Intel Core i5-5350H

Intel 5350H

Intel Core i7-5350H是一颗基于Broadwell架构的高速双核处理器,在2015年6月发布。除了两颗运行于3.0-3.5GHz(2核心:同为3.5GHz)支持超线程技术的核心之外,这块芯片中还集成了一颗Iris Pro Graphics 6200显卡,搭配集成eDRAM显存和双通道LPDDR3-1866/DDR3L-1600内存控制器。这颗Core i7处理器基于14纳米制程的FinFET半导体技术。

架构

Broadwell是Intel的滴答模式中的“滴”,这意味着它是基于前代Haswell架构进行了制程缩减。新的14纳米支撑技术配合三维FinFET晶体管技术不仅提高了能效,也帮助芯片尺寸得到了明显减小,让设备可以更加紧凑。

其他的优势来自于Broadwell在系统微架构上面的改进。由于在分支预测上得到了优化,加上采用了更大的缓存容量(L2 TLB中1500个条目相比前代的1000个)和其他的优化,它的单位时钟频率性能相比前代产品有了超过5%的提升。它同样提供了为加密应用设计的一些新指令集的支持。

性能

得力于改进的架构,Core i7-5350H提供了与Haswell架构Core i7-4610M(3.0-3.7GHz)相似的性能,是2015年中期最快的双颗处理器之一。因此这颗处理器有足够的性能运行大型软件以及应对繁重的多任务处理。

图形

集成的Iris Pro Graphics 6200(GT3e)提供了48个执行核心(EU),时钟频率为300-1050MHz,可以访问独立的128MB eDRAM显存。作为集成显卡,Iris Pro Graphics 6200达到了不凡的性能水平,可以与中低端独立显卡如GeFore 940M竞争。不过,2015年的大型游戏仍然只能在中低设定下运行。

Broadwell是Intel第一款完全支持DirectX 11.2和OpenCL 1.3/2.0以及OpenGL 4.3的芯片。视频信号可以通过DisplayPort 1.2或HDMI 1.4a输出。不过,它并不支持最新的HDMI 2.0标准。

功耗

i7-5350H的热设计功率为47瓦,包含显卡,内存控制器和VRM。不过,仅使用运算核心时的功耗会显著降低。因此,这款处理器最适合15寸或更大的笔记本电脑使用。

SeriesIntel Core i5
CodenameBroadwell

Series: Core i5 Broadwell

Intel Core i5-5350H « 3 - 3.5 GHz2 / 4 cores4 MB L3
Intel Core i5-5287U2.9 - 3.3 GHz2 / 4 cores3 MB L3
Intel Core i5-5257U2.7 - 3.1 GHz2 / 4 cores3 MB L3
Intel Core i5-5300U2.3 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-5350U1.8 - 2.9 GHz2 / 4 cores3 MB L3
Intel Core i5-5200U2.2 - 2.7 GHz2 / 4 cores3 MB L3
Intel Core i5-5250U1.6 - 2.7 GHz2 / 4 cores3 MB L3
Clock Rate3000 - 3500 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)47 Watt
Manufacturing Technology14 nm
Max. Temperature105 °C
SocketBGA1364
FeaturesLPDDR3-1866/DDR3L-1600 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI
GPUIntel Iris Pro Graphics 6200 (300 - 1050 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$289 U.S.
Announcement Date06/02/2015

Benchmarks

- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
