Intel Core i7-6650U

Intel 6650U

英特尔酷睿i7-6650U是一颗ULV（超低电压）双核处理器，基于Skylake架构。 在2015年9月，它是最快的15瓦系列处理器之一（协同i7-6600U），常用于超极本或普通笔记本电脑之中。 除了两个支持超线程的CPU核心运行于2.2 -  3.4 GHz（双核：最大3.2 GHz），该芯片还集成了Iris Graphics 540显卡和64 MB的独立eDRAM内存，以及双通道DDR4- 2133 / DDR3L-1600内存控制器。 该芯片采用14纳米工艺与FinFET晶体管制造工艺。

架构

Skylake架构取代了Haswell和Broadwell，为从4.5到45瓦热设计功率的处理器都提供了相同的微架构。Skylake架构设计的众多改进包括增加了乱序缓冲，优化的预取和分支预测以及超线程模式的性能改进。 不过整体上，它的单位时钟频率性能仅增加了5%到10%（相比Haswell）而相比Broadwell架构不足5%，这对于一个新架构（“Tock”）来说十分低。

另外，eDRAM的高速缓冲存储器的设计得到了修改。 它不再作为牺牲性高速缓存，经由L3 / LLC控址，现在eDRAM可以像主内存一样直接由程序控址。 它的容量仍然只有四核机型的128 MB（4C＋GT4e），而双核芯片（2C＋GT3e）只搭配了64 MB。

性能

根据时钟速率和改进的架构，酷睿i7-6650U应当与酷睿i5-4310M（Haswell，37瓦）相当，是2015年最快的ULV双核处理器之一。 因此，这颗处理器的性能足以满足办公和多媒体用途的需要，也可以胜任复杂的应用程序和多任务处理。

图形

它的集成显示单元名为Iris Graphics 540，代表了Skylake显卡的"GT3e"版本（Intel第九代）。 它的48执行单位，也被称为EU，主频在300  -  1050 MHz之间（同时支持eDRAM缓存），性能略高于GeForce 920M独立显卡。 2015年的游戏应该可以在低中设置下流畅运行。 有关性能和功能的详细信息，请参考我们的Iris Graphics 540页面。

功耗

设计热设计功率15瓦（包括CPU，GPU和内存控制器），这款处理器最适合于小型笔记本电脑和超极本（11寸或更大）。 它的TDP也可以降低到9.5瓦（cTDP降低），从而同时降低发热量和性能，让更加紧凑的设计成为可能。

SeriesIntel Core i7
CodenameSkylake

Series: Core i7 Skylake

Intel Core i7-6920HQ2.9 - 3.8 GHz4 / 8 cores8 MB L3
Intel Core i7-6970HQ2.8 - 3.7 GHz4 / 8 cores8 MB L3
Intel Core i7-6870HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HK2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6820HQ2.7 - 3.6 GHz4 / 8 cores8 MB L3
Intel Core i7-6770HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6700HQ2.6 - 3.5 GHz4 / 8 cores6 MB L3
Intel Core i7-6567U3.3 - 3.6 GHz2 / 4 cores4 MB L3
Intel Core i7-6600U2.6 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6650U « 2.2 - 3.4 GHz2 / 4 cores4 MB L3
Intel Core i7-6560U2.2 - 3.2 GHz2 / 4 cores4 MB L3
Intel Core i7-6500U2.5 - 3.1 GHz2 / 4 cores4 MB L3
Clock Rate2200 - 3400 MHz
Level 1 Cache128 KB
Level 2 Cache512 KB
Level 3 Cache4 MB
Number of Cores / Threads2 / 4
Power Consumption (TDP = Thermal Design Power)15 Watt
Manufacturing Technology14 nm
Max. Temperature100 °C
SocketBGA
FeaturesDual-Channel DDR3L-1600/DDR4-2133 Memory Controller, HyperThreading, AVX, AVX2, Quick Sync, Virtualization, AES-NI, vPro, TXT
GPUIntel Iris Graphics 540 (300 - 1050 MHz)
64 Bit64 Bit support
Architecturex86
Starting Price$415 U.S.
Announcement Date09/01/2015
Product Link (external)ark.intel.com

Benchmarks

Cinebench R15 - Cinebench R15 CPU Multi 64 Bit
342 Points (2%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
31 -91%
...
Intel Core i5-6267U
328.3 -4%
Intel Core i5-4210H
328.3 -4%
Intel Core i3-1000NG4
333 -3%
Intel Core i3-8130U
333.3 -3%
AMD Ryzen 3 3200U
335 -2%
Intel Core i7-7560U
336 -2%
Intel Pentium Silver N6005
338 -1%
Intel Core i7-7500U
338.4 -1%
Intel Core i7-7600U
338.5 -1%
Intel Core i7-6650U
342
Intel Celeron N5095
343 0%
Intel Core i5-7300U
343.3 0%
Intel Core i5-6287U
345 1%
Intel Core i3-8145U
345.5 1%
Intel Core i3-10110U
351.8 3%
AMD Athlon Gold 3150U
352 3%
Intel Core i3-8109U
352.5 3%
AMD Ryzen 3 3250U
352.7 3%
Intel Core i7-5557U
353 3%
...
AMD Ryzen 9 7945HX3D
5600 1537%
max:
AMD Ryzen Threadripper PRO 7995WX
15842 4532%
0%
100%
Cinebench R15 - Cinebench R15 CPU Single 64 Bit
132 Points (37%)
+ 1 benchmarks and specifications   - Hide comparison chart
AMD A4-1200
19 -86%
...
Intel Core i5-8210Y
129.5 -2%
Intel Core i7-8500Y
129.8 -2%
Intel Core i3-7100H
130 -2%
Intel Core i7-4700HQ
130 -2%
Intel Core i7-4712MQ
130.4 -1%
Intel Core i5-6300HQ
130.4 -1%
Intel Core i5-6267U
130.8 -1%
Intel Core i7-6560U
131.7 0%
Intel Core i7-4710MQ
131.9 0%
Intel Core i7-6650U
132
Intel Core i7-4700MQ
132.1 0%
Intel Core i5-7Y57
133 1%
Intel Core i7-4850HQ
133 1%
Intel Core i3-8121U
133 1%
Intel Core i7-4710HQ
133.2 1%
AMD Ryzen 3 3300U
134 2%
Intel Core i7-6770HQ
134.5 2%
AMD Ryzen 5 PRO 2500U
135 2%
Intel Core i7-4720HQ
135.6 3%
...
AMD Ryzen 9 7945HX3D
311 136%
max:
Intel Core Ultra 9 285K
355.5 169%
0%
100%
Cinebench R11.5 - Cinebench R11.5 CPU Multi 64 Bit
3.8 Points (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 - Cinebench R11.5 CPU Single 64 Bit
1.5 Points (36%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (32bit)
5223 points (32%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (32bit)
11564 points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Multi (64bit)
14833 Points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
Cinebench R10 - Cinebench R10 Rend. Single (64bit)
6787 Points (8%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 1024m *
445.6 s (5%)
+ 1 benchmarks and specifications   + Show comparison chart
wPrime 2.10 - wPrime 2.0 32m *
14.9 s (3%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Serpent
0.2 GB/s (6%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt Twofish
0.3 GB/s (6%)
+ 1 benchmarks and specifications   + Show comparison chart
TrueCrypt - TrueCrypt AES
2 GB/s (5%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 1M - Super Pi mod 1.5 XS 1M *
11.7 s (3%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi mod 1.5 XS 2M - Super Pi mod 1.5 XS 2M *
26.3 s (1%)
+ 1 benchmarks and specifications   + Show comparison chart
Super Pi Mod 1.5 XS 32M - Super Pi mod 1.5 XS 32M *
613 s (3%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 11 - 3DM11 Performance Physics
4919 Points (12%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Physics
44259 Points (36%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Extreme Physics
43694 Points (35%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Ice Storm Unlimited Physics
44857 Points (37%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Cloud Gate Physics
3639 Points (9%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark - 3DMark Fire Strike Standard Physics
5372 Points (10%)
+ 1 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance
