Intel Graphics Media Accelerator (GMA) HD Graphics

英特尔图形媒体加速器HD显卡，英特尔高清显卡，GMA HD（或GMA5700MHD）是一个捆绑包中的新的Arrandale双核心CPU即将到来的2010年第一季度的笔记本电脑，主机板/共享内存显卡。根据GMA HD的CPU型号，主频为166和500 MHz（通过Turbo Boost最高。500-766兆赫）。相比，在45nm和32nm制程的CPU芯片，GPU和内存控制器。相比当前的GMA 4500MHD图形适配器，图形媒体加速器HD有两个领先的12个执行单元的着色器（或统一的着色器核心）。相同的英特尔高清显卡中的入门级Sandy Bridge处理器是这​​款显卡的继任者，并提供了一​​个更好的架构，因此速度更快。新的图形媒体加速器HD图形卡的性能比老GMA 4500MHD（由于人数的增加着色器，在某些情况下，还时钟速率）是noticable。在一些游戏中，甚至是尽可能快的GeForce 9400M / ION芯片组的GMA HD。平均而言，它应该是尽可能快地HD四千二百分之三千二百的由ATI，因此允许用户播放和要求不高的游戏中低设置。仍然还不如Nvidia和AMD显卡的驱动程序支持。此外，低电压和超低电压酷睿处理器含有较低的主频GMA HD显卡，因此速度较慢。此外，OpenGL性能仍然不是很好。例如老Doom 3和Quake 4的游戏不会运行得很流利。类似的4500MHD，还提供GMA HD高清视频硬件加速功能的芯片。 DXVA检查器列出支持MPEG2（VLD，IDCT，MoComp，A，C），H264（VLD，MoComp，IDCT），WMV9（MoComp，IDCT）和VC1（MoComp，IDCT）72x480，1280×720和1920×1080。大巴克兔子（1080P，H.264）解码一个东芝Tecra A11笔记本电脑采用酷睿i5-430M的CPU使用的是Windows媒体播放器使用显卡与CPU负载只有0-1％。当使用VLC不支持使用图形卡，CPU负载显着高于8-17％，在我们的测试。用同样的方法发现WMV视频（3-5％和7-12％的飞行法宝，1080）和VC-1视频（大象之梦1080p的5-8％和8-15％）。新的Arrandale处理器的Turbo Boost功能，还可以自动超频的GPU核心。显卡超频的CPU不满载，并，TDP是没有充分利用。高端酷睿​​i5 520M，540M，酷睿i7 620M：500-766 MHzLow结束：酷睿i3 330M，350M：500-677 MHzLow电压：酷睿i7 620LM，640LM：266-566 MHzUltra低的电压：酷睿i5-520UM，i5的620UM，640UM：166-500兆赫这是值得商榷的，如果TURBO是真的经常被用来在当前的游戏，大多数游戏也使用了大量的CPU时间。因此，UM和LM的GMA HD版本应该是慢了很多，因为基本速度慢266分之166兆赫。

CodenameGMA HD
ArchitectureGen. 5 Arrandale
Pipelines12 - unified
Core Speed500 MHz
Shared Memoryyes
APIDirectX 10, Shader 4.0
Power Consumption35 Watt
technology45 nm
Date of Announcement10.01.2010

Benchmarks

3DMark Vantage
3DM Vant. Perf. total +
3DMark Vantage - 3DM Vant. Perf. total
min: 119     avg: 267.6     median: 297.5 (0%)     max: 394 Points
+ 20 benchmarks and specifications   + Show comparison chart
3DM Vant. Perf. GPU no PhysX +
3DMark Vantage - 3DM Vant. Perf. GPU no PhysX
min: 90     avg: 202.7     median: 225 (0%)     max: 299 Points
+ 20 benchmarks and specifications   - Hide comparison chart
ATI Radeon HD 3200
62 -69%
NVIDIA GeForce 9400M GeForceBoost
96 -53%
ATI Radeon HD 4225
112 -45%
ATI Radeon HD 4250
172 -15%
ATI Radeon HD 4270
179 -12%
ATI Radeon HD 4200
179.5 -11%
Intel Graphics Media Accelerator (GMA) HD Graphics
202.7
NVIDIA GeForce 9300M GS
204 1%
ATI Mobility Radeon HD 3450
234 15%
NVIDIA GeForce G 103M
281 39%
NVIDIA GeForce 9200M GS
286 41%
AMD Radeon HD 6250
363 79%
AMD Radeon HD 6290
414 104%
NVIDIA GeForce 9400M (G) / ION (LE)
465 129%
AMD Radeon HD 7290
466 130%
Intel HD Graphics (Bay Trail)
512 153%
...
NVIDIA GeForce RTX 4090 Laptop GPU
132443 65239%
max:
AMD Radeon RX 7900 XTX
173912 85698%
0%
100%
Restrict / Search: Model: Max. age: years
3DMark 2001SE - 3DMark 2001 - Standard
min: 4735     avg: 8113     median: 8301.5 (9%)     max: 10934 Points
+ 22 benchmarks and specifications   + Show comparison chart
3DMark 03 - 3DMark 03 - Standard
min: 2681     avg: 3981     median: 3988 (2%)     max: 5007 Points
+ 57 benchmarks and specifications   + Show comparison chart
3DMark 05 - 3DMark 05 - Standard
min: 1093     avg: 2790     median: 2748 (3%)     max: 3429 Points
+ 71 benchmarks and specifications   - Hide comparison chart
Intel Graphics Media Accelerator (GMA) 500
133.4 -95%
...
ATI Mobility Radeon X1400
2284 -18%
ATI Radeon HD 3200
2324 -17%
ATI Radeon HD 4225
2365 -15%
ATI Mobility Radeon X700
2381 -15%
ATI Mobility FireGL V5000
2400 -14%
NVIDIA Quadro FX Go 1400
2517 -10%
AMD Radeon HD 6250
2622 -6%
NVIDIA GeForce 8400M GS
2671 -4%
NVIDIA GeForce G 102M
2723 -2%
Intel Graphics Media Accelerator (GMA) HD Graphics
2790
NVIDIA GeForce Go 6600
2800 0%
ATI Mobility Radeon 9800
2800 0%
ATI Mobility Radeon HD 2400
2872 3%
ATI Radeon HD 4270
2926 5%
NVIDIA Quadro NVS 140M
2943 5%
NVIDIA GeForce 9400M (G) / ION (LE)
3002 8%
ATI Mobility Radeon HD 2400 XT
3091 11%
ATI Radeon HD 4200
3100 11%
ATI Radeon HD 4250
3127 12%
...
AMD Radeon RX 7600M XT
69623 2395%
max:
NVIDIA GeForce RTX 4080 Super
87172 3024%
0%
100%
Restrict / Search: Model: Max. age: years
3DMark 06 3DMark 06 - Score Unknown Settings +
3DMark 06
min: 1076     avg: 1436     median: 1389 (2%)     max: 2013 points
+ 10 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x1024 +
3DMark 06
min: 994     avg: 1476     median: 1420 (2%)     max: 1968 Points
+ 54 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x800 +
3DMark 06
min: 1120     avg: 1461     median: 1402.5 (2%)     max: 1919 Points
+ 4 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1280x768 +
3DMark 06
min: 1122     avg: 1610     median: 1680.5 (2%)     max: 2119 Points
+ 18 benchmarks and specifications   + Show comparison chart
3DMark 06 - Standard 1152x864 +
3DMark 06
1599 Points (2%)
+ 1 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Gaming graphics
min: 3.2     avg: 4.9     median: 5.1 (65%)     max: 5.3 Points
+ 58 benchmarks and specifications   + Show comparison chart
Windows 7 Experience Index - Win7 Graphics
min: 2.4     avg: 4.1     median: 4 (51%)     max: 4.8 Points
+ 58 benchmarks and specifications   + Show comparison chart
Cinebench R10 Cinebench R10 Shading (32bit) +
Cinebench R10 - Cinebench R10 Shading (32bit)
min: 62     avg: 1720     median: 1790 (1%)     max: 3036 points
+ 74 benchmarks and specifications   + Show comparison chart
Cinebench R11.5 Cinebench R11.5 OpenGL 64 Bit +
Cinebench R11.5 - Cinebench R11.5 OpenGL 64 Bit
min: 0.68     avg: 1.2     median: 1.2 (0%)     max: 1.86 fps
+ 52 benchmarks and specifications   + Show comparison chart
- Range of benchmark values for this graphics card
red legend - Average benchmark values for this graphics card
* Smaller numbers mean a higher performance

Game Benchmarks

The following benchmarks stem from our benchmarks of review laptops. The performance depends on the used graphics memory, clock rate, processor, system settings, drivers, and operating systems. So the results don't have to be representative for all laptops with this GPU. For detailed information on the benchmark results, click on the fps number.

Diablo III

Diablo III

2012
low 1024x768
20  fps    + Compare
med. 1366x768
12  fps    + Compare
high 1366x768
10  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 2070

Anno 2070

2011
low 1024x768
10.3 23 ~ 17 fps    + Compare
med. 1366x768
4.2 14 ~ 9 fps    + Compare
high 1366x768
5  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 12

Fifa 12

2011
low 800x600
63.4  fps    + Compare
med. 1024x768
30.2  fps    + Compare
» With all tested laptops playable in detail settings low.
Deus Ex Human Revolution

Deus Ex Human Revolution

2011
low 1024x768
21  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Dirt 3

Dirt 3

2011
low 800x600
8  fps    + Compare
med. 1024x768
6  fps    + Compare
high 1360x768
3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Total War: Shogun 2

Total War: Shogun 2

2011
low 1024x768
18  fps    + Compare
med. 1280x720
10  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Fifa 11

Fifa 11

2010
low 800x600
22 58.2 80.5 ~ 54 fps    + Compare
med. 1024x768
14 30 43.2 ~ 29 fps    + Compare
high 1360x768
5 24.6 33.8 ~ 21 fps    + Compare
ultra 1920x1080
21.1  fps    + Compare
» With most tested laptops playable in detail settings low.
Mafia 2

Mafia 2

2010
low 800x600
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
StarCraft 2

StarCraft 2

2010
low 1024x768
11 26 27.9 31 ~ 24 fps    + Compare
med. 1360x768
5 6 10 ~ 7 fps    + Compare
high 1360x768
4 5 ~ 5 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Metro 2033

Metro 2033

2010
low 800x600
13  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Battlefield: Bad Company 2

Battlefield: Bad Company 2

2010
low 1024x768
8 16 ~ 12 fps    + Compare
med. 1366x768
5  fps    + Compare
high 1366x768
3  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
CoD Modern Warfare 2

CoD Modern Warfare 2

2009
low 800x600
26  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Risen

Risen

2009
low 800x600
20 22 ~ 21 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Resident Evil 5

Resident Evil 5

2009
low 800x600
33.8  fps    + Compare
high 1360x768
10.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Need for Speed Shift

Need for Speed Shift

2009
low 800x600
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Colin McRae: DIRT 2

Colin McRae: DIRT 2

2009
low 800x600
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Anno 1404

Anno 1404

2009
low 1024x768
21.6 26 26 27 30 ~ 26 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Sims 3

Sims 3

2009
low 800x600
82.1 89 91 96 ~ 90 fps    + Compare
med. 1024x768
29.7 32 34 35 ~ 33 fps    + Compare
high 1280x1024
21  fps    + Compare
» With all tested laptops playable in detail settings low.
F.E.A.R. 2

F.E.A.R. 2

2009
low 800x600
45  fps    + Compare
med. 1024x768
12  fps    + Compare
» With all tested laptops playable in detail settings low.
Left 4 Dead

Left 4 Dead

2008
low 640x480
53  fps    + Compare
high 1024x768
23  fps    + Compare
» With all tested laptops playable in detail settings low.
Far Cry 2

Far Cry 2

2008
low 640x480
25.7  fps    + Compare
high 1024x768
6.4  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis Warhead

Crysis Warhead

2008
low 800x600
15  fps    + Compare
ultra 1024x768
-1  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Trackmania Nations Forever

Trackmania Nations Forever

2008
low 640x480
92.3  fps    + Compare
high 1024x768
21.9  fps    + Compare
ultra 1920x1080
15  fps    + Compare
» With all tested laptops playable in detail settings low.
Call of Duty 4 - Modern Warfare

Call of Duty 4 - Modern Warfare

2007
low 800x600
28.3 47 ~ 38 fps    + Compare
med. 1024x768
13.2 16 ~ 15 fps    + Compare
» With most tested laptops playable in detail settings low.
Supreme Commander - FA Bench

Supreme Commander - FA Bench

2007
low 1024x768
18.1 19.3 20.6 21.7 21.8 ~ 20 fps    + Compare
med. 1024x768
9.8 11.7 11.9 12.1 12.2 ~ 12 fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis - GPU Benchmark

Crysis - GPU Benchmark

2007
low 1024x768
23  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Crysis - CPU Benchmark

Crysis - CPU Benchmark

2007
low 1024x768
23  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World in Conflict - Benchmark

World in Conflict - Benchmark

2007
low 800x600
39  fps    + Compare
med. 1024x768
13  fps    + Compare
high 1024x768
8  fps    + Compare
» With all tested laptops playable in detail settings low.
Half Life 2 - Lost Coast Benchmark

Half Life 2 - Lost Coast Benchmark

2005
high 1024x768
47.4  fps    + Compare
» With all tested laptops playable in detail settings high.
Quake 4

Quake 4

2005
low 640x480
12  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
World of Warcraft

World of Warcraft

2005
low 800x600
97 98 ~ 98 fps    + Compare
med. 1024x768
32 36 ~ 34 fps    + Compare
high 1280x1024
7  fps    + Compare
» With all tested laptops playable in detail settings low.
Counter-Strike Source

Counter-Strike Source

2004
high 1024x768
79  fps    + Compare
» With all tested laptops playable in detail settings high.
Doom 3

Doom 3

2004
low 640x480
22  fps    + Compare
med. 640x480
21.8  fps    + Compare
high 800x600
21.6  fps    + Compare
ultra 1024x768
21.2  fps    + Compare
» The benchmarks indicate that the game is not playable in the tested settings.
Quake 3 Arena - Timedemo

Quake 3 Arena - Timedemo

1999
high 1024x768
155  fps    + Compare
» With all tested laptops playable in detail settings high.
lowmed.highultraQHD4K
Diablo III201210
Anno 20701795
Fifa 1263.430.2
Deus Ex Human Revolution21
Dirt 3863
Total War: Shogun 21810
Fifa 1154292121.07
Mafia 2-1
StarCraft 22475
Metro 203313
Battlefield: Bad Company 21253
CoD Modern Warfare 226
Risen21
Resident Evil 533.810.2
Need for Speed Shift-1
Colin McRae: DIRT 2-1
Anno 140426
Sims 3903321
F.E.A.R. 24512
Left 4 Dead5323
Far Cry 225.76.4
Crysis Warhead15-1
Trackmania Nations Forever92.321.915
Call of Duty 4 - Modern Warfare3815
Supreme Commander - FA Bench2012
Crysis - GPU Benchmark23
Crysis - CPU Benchmark23
World in Conflict - Benchmark39138
Half Life 2 - Lost Coast Benchmark47.44
Quake 412
World of Warcraft98347
Counter-Strike Source79
Doom 32221.821.621.2
Quake 3 Arena - Timedemo155
< 30 fps
< 60 fps
< 120 fps
≥ 120 fps		18
6
4
12
3

14
1
1
1		3








For more games that might be playable and a list of all games and graphics cards visit our Gaming List

v1.29
log 16. 05:52:33

#0 ran 0s before starting gpusingle class +0s ... 0s

#1 no ids found in url (should be separated by "_") +0s ... 0s

#2 not redirecting to Ajax server +0s ... 0s

#3 did not recreate cache, as it is less than 5 days old! Created at Thu, 13 Mar 2025 11:17:12 +0100 +0.001s ... 0.001s

#4 composed specs +0.045s ... 0.047s

#5 did output specs +0s ... 0.047s

#6 start showIntegratedCPUs +0s ... 0.047s

#7 getting avg benchmarks for device 1549 +0.022s ... 0.069s

#8 got single benchmarks 1549 +0.619s ... 0.688s

#9 got avg benchmarks for devices +0s ... 0.688s

#10 min, max, avg, median took s +0.888s ... 1.576s

#11 before gaming benchmark output +0s ... 1.576s

#12 Got 105 rows for game benchmarks. +0.037s ... 1.612s

#13 composed SQL query for gamebenchmarks +0s ... 1.612s

#14 got data and put it in $dataArray +0.025s ... 1.637s

#15 benchmarks composed for output. +0.32s ... 1.957s

#16 no comparison url found in template nbc.compare_page_1 needed +0.003s ... 1.961s

#17 return log +0s ... 1.961s

Notebook reviews with Intel Graphics Media Accelerator (GMA) HD Graphics graphics card

Lenovo ThinkPad Edge 15: Intel Core i3-350M, 15.60", 2.6 kg
  External Review » Lenovo ThinkPad Edge 15

Please share our article, every link counts!
Mail Logo

» Comparison of GPUs
Detailed list of all laptop GPUs sorted by class and performance.

» Benchmark List
Sort and restrict laptop GPUs based on performance in synthetic benchmarks.

» Notebook Gaming List
Playable games for each graphics card and their average FPS results.

Class 1

Class 2

Radeon RX 6800S
GeForce RTX 5060 Laptop *
Radeon RX 8060S *
Radeon RX 7600M XT *
Radeon RX 7700S *
M3 Max 40-Core GPU *
M2 Max 38-Core GPU *
GeForce RTX 2080 Mobile
Radeon RX 6700M
M3 Max 30-Core GPU *
Quadro RTX 5000 (Laptop)
Radeon RX 7600M *
M4 Max 32-Core GPU *
M2 Max 30-Core GPU *
GeForce RTX 3060 Laptop GPU
M1 Max 32-Core GPU *
Radeon RX 7600S
GeForce RTX 2070 Super Mobile
GeForce RTX 2080 Super Max-Q
RTX A3000 Laptop GPU
M1 Max 24-Core GPU *
A770M
Radeon RX 6650M XT *
M3 Pro 18-Core GPU *
M2 Pro 19-Core GPU *
Radeon RX 6650M
Radeon RX 6600M
Radeon RX 6700S
GeForce RTX 2070 Mobile
Quadro RTX 5000 Max-Q
GeForce RTX 2080 Max-Q
Radeon RX 8050S *
Radeon RX 5700M *
GeForce GTX 1080 Mobile
Quadro RTX 4000 (Laptop)
M3 Pro 14-Core GPU *
M2 Pro 16-Core GPU *
M1 Pro 16-Core GPU *
Radeon PRO W6600M *
GeForce RTX 2070 Super Max-Q
Quadro RTX 4000 Max-Q *
M1 Pro 14-Core GPU *
GeForce RTX 2070 Max-Q *
Radeon RX 6600S *
Quadro P5200
Quadro RTX 3000 (Laptop) *
GeForce RTX 5050 Laptop *
GeForce RTX 2060 Mobile
Quadro RTX 3000 Max-Q *
GeForce GTX 1080 Max-Q
GeForce GTX 1070 Mobile
GeForce RTX 2060 Max-Q *
Quadro P4200
NVIDIA GeForce RTX 4050 Laptop GPU
Nvidia RTX 1000 Ada Generation Laptop GPU
RTX A2000 Laptop GPU
A730M *
Radeon RX 8040S *
Radeon Pro 5600M *
Radeon RX 5600M
Quadro P5000
GeForce GTX 1660 Ti Mobile
GeForce RTX 3050 Ti Laptop GPU
GeForce RTX 3050 6GB Laptop GPU
A570M *
RTX A1000 Laptop GPU
GeForce GTX 1070 Max-Q
Arc 140T *
A550M *
Quadro P5000 Max-Q *
Radeon 890M *
Arc 130T *
GeForce RTX 3050 A Laptop GPU
GeForce RTX 3050 4GB Laptop GPU
Nvidia RTX 500 Ada Generation Laptop GPU
A530M *
GeForce GTX 1660 Ti Max-Q
RTX A500 Laptop GPU
Radeon RX 6550M *
Radeon RX 6500M
Radeon RX 6550S *
GeForce GTX 980 (Laptop)
Quadro M5500
Quadro P4000
Quadro T2000 (Laptop) *
GeForce GTX 1060 Mobile
GeForce GTX 1650 Ti Mobile
A370M *
Radeon RX 5500M
Radeon Pro 5500M *
Quadro P4000 Max-Q
Quadro P3200
Radeon RX 580X (Laptop) *
Radeon RX 580 (Laptop)
Radeon RX 6450M *
Arc 8-Core *
GeForce RTX 2050 Mobile
Arc 140V *
Radeon RX 6300M *
GeForce GTX 1650 Mobile
GeForce MX570
Radeon Pro 5300M
Radeon RX 5300M
Quadro P3000
GeForce GTX 1060 Max-Q
Quadro P3000 Max-Q *
GeForce GTX 1650 Ti Max-Q *
Quadro T2000 Max-Q *
Quadro T1000 (Laptop) *
Arc 130V *
Radeon Pro WX 7100 *
Arc 7-Core *
Radeon RX 570X (Laptop) *

Class 3

M4 8-Core GPU *
Radeon RX 570 (Laptop) *
Radeon RX 470 (Laptop) *
GeForce GTX 1650 Max-Q *
T1200 Laptop GPU *
Quadro T1000 Max-Q *
A310 *
A350M *
T600 Laptop GPU *
T550 Laptop GPU *
GeForce GTX 980M
Vega M GH
Quadro M5000M
Radeon Pro Vega 20
Radeon 880M *
Adreno 830 *
Adreno X1-85 4.6 TFLOPS *
Radeon 780M *
GeForce MX550
GeForce GTX 1050 Ti Mobile
Radeon 680M
Quadro P2000
Quadro P2000 Max-Q
Quadro M4000M
GeForce GTX 970M
T500 Laptop GPU *
GeForce MX450 *
Radeon R9 M395X
GeForce GTX 1050 Ti Max-Q *
Radeon Pro Vega 16
Vega M GL / 870
WX Vega M GL
Radeon R9 M485X
Quadro M3000M
GeForce GTX 1050 Mobile
FirePro W7170M
Radeon R9 M395
GeForce GTX 1050 Max-Q *
Radeon 860M *
Radeon 760M *
Adreno X1-85 3.8 TFLOPS *
Radeon Radeon Steam Deck 8CU
Radeon 660M
Radeon Pro WX 4150 *
GeForce GTX 965M
Radeon RX 560X (Laptop)
Radeon RX 560 (Laptop)
Quadro M2200
Radeon RX 460 (Laptop)
Quadro P1000
Radeon R9 M390
Xe MAX
Radeon Pro 560X
Radeon Pro 560
Radeon Pro 460
Radeon Pro WX 4130 *
Iris Xe G7 96EUs
GeForce MX350
GeForce GTX 960M
Quadro M1200
Quadro P620 *
Radeon RX 550X (Laptop)
Radeon RX 550 (Laptop)
Radeon RX 640
Radeon Pro WX 3200 *
Radeon Pro 555X
Radeon Pro 555
Radeon Pro 455
Quadro P600
GeForce MX250
GeForce MX330
GeForce MX150
Arc Graphics 3-core (Arrow Lake) *
Iris Xe G7 80EUs
Radeon 840M *
Radeon 740M *
Graphics 4-Core *
Quadro M2000M
Radeon RX 540X *
Radeon Pro WX 2100 *
Radeon RX 540 *
Radeon Pro WX 3100 *
Arc Graphics 2-core (Arrow Lake) *
GeForce GTX 950M
Radeon Pro 450
Adreno X1-45 2.1 TFLOPS *
Radeon 630
Radeon 540X *
Radeon R9 M470X *
Radeon R9 M385X
Quadro P520
Quadro M1000M
Quadro M620 *
GeForce 945M
Quadro P500 *
UHD Graphics 64EUs
Iris Plus Graphics G7 (Ice Lake 64 EU) *
Vega 10 *
Iris Pro Graphics P580
Iris Pro Graphics 580
Adreno X1-45 1.7 TFLOPS *
Radeon R9 M470 *
FirePro W5170M *
Radeon R9 M370X
Vega 9
FirePro W5130M
UHD Graphics Xe G4 48EUs *
UHD Graphics 32EUs
UHD Graphics Xe 32EUs (Tiger Lake-H) *
UHD Graphics 750
UHD Graphics 730
GeForce MX230
Vega 8 *
Vega 7
Radeon R7 M465
Iris Pro Graphics 6200
GeForce MX130
GeForce 940MX
Quadro M520
Vega 8
GeForce 940M
Iris Plus Graphics G4 (Ice Lake 48 EU)
GeForce 930MX
Quadro M600M
FirePro W4190M
Radeon R9 M375
Iris Plus Graphics 655
Radeon R7 M445
Quadro M500M
Iris Plus Graphics 650
GeForce 930M
Iris Graphics 550
Radeon 530
Radeon 625
Vega 6 *
Iris Plus Graphics 645
GeForce MX110 *
Iris Plus Graphics 640
GeForce 920MX
Iris Graphics 540
UHD Graphics 24EUs (Alder Lake-N) *
Radeon R7 (Bristol Ridge) *
Radeon R7 M460 *
Radeon R7 M360
GeForce 920M
Radeon R8 M445DX
Radeon 620
Radeon R7 M440
Radeon R7 M340
Radeon 520
Radeon 610
Radeon Graphics (Ryzen 7000)
Radeon 610M *
Vega 6 *
Vega 5 *
UHD Graphics G1 (Ice Lake 32 EU)
UHD Graphics Xe 16EUs (Tiger Lake-H) *
HD Graphics 530
Radeon R5 (Bristol Ridge)
UHD Graphics 620
HD Graphics 620
Adreno 690 *
Adreno 685 *
Adreno 680 *
Radeon R5 M330
Radeon R5 M430
Vega 3 *
GeForce 910M
HD Graphics 520
Iris Graphics 6100

Class 4

Radeon R5 M320 *
Radeon R5 M315 *
Radeon R5 M420 *
Vega 2 *
Radeon R5 (Stoney Ridge)
HD Graphics 6000
UHD Graphics (Jasper Lake 32 EU) *
UHD Graphics 617
UHD Graphics 615
UHD Graphics (Jasper Lake 24 EU) *
HD Graphics 615
HD Graphics 515
UHD Graphics 610
HD Graphics 610
HD Graphics 510
UHD Graphics (Jasper Lake 16 EU)
UHD Graphics 605
HD Graphics 505
Radeon R4 (Stoney Ridge)
Radeon R2 (Stoney Ridge)
VideoCore VII *
UHD Graphics 600
HD Graphics 500
HD Graphics 405 (Braswell)
HD Graphics (Braswell)
HD Graphics 400 (Braswell)

Class 5

* Approximate position of the graphics adapter

Klaus Hinum (Update: 2016-01-26)
