笔记本电脑和变形本中。

SeriesIntel Celeron
CodenameBay Trail-M

Series: Celeron Bay Trail-M

Intel Celeron N29401.83 - 2.25 GHz4 / 4 cores
Intel Celeron N29301.83 - 2.16 GHz4 / 4 cores
Intel Celeron N29201.86 - 2 GHz4 / 4 cores
Intel Celeron N28402.16 - 2.58 GHz2 / 2 cores
Intel Celeron N29101.6 GHz4 / 4 cores
Intel Celeron N28302.16 - 2.41 GHz2 / 2 cores
Intel Celeron N2820 « 2.17 - 2.39 GHz2 / 2 cores
Intel Celeron N28151.86 - 2.13 GHz2 / 2 cores
Intel Celeron N28102 GHz2 / 2 cores
Intel Celeron N28081.58 - 2.25 GHz2 / 2 cores
Intel Celeron N28071.58 - 2.16 GHz2 / 2 cores
Intel Celeron N28061.58 - 2 GHz2 / 2 cores
Intel Celeron N28051.46 GHz2 / 2 cores
Clock Rate2170 - 2390 MHz
Level 1 Cache112 KB
Level 2 Cache1 MB
Number of Cores / Threads2 / 2
Power Consumption (TDP = Thermal Design Power)7.5 Watt
Manufacturing Technology22 nm
Max. Temperature105 °C
SocketFCBGA1170
FeaturesHD Graphics (Bay Trail, 313 - 756 MHz), Wireless Display, Speedstep
GPUIntel HD Graphics (Bay Trail) (313 - 756 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$107 U.S.
Announcement Date12/01/2013
Product Link (external)ark.intel.com

Benchmarks

Performance Rating - CB R15 + R20 + 7-Zip + X265 + Blender + 3DM11 CPU
8.4 pt (12%)
AMD E1-2100
2.47 -71%
Intel Celeron N2820
8.38
AMD A4-5000
11.6 38%
Intel Celeron N3350
11.6 38%
Intel Atom x7-E3950
12.4 48%
AMD A6-5200
13.7 63%
AMD A4-5150M
14.4 72%
Intel Celeron N4000
15.2 81%
AMD A10-4600M
15.8 89%
Intel Celeron N4020
16.1 92%
Intel Celeron N4100
16.3 95%
...
AMD Ryzen 9 7945HX3D
57 580%
max:
AMD Ryzen Threadripper PRO 7995WX
72.1 760%
0%
100%
Cinebench R23 - Cinebench R23 Multi Core
347 Points (0%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD E1-2100
202 -42%
Intel Celeron N3350
328 -5%
Intel Celeron N2820
347
Intel Core 2 Duo SU7300
392 13%
Intel Atom x7-Z8750
612 76%
Intel Celeron N4020
616 78%
AMD A4-5000
651 88%
Intel Celeron N4500
709 104%
Intel Celeron N6211
735 112%
Intel Pentium B970
792 128%
AMD A10-5745M
830 139%
Qualcomm Snapdragon 7c
830 139%
...
AMD Ryzen 9 7945HX3D
32782 9347%
max:
AMD Ryzen Threadripper PRO 7995WX
107681 30932%
0%
100%
Cinebench R23 - Cinebench R23 Single Core
173 Points (7%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A10-5745M
74.4 -57%
AMD E1-2100
114 -34%
Intel Celeron N2820
173
AMD A4-5000
180 4%
Intel Atom x7-Z8750
208 20%
Intel Core 2 Duo SU7300
208 20%
AMD A6-5200
239 38%
Intel Celeron N3350
252 46%
Qualcomm Snapdragon 7c Gen 2
307 77%
Intel Celeron N4020
308 78%
Qualcomm Snapdragon 7c
321 86%
Intel Celeron N4100
386.5 123%
...
Intel Core i7-13800H
2017 1066%
max:
Intel Core i9-14900K
2351 1259%
0%
100%
Cinebench R20 - Cinebench R20 CPU (Single Core)
79 Points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R20 - Cinebench R20 CPU (Multi Core)
143 Points (0%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 46     avg: 58     median: 58 (0%)     max: 70 Points
+ 2 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -47%
AMD A4-1250
32.5 -44%
AMD E1-2100
35.62 -39%
Intel Celeron N2805
44 -24%
AMD E1-2500
44 -24%
AMD E1-6010
45.67 -21%
Intel Celeron N2815
55.5 -4%
Intel Celeron N2820
58
Intel Celeron N2810
59 2%
Intel Celeron N3050
61.2 6%
Intel Celeron N2807
65 12%
Intel Celeron N2830
68.3 18%
Intel Celeron N3060
71.8 24%
Intel Pentium 2129Y
72 24%
Intel Core 2 Duo SU7300
72.2 24%
Intel Celeron N2840
73.7 27%
AMD A6 Pro-7050B
81.5 41%
...
AMD Ryzen 9 7945HX3D
5600 9555%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 27214%
0%
100%
05101520253035404550556065Tooltip
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 26     avg: 34.3     median: 37.9 (11%)     max: 39 Points
+ 3 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -45%
...
Intel Celeron N2810
31 -10%
AMD A6-9220e
31 -10%
Intel Celeron N3150
32 -7%
AMD A4-5000
32.29 -6%
Intel Celeron N2815
32.5 -5%
Intel Celeron N2920
32.5 -5%
Intel Pentium N3510
33 -4%
Intel Celeron N3050
33.07 -4%
AMD A4 Micro-6400T
34 -1%
Intel Celeron N2820
34.3
Intel Celeron N2930
34.8 1%
Intel Celeron N2807
35 2%
Intel Celeron N2940
35.5 3%
Intel Atom x5-Z8500
35.75 4%
Intel Atom x5-Z8550
36 5%
Intel Atom Z3795
37 8%
AMD E2-7110
37 8%
Intel Pentium N3700
37.4 9%
Intel Atom x7-Z8700
37.5 9%
...
AMD Ryzen 9 7945HX3D
311 807%
max:
Intel Core i9-14900K
332 868%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 0.51     avg: 0.7     median: 0.7 (1%)     max: 0.87 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.29     avg: 0.4     median: 0.4 (9%)     max: 0.43 Points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 900     avg: 1061     median: 1061 (6%)     max: 1222 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 1635     avg: 2010     median: 2010 (1%)     max: 2385 points
+ 2 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
3243 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
1672 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
1543 s (18%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
48.5 s (10%)
+ 1 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
675 points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
7-Zip 18.03 - 7-Zip 18.03 Multli Thread 4 runs
2891 MIPS (2%)
+ 1 benchmarks and specifications   + Show comparison chart
7-Zip 18.03 - 7-Zip 18.03 Single Thread 4 runs
1643 MIPS (20%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
5.8 fps (2%)
+ 1 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
26.5 fps (6%)
+ 1 benchmarks and specifications   + Show comparison chart
HWBOT x265 Benchmark v2.2 - HWBOT x265 4k Preset
0.4 fps (1%)
+ 1 benchmarks and specifications   + Show comparison chart
000.10.10.20.20.20.30.30.40.40.40.50.50.60.60.60.70.70.8Tooltip
TrueCrypt - TrueCrypt Serpent
0.1 GB/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
0.1 GB/s (2%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
0.1 GB/s (0%)
+ 1 benchmarks and specifications   + Show comparison chart
Blender - Blender 2.79 BMW27 CPU *
9415 Seconds (66%)
+ 1 benchmarks and specifications   + Show comparison chart
R Benchmark 2.5 - R Benchmark 2.5 *
3.1 sec (67%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
1418 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
36.5 s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
81.4 s (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
1696 s (8%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
967 Points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
5790 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Physics
10079 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Unlimited Physics
12137 Points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
min: 196     avg: 521     median: 520.5 (1%)     max: 845 Points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Single-Core
221 points (9%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD E1-2100
125 -43%
AMD A4-5000
193 -13%
Intel Core 2 Duo SU7300
207 -6%
Intel Celeron N2820
221
Intel Atom x7-Z8750
233 5%
AMD A6-5200
248 12%
Intel Celeron J3455
293 33%
Intel Celeron N3350
320 45%
Intel Pentium N4200
345 56%
Qualcomm Snapdragon 835 (8998)
386 75%
AMD A10-5745M
388 76%
AMD A8-5550M
395 79%
Intel Celeron J4115
399 81%
...
Apple M3 Pro 11-Core
2331 955%
0%
100%
Geekbench 5.5 - Geekbench 5.1 - 5.4 64 Bit Multi-Core
405 points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.0 - Geekbench 5.0 64 Bit Single-Core
215 points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 5.0 - Geekbench 5.0 64 Bit Multi-Core
393 points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Single-Core
min: 1093     avg: 1094     median: 1094 (11%)     max: 1095 points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 4.4 - Geekbench 4.1 - 4.4 64 Bit Multi-Core
min: 1761     avg: 1763     median: 1762.5 (2%)     max: 1764 points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
1553 points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Single-Core
879 points (17%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Multi-Core
1677 points (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 64 Bit Single-Core
950 points (14%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Stream
2406 Points (19%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Memory
2077 Points (19%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Floating Point
2008 Points (4%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Integer
2304 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Total Score
2165 Points (6%)
+ 1 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
4659 ms (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
min: 372.9     avg: 522     median: 522 (6%)     max: 671 ms
+ 2 benchmarks and specifications   + Show comparison chart
WebXPRT 4 - WebXPRT 4 Score
29.1 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
WebXPRT 3 - WebXPRT 3 Score
41.1 Points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.28
log 26. 04:00:58

#0 no ids found in url (should be separated by "_") +0s ... 0s

#1 not redirecting to Ajax server +0s ... 0s

#2 did not recreate cache, as it is less than 5 days old! Created at Tue, 25 Jun 2024 05:30:22 +0200 +0.001s ... 0.001s

#3 no comparison url found in template nbc.compare_page_2 needed +0.005s ... 0.006s

#4 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#10 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#11 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#12 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#13 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#14 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.007s

#15 composed specs +0s ... 0.008s

#16 did output specs +0s ... 0.008s

#17 getting avg benchmarks for device 4991 +0.013s ... 0.021s

#18 got single benchmarks 4991 +0.013s ... 0.034s

#19 got avg benchmarks for devices +0s ... 0.034s

#20 min, max, avg, median took s +0.902s ... 0.935s

#21 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.936s

#22 return log +0s ... 0.936s

Reviews for the Intel Celeron N2820 processor

HP Pavilion 11-n071eg x360: Intel HD Graphics (Bay Trail), 11.60", 1.4 kg
  External Review » HP Pavilion 11-n071eg x360

HP Pavilion 11-n070eg x360: Intel HD Graphics (Bay Trail), 11.60", 1.5 kg
  External Review » HP Pavilion 11-n070eg x360

HP Pavilion 11-N000eo X360: Intel HD Graphics (Haswell), 11.60", 1.4 kg
  External Review » HP Pavilion 11-N000eo X360

Toshiba Satellite NB10t-A-10F: Intel HD Graphics (Bay Trail), 11.60", 1.3 kg
  External Review » Toshiba Satellite NB10t-A-10F

Toshiba Satellite C55-A5140: Intel HD Graphics (Bay Trail), 15.60", 2.3 kg
  External Review » Toshiba Satellite C55-A5140

HP Pavilion 11-n008tu x360: Intel HD Graphics (Haswell), 11.60", 1.4 kg
  External Review » HP Pavilion 11-n008tu x360

Please share our article, every link counts!

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series Celeron

» Intel Celeron 2970M
   2x 2.2 GHz
» Intel Celeron 4205U
   2x 1.8 GHz
» Intel Celeron 1020E
   2x 2.2 GHz
» Intel Celeron 3765U
   2x 1.9 GHz
» Intel Celeron 2950M
   2x 2 GHz
» Intel Celeron 1020M
   2x 2.1 GHz
» Intel Celeron 3755U
   2x 1.7 GHz
» Intel Celeron 3215U
   2x 1.7 GHz
» Intel Celeron 1005M
   2x 1.9 GHz
» Intel Celeron 1000M
   2x 1.8 GHz
» Intel Celeron 1037U
   2x 1.8 GHz
» Intel Celeron 2981U
   2x 1.6 GHz
» Intel Celeron 2980U
   2x 1.6 GHz
» Intel Celeron B840
   2x 1.9 GHz
» Intel Celeron J3455
   4x 1.5 GHz - 2.3 GHz
» Intel Celeron N3450
   4x 1.1 GHz - 2.2 GHz
» Intel Celeron B830
   2x 1.8 GHz
» Intel Celeron 1017U
   2x 1.6 GHz
» Intel Celeron 3205U
   2x 1.5 GHz
» Intel Celeron B820
   2x 1.7 GHz
» Intel Celeron J1900
   4x 2 GHz - 2.42 GHz
» Intel Celeron N2940
   4x 1.83 GHz - 2.25 GHz
» Intel Celeron N3160
   4x 1.6 GHz - 2.24 GHz
» Intel Celeron 2957U
   2x 1.4 GHz
» Intel Celeron 2955U
   2x 1.4 GHz
» Intel Celeron J3355
   2x 2 GHz - 2.5 GHz
» Intel Celeron N3350
   2x 1.1 GHz - 2.4 GHz
» Intel Celeron 1007U
   2x 1.5 GHz
» Intel Celeron N3150
   4x 1.6 GHz - 2.08 GHz
» Intel Celeron N2930
   4x 1.83 GHz - 2.16 GHz
» Intel Celeron J1850
   4x 2 GHz
» Intel Celeron B815
   2x 1.6 GHz
» Intel Celeron B810
   2x 1.6 GHz
» Intel Celeron N2920
   4x 1.86 GHz - 2 GHz
» Intel Celeron 1047UE
   2x 1.4 GHz
» Intel Celeron 887
   2x 1.5 GHz
» Intel Celeron B800
   2x 1.5 GHz
» Intel Celeron J1800
   2x 2.41 GHz - 2.58 GHz
» Intel Celeron N2840
   2x 2.16 GHz - 2.58 GHz
» Intel Celeron J1750
   2x 2.41 GHz
» Intel Celeron N3060
   2x 1.6 GHz - 2.48 GHz
» Intel Celeron N2910
   4x 1.6 GHz
» Intel Celeron N2830
   2x 2.16 GHz - 2.41 GHz
» Intel Celeron N2820
   2x 2.17 GHz - 2.39 GHz
» Intel Celeron N3050
   2x 1.6 GHz - 2.16 GHz
» Intel Celeron N2815
   2x 1.86 GHz - 2.13 GHz
» Intel Celeron N3000
   2x 1.04 GHz - 2.08 GHz
» Intel Celeron N2810
   2x 2 GHz
» Intel Celeron 2961Y
   2x 1.1 GHz
» Intel Celeron 877
   2x 1.4 GHz
» Intel Celeron 867
   2x 1.3 GHz
» Intel Celeron B730
   1x 1.8 GHz
» Intel Celeron 1019Y
   2x 1 GHz
» Intel Celeron 847
   2x 1.1 GHz
» Intel Celeron 807
   1x 1.5 GHz
» Intel Celeron B720
   1x 1.7 GHz
» Intel Celeron N2808
   2x 1.58 GHz - 2.25 GHz
» Intel Celeron 927UE
   1x 1.5 GHz
» Intel Celeron N2807
   2x 1.58 GHz - 2.16 GHz
» Intel Celeron N2806
   2x 1.58 GHz - 2 GHz
» Intel Celeron B710
   1x 1.6 GHz
» Intel Celeron 797
   1x 1.4 GHz
» Intel Celeron N2805
   2x 1.46 GHz

Surrounding CPUs

+ Intel Core i5-430UM
   2x 1.2 GHz - 1.73 GHz
+ AMD A6-4455M
   2x 2.1 GHz - 2.6 GHz
+ AMD A4-5145M
   2x 2 GHz - 2.6 GHz
+ AMD A4-4355M
   2x 1.9 GHz - 2.4 GHz
+ Intel Celeron N2830
   2x 2.16 GHz - 2.41 GHz
» Intel Celeron N2820
   2x 2.17 GHz - 2.39 GHz
- Intel Celeron N3050
   2x 1.6 GHz - 2.16 GHz
- Intel Celeron N2815
   2x 1.86 GHz - 2.13 GHz
- Intel Celeron N3000
   2x 1.04 GHz - 2.08 GHz
- Intel Celeron N2810
   2x 2 GHz
- Intel Core 2 Duo T5470
   2x 1.6 GHz
> Notebookcheck中文版（NBC中国） > FAQ / 小提示/ 技术参数 > 移动处理器 —— 基准测试成绩列表 > Intel Celeron N2820 笔记本处理器
Klaus Hinum (Update: 2014-07-30)
