Intel Graphics Media Accelerator (GMA) 3650

一个集成的处理器的英特尔图形媒体加速器3650或GMA3650显卡(例如在Atom N2800)没有专用的内存。它是基于了PowerVR SGX545的设计类似的GMA500​​(SGX 535)。这是不是很快速,无声的,所以是不是真的适合游戏。我们的测试表明,没有这么多场比赛,甚至不会启动的GPU,因此无法播放。进一步,宣布不支持DX10.1的givenname推出的DirectX 9 GMA3650的高清视频解码器,并输出到HDMI端口是可行的。

Graphics Media Accelerator 3000 Series

Graphics Media Accelerator (GMA) 3650 4/0 cores @ 0.64 GHz
Graphics Media Accelerator (GMA) 3600 4/0 cores @ 0.4 GHz
Graphics Media Accelerator (GMA) 3150 2/0 cores @ 0.2 GHz
CodenameCedar Trail
ArchitecturePowerVR SGX5
Pipelines4 / 0 Pixel- / Vertexshader
Core Speed640 MHz
Shared Memoryyes
APIDirectX 9.1
technology32 nm
FeaturesOpenGL 3.0
Date of Announcement01.11.2011
CPU in Graphics Media Accelerator (GMA) 3650GPU Base SpeedGPU Boost / Turbo
Intel Atom D27002 x 2130 MHz, 10 W640 MHz? MHz
Intel Atom N28502 x 2000 MHz, 6,6 W640 MHz? MHz
Intel Atom D25602 x 2000 MHz, 10 W640 MHz? MHz
min. - max.640 MHz? MHz

Benchmarks

3DMark 2001SE - 3DMark 2001 - Standard
3207 Points (3%)
3DMark 03 - 3DMark 03 - Standard
min: 2014     avg: 2284     median: 2284 (1%)     max: 2554 Points
3DMark 05 - 3DMark 05 - Standard
min: 809     avg: 905     median: 905 (1%)     max: 1001 Points
Intel Graphics Media Accelerator (GMA) 500
133.4 -85%
...
ATI Radeon Xpress 1150
633 -30%
NVIDIA GeForce Go 6100
655 -28%
NVIDIA GeForce 7000M
679 -25%
NVIDIA GeForce 7150M
700 -23%
738 -18%
Intel Graphics Media Accelerator (GMA) X3100
805 -11%
ATI Radeon Xpress X1200
839 -7%
NVIDIA GeForce Go 6200
900 -1%
NVIDIA GeForce Go 6400
900 -1%
Intel Graphics Media Accelerator (GMA) 3650
905
ATI Radeon Xpress X1270
983 9%
Intel Graphics Media Accelerator (GMA) 4500M
987 9%
ATI Radeon Xpress 1250
988 9%
ATI Mobility Radeon X300
994 10%
ATI Radeon Xpress X1250
1089 20%
ATI Mobility Radeon 9700
1200 33%
Intel Graphics Media Accelerator (GMA) 4500MHD
1224 35%
ATI Mobility FireGL V3200
1250 38%
ATI Mobility Radeon X1300
1333 47%
...
68064 7421%
max:
87172 9532%
0%
100%
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
440 points (1%)
3DMark 06 - Standard 1280x1024 +
3DMark 06
422 Points (1%)
Windows 7 Experience Index - Win7 Gaming graphics
3.4 Points (43%)
Windows 7 Experience Index - Win7 Graphics
5.9 Points (75%)
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 429     avg: 680     median: 435 (0%)     max: 1176 points
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
0 fps (0%)
- Range of benchmark values for this graphics card
- Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Anno 2070

Anno 2070

2011
low 1024x768
3.9  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
-1 (!)  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
F1 2011

F1 2011

2011
low 800x600
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Left 4 Dead

Left 4 Dead

2008
low 640x480
14.3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
lowmed.highultraQHD4K
Anno 20703.9
Fifa 12-1
F1 201112
Colin McRae: DIRT 2-1
Left 4 Dead14.3
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps
3

















For more games that might be playable and a list of all games and graphics cards visit our Gaming List
