Intel Graphics Media Accelerator (GMA) 3150

英特尔图形媒体加速器3150或GMA3150是一个集成（共享内存）显卡，处理器包位于的英特尔Atom N4xx处理器。图形核心基于GMA X3100上设计（英特尔），但只拥有两个处理器核心，主频为200 ​​MHz。因此，性能比老的GMA 950发现在众多上网本与Atom处理器N270更是只有一点点。 GMA3150的3D性能，因此只适合于一些低在低细节要求苛刻的3D游戏。在我们的测试中，只有老“雷神之锤3：竞技场”跑流利（甚至高细节设置）。此外，火炬跑或多或少流利的800X600 - 低，但，FRAPS仅表现为10fps的。更现代的低要求苛刻的游戏，如“赛道狂飙国家永恒”或“左4人死亡只显示幻灯片。在我们的测试中，戴尔Mini1018许多现代游戏没有开始（驱动8.14.10.2117）：CrysisAnno1404Supreme CommanderNeed速度ShiftMafia IICall职责：现代战争2Battlefield：叛逆连队2根据Intel GMA3150可以帮助CPU解码MPEG2视频。的DXVAChecker显示挂钩MPEG2（VLD，MoComp，A和C）高达1920×1080。因此，N450和N470，GMA3150的性能是目前没有足够看具有较高的分辨率比720p的H.264编码的高清视频。高清Flash视频（例如从YouTube）也不会流利运行在Atom处理器。 GMA 3150的另一个缺点是支持的显示类型和分辨率。 GMA3150支持一个数字LVDS端口（连接内部显示），分辨率最高可达1366×768。此外，外部模拟VGA端口支持分辨率高达1400×1050。的DisplayPort，HDMI或DVI是不可能的（没有SDVO端口连接）。因此，带有HDMI端口的AtomN450上网本仅可能与即将推出的ION2 GPU。新的GMA3150的主要优点是，因为它是在Atom CPU集成的低功耗。

Graphics Media Accelerator 3000 Series

Graphics Media Accelerator (GMA) 3650 4/0 cores @ 0.64 GHz
Graphics Media Accelerator (GMA) 3600 4/0 cores @ 0.4 GHz
Graphics Media Accelerator (GMA) 3150 2/0 cores @ 0.2 GHz
CodenamePineview
ArchitectureGen. 4
Pipelines2 / 0 Pixel- / Vertexshader
Core Speed200 MHz
Shared Memoryyes
APIDirectX 9c, Shader 3.0
Transistor Count123 Million
technology45 nm
FeaturesOpenGL 1.5, Clear Video HD (SD Videos only), MPEG-2 Decode, Adaptive Interlacing,
Date of Announcement10.01.2010
Link to Manufacturer Pagewww.intel.com

Benchmarks

3DMark 2001SE - 3DMark 2001 - Standard
min: 2255     avg: 2544     median: 2483.5 (3%)     max: 3211 Points
+ 36 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
min: 588     avg: 693     median: 693 (0%)     max: 842 Points
+ 33 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 245     avg: 295.1     median: 299 (0%)     max: 332 Points
+ 38 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -55%
Intel Graphics Media Accelerator (GMA) 900
234 -21%
Intel Graphics Media Accelerator (GMA) 600
259.3 -12%
VIA Chrome9 HC
276.7 -6%
Intel Graphics Media Accelerator (GMA) 3150
295.1
SIS Mirage 3+ 672MX
314.7 7%
SIS Mirage 3 671MX
332.8 13%
ATI Radeon Xpress 1100
367 24%
Intel Graphics Media Accelerator (GMA) 950
407.3 38%
NVIDIA GeForce FX Go 5700
500 69%
ATI Mobility FireGL T2e
580 97%
ATI Mobility FireGL V3100
580 97%
ATI Radeon Xpress 200M
587 99%
NVIDIA GeForce Go 6150
631 114%
...
AMD Radeon RX 7600M XT
68064 22965%
max:
NVIDIA GeForce RTX 4080 Super
87172 29440%
0%
100%
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
min: 143     avg: 156.7     median: 158 (0%)     max: 169 points
+ 3 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 89     avg: 141.9     median: 144 (0%)     max: 164 Points
+ 35 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x800 +
3DMark 06
492 Points (1%)
+ 1 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x768 +
3DMark 06
min: 146     avg: 148     median: 148 (0%)     max: 150 Points
+ 2 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1024x768 +
3DMark 06
min: 136     avg: 149     median: 155 (0%)     max: 156 Points
+ 3 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
min: 2.9     avg: 3     median: 3 (38%)     max: 3 Points
+ 37 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 2.8     avg: 3     median: 3 (38%)     max: 3.1 Points
+ 37 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 241     avg: 284.6     median: 287.5 (0%)     max: 328 points
+ 42 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

StarCraft 2

StarCraft 2

2010
low 1024x768
3.5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sims 3

Sims 3

2009
low 800x600
5.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Left 4 Dead

Left 4 Dead

2008
low 640x480
2.5 2.7 ~ 3 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
12 12.9 ~ 12 fps    + Compare
high 1024x768
3.1 3.2 ~ 3 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
5 5 ~ 5 fps    + Compare
med. 1024x768
1 1 ~ 1 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Half Life 2 - Lost Coast Benchmark

Half Life 2 - Lost Coast Benchmark

2005
high 1024x768
4.4 5.2 ~ 5 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
F.E.A.R.

F.E.A.R.

2005
low 640x480
22  fps    + Compare
med. 800x600
5  fps    + Compare
high 1024x768
3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World of Warcraft

World of Warcraft

2005
low 800x600
4.9 5 ~ 5 fps    + Compare
med. 1024x768
3.4 3.5 ~ 3 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Counter-Strike Source

Counter-Strike Source

2004
low 640x480
8.4 8.5 ~ 8 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Doom 3

Doom 3

2004
low 640x480
5.4 5.5 ~ 5 fps    + Compare
med. 640x480
5.1 5.1 ~ 5 fps    + Compare
high 800x600
4.3 4.4 ~ 4 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
53.7  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
StarCraft 23.5
Sims 35.3
Left 4 Dead3
Trackmania Nations Forever123
World in Conflict - Benchmark51
Half Life 2 - Lost Coast Benchmark5
F.E.A.R.2253
World of Warcraft53
Counter-Strike Source8
Doom 3554
Quake 3 Arena - Timedemo53.7
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		9


4


4
1










For more games that might be playable and a list of all games and graphics cards visit our Gaming List
