Intel Core i7-6970HQ

英特尔酷睿i7-6970HQ是一款基于Skylake微架构的高速笔记本电脑四核处理器，在2016年年初推出。它提供了四个处理器核心（支持超线程），主频2.8-3.7 GHz（四核最高3.3 GHz的，双核最高3.5 GHz），还集成了一个高速的图形单元。Iris Pro Graphics 580 (GT4e)提供了72个EU以及128 MB的eDRAM缓存，它也可以由处理器核心调用。该芯片采用14纳米工艺与FinFET晶体管制造工艺。

与酷睿i7-6920HQ不同的是，i7-6970HQ没有搭配快很多的显卡，也不支持TSX-NI 和vPro指令集。

架构

英特尔Skylake架构取代Broadwell架构和Haswell架构，因此再次为所有TDP在4.5瓦到45瓦间处理器使用同样的核心设计。Skylake架构的几个改进包括更高的乱序缓存，更高效的超线程技术，以及优化的预读取技术。而这相比以往的架构优化幅度较小，它的单位时钟频率性能提高仅5%到10%（相比Haswell架构）或5%（相比Broadwell架构）。

i7-6970HQ在一些情况下还可以从额外的eDRAM缓存中获益，它可以帮助对内存需要较大的程序提高速度。

性能

由于额外的eDRAM缓存，i7-6970HQ甚至应该与频率更高i7-6920HQ竞争，因此它是在2016年初最快笔记本处理器之一。即使是要求最高的应用程序和繁重的多任务对这块高端处理器来说也不成问题。

图形

它集成的英特尔Iris Pro Graphics P580（GT4e）是Skylake架构显卡中（英特尔第九代）最快的之一。

它提供了运行于350到1050MHz间的72个执行单元，性能可以与主流独立显卡媲美。

在理想情况下它可以与GeForce 945M竞争，因此它是目前市场上最快的集成显卡。2015／2016年的最新游戏可以在中设定下流畅运行。有关性能和特性的更多信息，请参考我们的Iris Pro Graphics 580页面。

功耗

热设计功率45瓦的这款处理器最适合于15英寸或更大的笔记本电脑。它的热设计功率可以降低到35瓦（cTDP下调），但是这显然会影响性能。

Series

Intel Core i7

Codename

Skylake

Series: Core i7 Skylake

Intel Core i7-6920HQ	2.9 - 3.8 GHz	4 / 8	8 MB L3
Intel Core i7-6970HQ «	2.8 - 3.7 GHz	4 / 8	8 MB L3
Intel Core i7-6870HQ	2.7 - 3.6 GHz	4 / 8	8 MB L3
Intel Core i7-6820HK	2.7 - 3.6 GHz	4 / 8	8 MB L3
Intel Core i7-6820HQ	2.7 - 3.6 GHz	4 / 8	8 MB L3
Intel Core i7-6770HQ	2.6 - 3.5 GHz	4 / 8	6 MB L3
Intel Core i7-6700HQ	2.6 - 3.5 GHz	4 / 8	6 MB L3
Intel Core i7-6567U	3.3 - 3.6 GHz	2 / 4	4 MB L3
Intel Core i7-6600U	2.6 - 3.4 GHz	2 / 4	4 MB L3
Intel Core i7-6650U	2.2 - 3.4 GHz	2 / 4	4 MB L3
Intel Core i7-6560U	2.2 - 3.2 GHz	2 / 4	4 MB L3
Intel Core i7-6500U	2.5 - 3.1 GHz	2 / 4	4 MB L3

Clock Rate

2800 - 3700 MHz

Level 1 Cache

256 KB

Level 2 Cache

1 MB

Level 3 Cache

8 MB

Number of Cores / Threads

4 / 8

Power Consumption (TDP = Thermal Design Power)

45 Watt

Manufacturing Technology

14 nm

Max. Temperature

100 °C

Socket

BGA

Features

Dual-Channel DDR3L-1600/DDR4-2133 Memory Controller, AVX, AVX2, Quick Sync, Virtualization, AES-NI, TXT

GPU

Intel Iris Pro Graphics 580 (350 - 1050 MHz)

64 Bit

64 Bit support

Architecture

x86

Starting Price

$623 U.S.

Announcement Date

01/24/2016

Product Link (external)

ark.intel.com
