Intel Core M-5Y10

Intel 5Y10

Intel Core M-5Y10是一款超低电压（ULV）双核整合芯片，基于Broadwell及足够，在2014年9月发布。由于热设计功率仅4.5W，这款处理器适合于被动散热的平板电脑和二合一笔记本电脑。除了两个支持超线程，运行于0.8-2.0GHz的两个处理器核心，它的芯片中还继承了一个HD Graphics 5300显卡，和一个双通道LPDDR3/DDR3L(-RS)内存控制器，最大带宽25.6GB/s。它采用了14纳米制程和FinFET晶体管技术。


Core M-5Y10支持“TDP降设”到可选的4.0W热设计功率，但相似的5Y10a型号则不支持。


架构


Broadwell是Intel的滴答模式中的“滴”，这意味着它是基于前代Haswell架构进行了制程缩减。新的14纳米支撑技术配合三维FinFET晶体管技术不仅提高了能效，也帮助芯片尺寸得到了明显减小，让设备可以更加紧凑。


其他的优势来自于Broadwell在系统微架构上面的改进。由于在分支预测上得到了优化，加上采用了更大的缓存容量（L2 TLB中1500个条目相比前代的1000个）和其他的优化，它的单位时钟频率性能相比前代产品有了超过5%的提升。它同样提供了为加密应用设计的一些新指令集的支持。


性能


Core M-5Y10在时钟频率上有很大的加速范围，从0.8到2.0GHz；它的实际运行频率很大程度上取决于热设计功率的限制。尽管这款处理器在短时间的测试中与Core i5-4202Y（Haswell架构，11.5W）相当，但在长时间的负载下，它的性能将开始下降。相应的，Broadwell的更高能效的设计目的也在于降低功耗而非提高性能表现。


整体上，Core M-5Y10的性能足够办公和多媒体用途的需求，也可以满足大型应用程序的性能需要。


图形


集成的HD Graphics 5300提供了24个执行单元（EU），运行于100到850MHz。与处理器核心相似的是，它的显卡架构（Intel Gen 8）也在单位时钟频率性能上得到了改进。不过，这款显卡的运行频率同样由热设计功率限制，这会影响到它相比较老的HD 4200在持续3D负载下的性能优势。2014年的最新游戏可以在低设定和XGA分辨率下运行。


Broadwell是Intel的第一块全面支持DirectX 11.2和OpenCL 1.3/2.0与OpenGL 4.3的芯片。它的原生视频信号可以通过DisplayPort 1.2或HDMI 1.4a输出。不过，它并不支持最新的HDMI 2.0标准。


功耗


Core M-5Y10的热设计功率仅为4.5W（可降低到4.0W），它的功耗远低于Haswell架构的Y系列处理器（11.5W）。这款处理器可以通过被动散热使用于轻薄平板中。

CodenameBroadwell
SeriesIntel Core M

Series: Core M Broadwell

Intel Core M-5Y711.2 - 2.9 GHz2 / 4 cores4 MB L3
Intel Core M-5Y511.1 - 2.6 GHz2 / 4 cores4 MB L3
Intel Core M-5Y701.1 - 2.6 GHz2 / 4 cores4 MB L3
Intel Core M-5Y310.9 - 2.4 GHz2 / 4 cores4 MB L3
Intel Core M-5Y10c0.8 - 2 GHz2 / 4 cores4 MB L3
Intel Core M-5Y10a0.8 - 2 GHz2 / 4 cores4 MB L3
Intel Core M-5Y10 « 0.8 - 2 GHz2 / 4 cores4 MB L3
Clock Rate800 - 2000 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)4.5 Watt
Transistor Count1300 Million
Manufacturing Technology14 nm
Die Size82 mm2
Max. Temperature95 °C
SocketBGA
FeaturesHD Graphics 5300 (100 - 800 MHz), Dual-Channel DDR3L(-RS)/LPDDR3 Memory Controller (max. 800 MHz, 25.6 GB/s), HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel HD Graphics 5300 (100 - 800 MHz)
64 Bit64 Bit support
Architecturex86
Announcement Date09/05/2014
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
min: 139     avg: 153.6     median: 155 (1%)     max: 167 Points
+ 5 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -80%
...
AMD E2-7110
140 -9%
Intel Celeron 3865U
142 -8%
Intel Core i5-4210Y
145.8 -5%
Intel Celeron N3450
146.8 -4%
Intel Core M-5Y51
149.7 -3%
Intel Core i3-3217U
152 -1%
AMD A10-7300
152 -1%
Intel Core i3-4020Y
152 -1%
AMD FX-7500
153 0%
Intel Core M-5Y10
153.6
AMD A6-5200
155.5 1%
Intel Pentium N3540
155.5 1%
AMD A4-7210
157 2%
AMD A6-6310
157 2%
Intel Pentium N4200
157.2 2%
Intel Core M-5Y10c
158.3 3%
AMD A10 Pro-7350B
160 4%
Intel Celeron 6305
161.1 5%
Intel Core i5-3339Y
163 6%
...
AMD Ryzen 9 7945HX3D
5600 3546%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 10214%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
min: 63     avg: 77.4     median: 81 (23%)     max: 82 Points
+ 5 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -75%
...
AMD FX-7600P
74.3 -4%
AMD A10-9600P
74.8 -3%
AMD A10-5750M
75.5 -2%
AMD PRO A12-9800B
75.7 -2%
AMD A9-9425
76 -2%
Intel Celeron N6211
76 -2%
Intel Core i5-4300Y
77 -1%
Intel Core i3-4158U
77 -1%
Intel Pentium 3825U
77 -1%
Intel Core M-5Y10
77.4
Intel Pentium Silver N5000
77.5 0%
AMD A12-9700P
79 2%
Intel Core i3-2350M
79 2%
AMD Ryzen 3 2300U
79 2%
Intel Core i3-6006U
80 3%
AMD A9-9420
80.3 4%
Intel Pentium Silver N5030
80.9 5%
Intel Core m3-6Y30
81 5%
AMD FX-8800P
81.3 5%
...
AMD Ryzen 9 7945HX3D
311 302%
max:
Intel Core Ultra 9 285K
355.5 359%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
min: 1.53     avg: 1.7     median: 1.7 (2%)     max: 1.8 Points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
min: 0.92     avg: 0.9     median: 1 (23%)     max: 0.95 Points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
min: 2830     avg: 3053     median: 3102 (19%)     max: 3130 points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
min: 4964     avg: 5235     median: 5217 (4%)     max: 5625 points
+ 5 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
7072 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
4159 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
min: 1098     avg: 1117     median: 1116.5 (13%)     max: 1135 s
+ 2 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
min: 25.64     avg: 30.9     median: 30.9 (6%)     max: 36.2 s
+ 2 benchmarks and specifications   + Show comparison chart
WinRAR - WinRAR 4.0
min: 1926     avg: 1952     median: 1951.5 (3%)     max: 1977 points
+ 2 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 2
min: 8.7     avg: 9.6     median: 9.6 (3%)     max: 10.5 fps
+ 2 benchmarks and specifications   + Show comparison chart
X264 HD Benchmark 4.0 - x264 Pass 1
min: 52.9     avg: 55.6     median: 55.6 (13%)     max: 58.3 fps
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Serpent
min: 0.105     avg: 0.1     median: 0.1 (3%)     max: 0.111 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
min: 0.175     avg: 0.2     median: 0.2 (3%)     max: 0.194 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
min: 1.1     avg: 1.2     median: 1.2 (3%)     max: 1.2 GB/s
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - CPU - 3DMark 06 - CPU
min: 1903     avg: 2066     median: 1987 (4%)     max: 2307 Points
+ 3 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
min: 19.08     avg: 22.1     median: 22.1 (5%)     max: 25.16 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
min: 43.09     avg: 49.2     median: 49.1 (2%)     max: 55.2 s
+ 2 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
min: 971     avg: 974     median: 973.5 (4%)     max: 976 s
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
min: 1895     avg: 2158     median: 2171 (5%)     max: 2480 Points
+ 5 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
min: 18980     avg: 20947     median: 20080 (16%)     max: 24168 Points
+ 5 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
min: 1628     avg: 1811     median: 1838 (5%)     max: 1980 Points
+ 5 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Physics
min: 2299     avg: 2558     median: 2595 (5%)     max: 2786 Points
+ 5 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Multi-Core
min: 3293     avg: 3775     median: 3853.5 (7%)     max: 4098 points
+ 4 benchmarks and specifications   + Show comparison chart
Geekbench 3 - Geekbench 3 32 Bit Single-Core
min: 1934     avg: 2003     median: 2007.5 (39%)     max: 2064 points
+ 4 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Stream
min: 4887     avg: 5598     median: 5597.5 (45%)     max: 6308 Points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Memory
min: 4280     avg: 4465     median: 4464.5 (40%)     max: 4649 Points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Floating Point
min: 4272     avg: 4361     median: 4361 (9%)     max: 4450 Points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Integer
min: 4050     avg: 4111     median: 4110.5 (8%)     max: 4171 Points
+ 2 benchmarks and specifications   + Show comparison chart
Geekbench 2 - 32 Bit - Geekbench Total Score
min: 4362     avg: 4418     median: 4417.5 (12%)     max: 4473 Points
+ 2 benchmarks and specifications   + Show comparison chart
Mozilla Kraken 1.1 - Kraken 1.1 Total Score *
min: 3302     avg: 3365     median: 3310 (4%)     max: 3581 ms
+ 5 benchmarks and specifications   + Show comparison chart
Sunspider - Sunspider 1.0 Total Score *
min: 157     avg: 168.9     median: 166.9 (2%)     max: 185.4 ms
+ 5 benchmarks and specifications   + Show comparison chart
Octane V2 - Octane V2 Total Score
min: 8474     avg: 9240     median: 9354 (8%)     max: 9622 Points
+ 5 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

v1.28
log 23. 23:01:19

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Fri, 22 Nov 2024 05:30:53 +0100 +0.001s ... 0.001s

#4 no comparison url found in template nbc.compare_page_2 needed +0.005s ... 0.006s

#5 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#6 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#7 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#8 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#9 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.006s

#10 composed specs +0s ... 0.006s

#11 did output specs +0s ... 0.006s

#12 getting avg benchmarks for device 6369 +0.003s ... 0.009s

#13 got single benchmarks 6369 +0.014s ... 0.023s

#14 got avg benchmarks for devices +0s ... 0.023s

#15 min, max, avg, median took s +0.578s ... 0.601s

#16 no comparison url found in template nbc.compare_page_2 needed +0s ... 0.601s

#17 return log +0s ... 0.601s

Reviews for the Intel Core M-5Y10 processor

华硕 Zenbook UX305 亚笔记本简短评测

华硕 Zenbook UX305 亚笔记本简短评测

修身。 它到底薄了多少？在这个仅厚12毫米的轻盈机身之中，Core M处理器得到了最大程度的发挥。它在性能上落后于Haswell架构的竞争者，且这台Zenbook在电池续航方面都表现平平。不过它的输入设备，制造工艺，噪音散热，以及（同样重要的）价格都让它值得考虑。...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 13.30" | 1.3 kg
戴尔 Latitude 13 7350 变形本简短评测

戴尔 Latitude 13 7350 变形本简短评测

超极变形本。 戴尔Latitude 13 7350结合了超极本，平板和变形本的元素。安静的运行加上高质量键盘和长电池续航让它十分适合商务用户使用。...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 13.30" | 1.7 kg
惠普 Envy x2 15-c000ng 变形本简短评测

惠普 Envy x2 15-c000ng 变形本简短评测

无风扇。 惠普的这款15.6寸变形本希望靠超高能效的Intel新Broadwell系列处理器吸引用户的目光，它也帮助这款Envy系列的平板得以采用无风扇的散热设计。这款设备同时还有全高清的IPS屏幕和优秀的电池续航。...
Intel Core M-5Y10 | Intel HD Graphics 5300 | 15.60" | 2.5 kg

Asus UX305FA-FB041H: Intel HD Graphics 5300, 13.30", 1.2 kg
  External Review » Asus UX305FA-FB041H

Asus Transformer Book T300FA-FE001H: Intel HD Graphics 5300, 12.50", 1.6 kg
  External Review » Asus Transformer Book T300FA-FE001H

Asus Zenbook UX305FA-FC007H: Intel HD Graphics 5300, 13.30", 1.2 kg
  External Review » Asus Zenbook UX305FA-FC007H

HP Envy x2 15-c000ng: Intel HD Graphics 5300, 15.60", 2.5 kg
  External Review » HP Envy x2 15-c000ng

Asus Zenbook UX305FA-ASM1: Intel HD Graphics 5300, 13.30", 1.3 kg
  External Review » Asus Zenbook UX305FA-ASM1

Asus Zenbook UX305FA-FC008H: Intel HD Graphics 5300, 13.30", 1.2 kg
  External Review » Asus Zenbook UX305FA-FC008H

HP Envy X2-j001nf: Intel HD Graphics 5300, 13.30", 1.8 kg
  External Review » HP Envy X2-j001nf

Dell Latitude 13 7350: Intel HD Graphics 5300, 13.30", 1.7 kg
  External Review » Dell Latitude 13 7350

Asus ZenBook UX305FA-FB003H: Intel HD Graphics 5300, 13.30", 1.3 kg
  External Review » Asus ZenBook UX305

Please share our article, every link counts!
Mail Logo

»移动处理器 对比
所有移动处理器的对比


»移动处理器 基准测试
所有已有笔记本电脑中使用的处理器的基准测试成绩 (桌面处理器或移动处理器)

Other CPUs of the series Core M

» Intel Core M-5Y71
   2x 1.2 GHz - 2.9 GHz
» Intel Core M-5Y51
   2x 1.1 GHz - 2.6 GHz
» Intel Core M-5Y70
   2x 1.1 GHz - 2.6 GHz
» Intel Core M-5Y31
   2x 0.9 GHz - 2.4 GHz
» Intel Core M-5Y10c
   2x 0.8 GHz - 2 GHz
» Intel Core M-5Y10a
   2x 0.8 GHz - 2 GHz
» Intel Core M-5Y10
   2x 0.8 GHz - 2 GHz

Surrounding CPUs

+ AMD 3015Ce
   2x 1.2 GHz - 2.3 GHz
+ Intel Celeron N4120
   4x 1.1 GHz - 2.6 GHz
+ Intel Core M-5Y10c
   2x 0.8 GHz - 2 GHz
+ Intel Core M-5Y10a
   2x 0.8 GHz - 2 GHz
+ AMD Phenom II X4 X920 BE
   4x 2.3 GHz
» Intel Core M-5Y10
   2x 0.8 GHz - 2 GHz
- Intel Core 2 Quad Q9000
   4x 2 GHz
- Intel Core i7-2617M
   2x 1.5 GHz - 2.6 GHz
- Intel Core i5-3439Y
   2x 1.5 GHz - 2.3 GHz
- AMD A9-9425
   2x 3.1 GHz - 3.7 GHz
- AMD A9-9420e
   2x - 2.5 GHz
Klaus Hinum (Update: 2014-11-26)
